hbmame (0.289.2) • machine gekiridn02 • Gekirindan (Chinese)

machine

• XML • JSON • RUN

name	sourcefile	cloneof	romof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	sampleof
gekiridn02	hbmame/drivers/taito_f3.cpp	gekiridn	gekiridn	no	no	no	yes	Gekirindan (Chinese)	1995	hack

snap

Gekirindan (Chinese) png snap

Gekirindan (Chinese) jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
gekiridn02	27973	04/03/2026 14:19:46	232	320	96	96	0	Format24bppRgb	305:HBMAME 0.245.31 (2026-03-01)	e32b2cdcc168333f2540d0d6efa06ec3f12661f0

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	270	320	232	58.943844	6671500	432	46	366	262	24	256	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
imperfect	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
e11-01c.bin	2097152	e19874b3	a8d6806133977a7decefafff5d7b249803add70b	sprites_hi	0	good	no
e11-02c.bin	2097152	a2c4fa4f	2ad73ce8431f1199dd32df83352dc4f85345529f	sprites	1	good	no
e11-03c.bin	2097152	2b0dab58	7c70a2104fbbfde32fa006bfafe30c3d9708cb10	sprites	0	good	no
e11-04.ic38	2097152	e0ff4fb1	81e186e3a692af1da316b8085a729c4f103d9a52	taito_en:ensoniq	0	good	no	e11-04.ic38
e11-05.ic41	2097152	a4d08cf1	ae2cabef7b7bcb8a788988c73d7af6fa4bb2c444	taito_en:ensoniq	400000	good	no	e11-05.ic41
e11-06c.bin	2097152	0acc71d3	455c70ec8f1087189170160d5683545bbea1fe9a	tilemap_hi	0	good	no
e11-07c.bin	2097152	15ca8ac2	33cbcc96e5144e5910c67c99815958d8f004287e	tilemap	2	good	no
e11-08c.bin	2097152	93884253	6d0530db64c84bf7b2ad47e94036ecd8c81418b6	tilemap	0	good	no
e11-09c.bin	262144	24d884ff	35ddb21608c781a0674a4244c8e5c0aa6dc220eb	maincpu	3	good	no
e11-10c.bin	262144	b1ff4529	9e8366d9d90ad4155aab3828523daff09e3d400d	maincpu	2	good	no
e11-11c.bin	262144	8ae457c4	f1d74d99c916df90a74be0ff80b05b0f31284306	maincpu	1	good	no
e11-12c.bin	262144	448308ce	22eac25158bd3a0349aa4f1f041473b93030ee43	maincpu	0	good	no
e11-13.bin	131072	51a11ff7	c03042489d71423667f25856d15aa6a363ea6c92	taito_en:audiocpu	100000	good	no
e11-14.bin	131072	dce2ba91	00bc353c7747a7954365b587d7bc759ee5dc09c2	taito_en:audiocpu	100001	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68EC020	16000000
cpu	taito_en:audiocpu	Motorola MC68000	15238090
cpu	taito_en:esp	Ensoniq ES5510	10000000
audio	speaker	Speaker
audio	taito_en	Taito Ensoniq Sound System
audio	taito_en:pump	Ensoniq 5505/5506 to 5510 interface	29761
audio	taito_en:ensoniq	Ensoniq ES5505	15238090

device_ref

tag	name
:maincpu	m68ec020
:eeprom	93c46_16
:watchdog	watchdog
:screen	screen
:gfxdecode	gfxdecode
:palette	palette
:speaker	speaker
:taito_en	taito_en
:taito_en:audiocpu	m68000
:taito_en:esp	es5510
:taito_en:duart68681	mc68681
:taito_en:duart68681:cha	duart_channel
:taito_en:duart68681:chb	duart_channel
:taito_en:mb87078	mb87078
:taito_en:dpram	mb8421
:taito_en:pump	esq_5505_5510_pump
:taito_en:ensoniq	es5505

sound

channels
1

feature

type	overall	status
sound	imperfect

input

players	coins	service	tilt
4	4	yes	yes

control

type	player	ways	reverse	buttons	minimum	maximum	sensitivity	keydelta	ways2
joy	1	8	no	4
dial	1		no		0	4095	25	25
joy	2	8	no	4
dial	2		no		0	4095	25	25
joy	3	8	no	4
joy	4	8	no	4

port, analog

port_tag	analog_masks
:DIAL.0	4095
:DIAL.1	4095
:EEPROMIN
:EEPROMOUT
:IN.0
:IN.1
:IN.2
:IN.3
:IN.4
:IN.5
