name	sourcefile	cloneof	romof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	sampleof
grdians	seta2.cpp			no	no	no	yes	Guardians / Denjin Makai II (P-FG01-1 PCB)	1995	Winkysoft (Banpresto license)

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	304	232	60.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
imperfect	good	unsupported	no	no	no	no	preliminary

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
u2.bin	524288	36adc6f2	544e87f88179fe1342e7a06a8948ac1828e85108	maincpu	0	good	no
u3.bin	524288	2704f416	9081a12cbb9927d36e1c50b52aa2c6003810ee42	maincpu	1	good	no
u4.bin	524288	bb52447b	61433f683210ab2bc2cf1cc4b5b7a39cc5b6493d	maincpu	100000	good	no
u5.bin	524288	9c164a3b	6d688c7af9e7e8e8d54b2e4dfbf41f59c79242eb	maincpu	100001	good	no
u16.bin	4194304	6a65f265	6cad11f718f8bbcff464d41eb4717460769237ed	sprites	0	good	no
u15.bin	4194304	01672dcd	f61f60e3343cc5b6ccee391ee529966a141566db	sprites	2	good	no
u18.bin	4194304	967babf4	42a6311576417c44aeaceb8ba6bb3cd7794e4882	sprites	4	good	no
u17.bin	4194304	0fad0629	1bdc8e7c5e39e83d327f14a672ec81b049112da6	sprites	6	good	no
u20.bin	4194304	a7226ab7	408580dd35c568ffef1ebbd87359e3ec1f867020	sprites	1800000	good	no
u19.bin	4194304	c0c998a0	498fb1877527ed37412537f06a2c39ff0c60f146	sprites	1800002	good	no
u22.bin	4194304	6239997a	87b6d6f30f152f625f82fd858c1290176c7e156e	sprites	1800004	good	no
u21.bin	4194304	6f95e466	28482fad16a3ac9302f152d81552e6f84a44f3e4	sprites	1800006	good	no
u32.bin	1048576	cf0f3017	8376d3a674f71aec72f52c72758fbc53d9feb1a1	x1snd	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Toshiba TMP68301	16666666
audio	mono	Speaker
audio	x1snd	Seta X1-010	16666666

device_ref

name
tmp68301
watchdog
screen
gfxdecode
palette
speaker
x1_010

sound

channels
1

feature

type	status	overall
graphics	imperfect

input

players	coins	service	tilt
2	2	yes	no

control

type	player	ways	reverse	buttons	minimum	maximum	sensitivity	keydelta	ways2	reqbuttons
joy	1	8	no	3
joy	2	8	no	3

port, analog

port_tag	analog_masks
:DSW1
:DSW2
:P1
:P2
:SYSTEM

dipswitch

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW1	3

location

name	number	inverted
SW1	1	no
SW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Easy	2	no
Normal	3	yes
Hard	1	no
Hardest	0	no

Bonus Life

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bonus Life	DSW1	4

location

name	number	inverted
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
300000	4	yes
500000	0	no

Title

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Title	DSW1	8

location

name	number	inverted
SW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Guardians	8	yes
Denjin Makai II	0	no

Lives

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Lives	DSW1	48

location

name	number	inverted
SW1	5	no
SW1	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1	32	no
2	48	yes
3	16	no
4	0	no

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	DSW1	64

location

name	number	inverted
SW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW1	128

location

name	number	inverted
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	128	yes

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSW2	15

location

name	number	inverted
SW2	1	no
SW2	2	no
SW2	3	no
SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
4 Coins/1 Credit	2	no
3 Coins/1 Credit	5	no
2 Coins/1 Credit	8	no
3 Coins/2 Credits	4	no
4 Coins/3 Credits	1	no
1 Coin/1 Credit	15	yes
3 Coins/4 Credits	3	no
2 Coins/3 Credits	7	no
1 Coin/2 Credits	14	no
2 Coins/5 Credits	6	no
1 Coin/3 Credits	13	no
1 Coin/4 Credits	12	no
1 Coin/5 Credits	11	no
1 Coin/6 Credits	10	no
1 Coin/7 Credits	9	no
Free Play	0	no

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSW2	240

location

name	number	inverted
SW2	5	no
SW2	6	no
SW2	7	no
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
4 Coins/1 Credit	32	no
3 Coins/1 Credit	80	no
2 Coins/1 Credit	128	no
3 Coins/2 Credits	64	no
4 Coins/3 Credits	16	no
1 Coin/1 Credit	240	yes
3 Coins/4 Credits	48	no
2 Coins/3 Credits	112	no
1 Coin/2 Credits	224	no
2 Coins/5 Credits	96	no
1 Coin/3 Credits	208	no
1 Coin/4 Credits	192	no
1 Coin/5 Credits	176	no
1 Coin/6 Credits	160	no
1 Coin/7 Credits	144	no
Free Play	0	no
