hbmame (0.289.2) • machine kovps23 • Knights of Valour Plus 2015 (Authentic 2015 Nightmare, 2015-07-07)

machine

• XML • JSON • RUN

name	sourcefile	cloneof	romof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	sampleof
kovps23	hbmame/drivers/pgm.cpp	kovplus	kovplus	no	no	no	yes	Knights of Valour Plus 2015 (Authentic 2015 Nightmare, 2015-07-07)	2015	hack

snap

Knights of Valour Plus 2015 (Authentic 2015 Nightmare, 2015-07-07) png snap

Knights of Valour Plus 2015 (Authentic 2015 Nightmare, 2015-07-07) jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
kovps23	30423	27/08/2026 20:25:12	448	224	96	96	0	Format24bppRgb	305:HBMAME 0.289.1 (2026-08-03)	7de09358cee69094f882c98952f52fa157fa122f

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	448	224	59.185606	10000000	640	0	448	264	0	224	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
imperfect	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
a0600_ph115.rom	8388608	5bd7ea9f	0eb33bd0e23441394ae7c6fa28aafe11adf0b22f	igs023:sprcol	0	good	no
b0600_ph115.rom	8388608	07d91ea3	8713409439eb4a2875baffbda711587f283a652b	igs023:sprmask	0	good	no
m0600_ph03.rom	4194304	01059d4f	a18a960afd90e2574b31ef8b347ba1d38a12ef89	ics	400000	good	no
p0600_ph170.120	4194304	694e68be	e9e98aa5e65fa4080446312ff262837312bb1ca0	maincpu	100000	good	no
pgm_a0601.u4	8388608	ff7a4373	7def9fca7513ad5a117da230bebd2e3c78679041	igs023:sprcol	800000	good	no	pgm_a0601.u4
pgm_a0602.u6	8388608	e7a32959	3d0ed684dc5b269238890836b2ce7ef46aa5265b	igs023:sprcol	1000000	good	no	pgm_a0602.u6
pgm_a0603.u9	4194304	ec31abda	ee526655369bae63b0ef0730e9768b765c9950fc	igs023:sprcol	1800000	good	no	pgm_a0603.u9
pgm_b0601.u7	4194304	a0bb1c2f	0542348c6e27779e0a98de16f04f9c18158f2b28	igs023:sprmask	800000	good	no	pgm_b0601.u7
pgm_m01s.rom	2097152	45ae7159	d3ed3ff3464557fd0df6b069b2e431528b0ebfa8	ics	0	good	no	pgm_m01s.rom
pgm_p01s.u20	131072	e42b166e	2a9df9ec746b14b74fae48b1a438da14973702ea	maincpu	0	good	no	pgm_p01s.u20	v1
pgm_p02s.u20	131072	78c15fa2	885a6558e022602cc6f482ac9667ba9f61e75092	maincpu	0	good	no	pgm_p02s.u20	v2
pgm_t01s.rom	2097152	1a7123a0	cc567f577bfbf45427b54d6695b11b74f2578af3	igs023	0	good	no	pgm_t01s.rom
t0600.ph17	8388608	84567fa4	932fdd8095b499acbac69035c12929a2dc9a5564	igs023	180000	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	20000000
cpu	soundcpu	Zilog Z80	8467200
cpu	prot	ARM7 (little)	20000000
audio	mono	Speaker
audio	ics	ICS2115 WaveFront Synthesizer	33868800

device_ref

tag	name
:maincpu	m68000
:scantimer	timer
:soundcpu	z80
:sram	nvram
:rtc	v3021
:screen	screen
:palette	palette
:mono	speaker
:soundlatch1	generic_latch_8
:soundlatch2	generic_latch_8
:soundlatch3	generic_latch_8
:igs023	igs023
:ics	ics2115
:prot	arm7_le

biosset

name	description	default
v2	PGM BIOS V2	no
v1	PGM BIOS V1	no

sound

channels
1

feature

type	overall	status
sound	imperfect

input

players	coins	service	tilt
4	4	no	no

control

type	player	ways	reverse	buttons	minimum	maximum	sensitivity	keydelta	ways2
joy	1	8	no	4
joy	2	8	no	4
joy	3	8	no	4
joy	4	8	no	4

port, analog

port_tag	analog_masks
:DSW
:P1P2
:P3P4
:Region
:Service

configuration

Region

name	tag	mask
Region	Region	15

setting

name	value	default
China	0	no
Taiwan	1	no
Japan (Alta license)	2	no
Korea	3	no
Hong Kong	4	no
World	5	yes

dipswitch

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	DSW	1

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Music

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Music	DSW	2

location

name	number	inverted
SW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	2	yes

Voice

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Voice	DSW	4

location

name	number	inverted
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	4	yes

Free

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Free	DSW	8

location

name	number	inverted
SW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Stop

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stop	DSW	16

location

name	number	inverted
SW1	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	32

location

name	number	inverted
SW1	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	64

location

name	number	inverted
SW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Debug

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Debug	DSW	128

location

name	number	inverted
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no
