NBA Jam Rewind (rev 1.1) - mame (0.245.25) machine

MAME: 0.245.25 - Released: 1601-01-01T00:00:00 - Lists: 2 - Software: 266 - rom: 266 - disk: 0

machine

• XML • JSON • AO

name	sourcefile	cloneof	romof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	sampleof
nbajam02	midtunit.cpp	nbajamte	nbajamte	no	no	no	yes	NBA Jam Rewind (rev 1.1)	2022	Asure

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	400	254	54.706840	8000000	506	100	500	289	20	274	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge
l1_nba_jam_tournament_u3_sound_rom.u3	131072	d4551195	e8908fbe4339fb8c93f7e74113dfd25dda1667ea	adpcm:cpu	10000	good	no	l1_nba_jam_tournament_u3_sound_rom.u3
nbajam02.u12	524288	cd5d4532	63ff4b5b22e02ee90cdcb745acc6bf9dbc1c3140	adpcm:oki	0	good	no
nbajam02.u13	524288	e92fb0d3	bac12a69f74051cb97326c05eb77d88acdf81a63	adpcm:oki	80000	good	no
nbajam02.uj12	524288	9b3fc483	4e7b6b85d9972063ebdb08ad2c860e082b6e886b	maincpu	0	good	no
nbajam02.ug12	524288	18e75204	e33eaa969dbc7ac19641238fc62d2af4d75bddef	maincpu	1	good	no
l1_nba_jam_tournament_game_rom_ug14.ug14	524288	04bb9f64	9e1a8c37e14cb6fe67f4aa3caa9022f356f1ca64	gfxrom	0	good	no	l1_nba_jam_tournament_game_rom_ug14.ug14
l1_nba_jam_tournament_game_rom_uj14.uj14	524288	b34b7af3	0abb74d2f414bc9da0380a81beb134f3a87c1a0a	gfxrom	1	good	no	l1_nba_jam_tournament_game_rom_uj14.uj14
l1_nba_jam_tournament_game_rom_ug19.ug19	524288	a8f22fbb	514208a9d6d0c8c2d7847cc02d4387eac90be659	gfxrom	2	good	no	l1_nba_jam_tournament_game_rom_ug19.ug19
l1_nba_jam_tournament_game_rom_uj19.uj19	524288	8130a8a2	f23f124024285d07d8cf822817b62e42c38b82db	gfxrom	3	good	no	l1_nba_jam_tournament_game_rom_uj19.uj19
nbajam02.ug16	524288	b9a07a6f	0b9410ae9d761928b828449f45302f0951a6a8af	gfxrom	200000	good	no
nbajam02.uj16	524288	ffa7db04	984a1011f378d7e77acf43f285f7c72f035fc7ee	gfxrom	200001	good	no
nbajam02.ug20	524288	67c8646b	a0584e79cdd5c83cd62bda09470f67082a670fe1	gfxrom	200002	good	no
nbajam02.uj20	524288	71d028f8	6c9d3cb6b937a53af8be0c7c5e209fb8740d6d9a	gfxrom	200003	good	no
nbajam02.ug17	524288	34c6bdb8	fe613fc3256eafc368ba566dd989c05293df1829	gfxrom	400000	good	no
nbajam02.uj17	524288	3af5b32e	397d2524a5749f8e8419280cc3c48ec3081834b5	gfxrom	400001	good	no
nbajam02.ug22	524288	d41234d2	9dab65c7843758572634c4805227fee1850b0349	gfxrom	400002	good	no
nbajam02.uj22	524288	42196c84	7f30204a4764b4afd38cf82f8be909c9ee5a0a0b	gfxrom	400003	good	no
nbajam02.ug18	524288	fe18a6ef	58b8bbf257b3de5d7536421dda302e2d93f51999	gfxrom	600000	good	no
nbajam02.uj18	524288	9a6d36de	1bb24ff5fdbdc1f7265da0ba43e3d96ab589548f	gfxrom	600001	good	no
nbajam02.ug23	524288	8d1af1a6	4de21240ec0ffce9346e75b9719d9ae71bfbdb8e	gfxrom	600002	good	no
nbajam02.uj23	524288	b5bf66f9	de12e47e44f9cf7c611d674fe6c9b3466fde2081	gfxrom	600003	good	no

chip

type	tag	name	clock
cpu	maincpu	Texas Instruments TMS34010	50000000
cpu	adpcm:cpu	Motorola MC6809E	2000000
audio	speaker	Speaker
audio	adpcm	Williams ADPCM Sound Board
audio	adpcm:ym2151	YM2151 OPM	3579545
audio	adpcm:dac	AD7524 DAC
audio	adpcm:oki	OKI MSM6295 ADPCM	1000000

device_ref

name
tunitvid
tms34010
nvram
watchdog
palette
screen
speaker
wmsadpcm
mc6809e
ym2151
ad7524
okim6295

sound

channels
1

input

players	coins	service	tilt
4	4	yes	yes

control

type	player	ways	reverse	buttons
joy	1	8	no	3
joy	2	8	no	3
joy	3	8	no	3
joy	4	8	no	3

port, analog

port_tag	analog_masks
:DSW
:IN0
:IN1
:IN2

dipswitch

Test Switch

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Test Switch	DSW	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Powerup Test

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Powerup Test	DSW	2

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	2	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	4

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	8

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	32

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	32	yes

Dollar Bill Validator

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Dollar Bill Validator	DSW	64

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Installed	0	no
Not Present	64	yes

Players

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Players	DSW	128

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
2	0	no
4	128	yes

Coin Counters

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin Counters	DSW	768

value

name	value	default
1 Counter, 1 count/coin	768	yes
1 Counter, Totalizing	512	no
2 Counters, 1 count/coin	256	no

Country

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Country	DSW	3072

value

name	value	default
USA	3072	yes
French	2048	no
German	1024	no

Coinage

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage	DSW	28672

value

name	value	default
1	28672	yes
2	12288	no
3	20480	no
4	4096	no
ECA	24576	no
Free Play	0	no

Coinage Source

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage Source	DSW	32768

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Dipswitch	32768	no
CMOS	0	yes
