NBA Jam Tournament Edition SE (rev 5.02) - hbmame (0.245.26) machine

HBMAME: 0.245.26 - Released: 1601-01-01T00:00:00 - Lists: 2 - Software: 266 - rom: 266 - disk: 0

machine

• XML • JSON • AO

name	sourcefile	cloneof	romof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	sampleof
nbajam05	midtunit.cpp	nbajamte	nbajamte	no	no	no	yes	NBA Jam Tournament Edition SE (rev 5.02)	2023	Asure

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	400	254	54.706840	8000000	506	100	500	289	20	274	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge
l1_nba_jam_tournament_u3_sound_rom.u3	131072	d4551195	e8908fbe4339fb8c93f7e74113dfd25dda1667ea	adpcm:cpu	10000	good	no	l1_nba_jam_tournament_u3_sound_rom.u3
nbajam05.u12	524288	7be1622b	1b2bedc7c98bd01e5fbed9a97256d369f8ff67e7	adpcm:oki	0	good	no
nbajam05.u13	524288	f939bfcb	e3627afb539b56a355050f74efbb11b20becc768	adpcm:oki	80000	good	no
nbajam05.uj12	524288	08507007	b900ce98dc0725c4cd5f6a1eeefffe1f7c910d2b	maincpu	0	good	no
nbajam05.ug12	524288	d784608e	ed086f3d0a08392999f13cb576abecac06405484	maincpu	1	good	no
l1_nba_jam_tournament_game_rom_ug14.ug14	524288	04bb9f64	9e1a8c37e14cb6fe67f4aa3caa9022f356f1ca64	gfxrom	0	good	no	l1_nba_jam_tournament_game_rom_ug14.ug14
l1_nba_jam_tournament_game_rom_uj14.uj14	524288	b34b7af3	0abb74d2f414bc9da0380a81beb134f3a87c1a0a	gfxrom	1	good	no	l1_nba_jam_tournament_game_rom_uj14.uj14
l1_nba_jam_tournament_game_rom_ug19.ug19	524288	a8f22fbb	514208a9d6d0c8c2d7847cc02d4387eac90be659	gfxrom	2	good	no	l1_nba_jam_tournament_game_rom_ug19.ug19
l1_nba_jam_tournament_game_rom_uj19.uj19	524288	8130a8a2	f23f124024285d07d8cf822817b62e42c38b82db	gfxrom	3	good	no	l1_nba_jam_tournament_game_rom_uj19.uj19
nbajam03.ug16	524288	c8da980e	a907d579e7ce699f14787d45110b0723e8ac8577	gfxrom	200000	good	no
nbajam03.uj16	524288	205c5fb7	9e5ae65fb2d38643406149ffde081ee3845e1cd5	gfxrom	200001	good	no
nbajam03.ug20	524288	9cd4f985	97ebe1df160803a2c48cbad48e66a7fba9e7f7f0	gfxrom	200002	good	no
nbajam03.uj20	524288	7a47f364	55ef88680a5a26da3140fe49d1c102f472d41a89	gfxrom	200003	good	no
nbajam03.ug17	524288	1b7ddbe9	198309e4eabd33f23b28b99a589cf54f8f5690e8	gfxrom	400000	good	no
nbajam03.uj17	524288	cb08465f	856bd3475bed9652252ba14095e4bb56df7112ac	gfxrom	400001	good	no
nbajam03.ug22	524288	5427ca82	bf206c8fd47e4fa93abf344fcb4f56ab7cdc9a14	gfxrom	400002	good	no
nbajam03.uj22	524288	569b1ae5	c8f73b24b24bb50e9972a7ef4b94fdc3f3d4d70d	gfxrom	400003	good	no
nbajam05.ug18	524288	a182457b	e9be2ab87afce3b36c4d7a28185cbb6904d0458a	gfxrom	600000	good	no
nbajam05.uj18	524288	ed6b08a5	b80f151c64931370da228bec497aba41e40f12b7	gfxrom	600001	good	no
nbajam05.ug23	524288	7755db95	e490a6994ac08d9337474bbfd0feb63633460ff1	gfxrom	600002	good	no
nbajam05.uj23	524288	a659b604	89a498e75081f849197b2fd1da4d344cf997918d	gfxrom	600003	good	no

chip

type	tag	name	clock
cpu	maincpu	Texas Instruments TMS34010	50000000
cpu	adpcm:cpu	Motorola MC6809E	2000000
audio	speaker	Speaker
audio	adpcm	Williams ADPCM Sound Board
audio	adpcm:ym2151	YM2151 OPM	3579545
audio	adpcm:dac	AD7524 DAC
audio	adpcm:oki	OKI MSM6295 ADPCM	1000000

device_ref

name
tunitvid
tms34010
nvram
watchdog
palette
screen
speaker
wmsadpcm
mc6809e
ym2151
ad7524
okim6295

sound

channels
1

input

players	coins	service	tilt
4	4	yes	yes

control

type	player	ways	reverse	buttons
joy	1	8	no	3
joy	2	8	no	3
joy	3	8	no	3
joy	4	8	no	3

port, analog

port_tag	analog_masks
:DSW
:IN0
:IN1
:IN2

dipswitch

Test Switch

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Test Switch	DSW	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Powerup Test

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Powerup Test	DSW	2

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	2	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	4

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	8

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	32

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	32	yes

Dollar Bill Validator

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Dollar Bill Validator	DSW	64

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Installed	0	no
Not Present	64	yes

Players

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Players	DSW	128

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
2	0	no
4	128	yes

Coin Counters

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin Counters	DSW	768

value

name	value	default
1 Counter, 1 count/coin	768	yes
1 Counter, Totalizing	512	no
2 Counters, 1 count/coin	256	no

Country

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Country	DSW	3072

value

name	value	default
USA	3072	yes
French	2048	no
German	1024	no

Coinage

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage	DSW	28672

value

name	value	default
1	28672	yes
2	12288	no
3	20480	no
4	4096	no
ECA	24576	no
Free Play	0	no

Coinage Source

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage Source	DSW	32768

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Dipswitch	32768	no
CMOS	0	yes
