Demo - PGM - mame (0.245.25) machine

MAME: 0.245.25 - Released: 1601-01-01T00:00:00 - Lists: 2 - Software: 266 - rom: 266 - disk: 0

machine

• XML • JSON • AO

name	sourcefile	cloneof	romof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	sampleof
pgmdemo	pgm.cpp		pgm	no	no	no	yes	Demo - PGM	2005	Charles Doty

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	448	224	59.185606	10000000	640	0	448	264	0	224	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
pgm_p02s.u20	131072	78c15fa2	885a6558e022602cc6f482ac9667ba9f61e75092	maincpu	0	good	no	pgm_p02s.u20	v2
pgm_p01s.u20	131072	e42b166e	2a9df9ec746b14b74fae48b1a438da14973702ea	maincpu	0	good	no	pgm_p01s.u20	v1
pgmdemo.p1	2097152	d3f6ec45	4c171ffff6a04b362f71c42de7bc1d7b57da2c0e	maincpu	100000	good	no
pgm_t01s.rom	2097152	1a7123a0	cc567f577bfbf45427b54d6695b11b74f2578af3	tiles	0	good	no	pgm_t01s.rom
pgmdemo.t1	4194304	0596a59a	e48cb703e886a5b71ecc839136c642117aa529ef	tiles	180000	good	no
pgmdemo.a1	4194304	5d0e8fa1	95380456c8a6c9c48d4987951f689d5b9a7a397c	sprcol	0	good	no
pgmdemo.b1	4194304	15dd191f	a90f63138c9a9bf9215b17a14635518aed7da8a9	sprmask	0	good	no
pgm_m01s.rom	2097152	45ae7159	d3ed3ff3464557fd0df6b069b2e431528b0ebfa8	ics	0	good	no	pgm_m01s.rom
pgmdemo.m1	2097152	8d89877e	7d76d48d64d7ac5411d714a4bb83f37e3e5b8df6	ics	400000	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	20000000
cpu	soundcpu	Zilog Z80	8467200
audio	mono	Speaker
audio	ics	ICS2115 WaveFront Synthesizer	33868800

device_ref

name
m68000
timer
z80
nvram
v3021
screen
gfxdecode
palette
speaker
generic_latch_8
generic_latch_8
generic_latch_8
ics2115

biosset

name	description	default
v2	PGM Bios V2	no
v1	PGM Bios V1	no

sound

channels
1

input

players	coins	service	tilt
4	4	no	no

control

type	player	ways	reverse	buttons	minimum	maximum	sensitivity	keydelta	ways2	reqbuttons
joy	1	8	no	4
joy	2	8	no	4
joy	3	8	no	4
joy	4	8	no	4

port, analog

port_tag	analog_masks
:DSW
:P1P2
:P3P4
:Region
:Service

dipswitch

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	DSW	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Music

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Music	DSW	2

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	2	yes

Voice

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Voice	DSW	4

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	4	yes

Free

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Free	DSW	8

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Stop

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stop	DSW	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	32

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	64

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	128

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no
