Heroes of the 3 Kingdoms (set E3) - mame (0.245.25) machine

MAME: 0.245.25 - Released: 1601-01-01T00:00:00 - Lists: 2 - Software: 266 - rom: 266 - disk: 0

machine

• XML • JSON • AO

name	sourcefile	cloneof	romof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	sampleof
sk2e3	cps1mis.cpp	wof	wof	no	no	no	yes	Heroes of the 3 Kingdoms (set E3)	1992	All-In Co Ltd

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	384	224	59.637405	8000000	512	64	448	262	16	240	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
c23yxz.p1	524288	95429c83	e981624d018132e5625a66113b6ac4fc44e55cf7	maincpu	0	good	no
c23yxz.p2	524288	d8511929	4de9263778f327693f4d1e21b48e43806f673487	maincpu	1	good	no
c23yx.c1	2097152	a60be9f6	2298a4b6a2c83b76dc106a1efa19606b298d378a	gfx	0	good	no
c23yx.c2	2097152	6ad9d048	d47212d28d0a1ce349e4c59e5d0d99c541b3458e	gfx	2	good	no
c23abl.m1	65536	210c376f	0d937c86078d0a106f5636b7daf5fc0266c2c2ec	audiocpu	0	good	no
c23yx.m1	262144	c15ac0f2	8d9e5519d9820e4ac4f70555088c80e64d052c9d	oki	0	good	no
sk2h101.key	128	679300a3	f3e8197955f6b2b54493a449386b804b0d5e15ed	control	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	12000000
cpu	audiocpu	Zilog Z80	3579545
audio	mono	Speaker
audio	2151	YM2151 OPM	3579545
audio	oki	OKI MSM6295 ADPCM	1000000

device_ref

name
m68000
z80
screen
gfxdecode
palette
speaker
generic_latch_8
generic_latch_8
ym2151
okim6295
93c46_8

sound

channels
1

input

players	coins	service	tilt
3	3	yes	no

control

type	player	ways	reverse	buttons	minimum	maximum	sensitivity	keydelta	ways2	reqbuttons
joy	1	8	no	3
joy	2	8	no	3
joy	3	8	no	2

port, analog

port_tag	analog_masks
:DSWA
:DSWB
:DSWC
:EEPROMIN
:EEPROMOUT
:IN0
:IN1
:IN2

dipswitch

Play Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Play Mode	DSWA	3

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Normal	0	yes
Tournament	3	no

Coinage

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage	DSWB	3

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1 Coin/1 Credit	3	yes
1 Coin/2 Credits	2	no
1 Coin/3 Credits	1	no
1 Coin/4 Credits	0	no
