Tengai (World) - mame (0.245.25) machine

MAME: 0.245.25 - Released: 1601-01-01T00:00:00 - Lists: 2 - Software: 266 - rom: 266 - disk: 0

machine

• XML • JSON • AO

name	sourcefile	cloneof	romof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	sampleof
tengai	psikyo.cpp			no	no	no	yes	Tengai (World)	1996	Psikyo

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	320	224	59.922900								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
imperfect	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
5-u40.bin	524288	90088195	8ec48d581ecd14b3dad36edc65d5a273324cf3c1	maincpu	0	good	no
4-u41.bin	524288	0d53196c	454bb4695b13ce44ca5dac7c6d4142a8b9afa798	maincpu	2	good	no
1-u63.bin	131072	2025e387	334b0eb3b416d46ccaadff3eee6f1abba63285fb	audiocpu	0	good	no
4-u59.bin	4096			mcu	0	nodump	no
u20.bin	2097152	ed42ef73	74693fcc83a2654ddb18fd513d528033863d6116	gfx1	0	good	no
u22.bin	2097152	8d21caee	2a68af8b2be2158dcb152c434e91a75871478d41	gfx1	200000	good	no
u21.bin	2097152	efe34eed	7891495b443a5acc7b2f17fe694584f6cb0afacc	gfx1	400000	good	no
u34.bin	4194304	2a2e2eeb	f1d99353c0affc5c908985e6f2a5724e5223cccc	gfx2	0	good	no
u61.bin	2097152	a63633c5	89e75a40518926ebcc7d88dea86c01ba0bb496e5	ymf	0	good	no
u62.bin	2097152	3ad0c357	35f78cfa2eafa93ab96b24e336f569ee84af06b6	ymf	200000	good	no
u1.bin	262144	681d7d55	b0b28471440d747adbc4d22d1918f89f6ede1615	spritelut	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68EC020	16000000
cpu	audiocpu	Sharp LZ8420M	8000000
cpu	mcu	Microchip PIC16C57	4000000
audio	mono	Speaker
audio	ymf	YMF278B OPL4	33868800

device_ref

name
m68ec020
lz8420m
pic16c57
screen
gfxdecode
palette
buffered_spriteram32
speaker
ymf278b
generic_latch_8

sound

channels
1

feature

type	status	overall
timing	imperfect

input

players	coins	service	tilt
2	2	yes	yes

control

type	player	ways	reverse	buttons	minimum	maximum	sensitivity	keydelta	ways2	reqbuttons
joy	1	8	no	3
joy	2	8	no	3

port, analog

port_tag	analog_masks
:DSW
:P1_P2

configuration

Region

name	tag	mask
Region	DSW	15

setting

name	value	default
World	15	yes
USA & Canada	14	no
Korea	13	no
Hong Kong	11	no
Taiwan	7	no

dipswitch

Flip Screen

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flip Screen	DSW	65536

location

name	number	inverted
SW2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	65536	yes
On	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW	131072

location

name	number	inverted
SW2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	131072	no
On	0	yes

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW	786432

location

name	number	inverted
SW2	3	no
SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Easy	524288	no
Normal	786432	yes
Hard	262144	no
Hardest	0	no

Lives

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Lives	DSW	3145728

location

name	number	inverted
SW2	5	no
SW2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1	2097152	no
2	1048576	no
3	3145728	yes
4	0	no

Bonus Life

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bonus Life	DSW	4194304

location

name	number	inverted
SW2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
600K	4194304	yes
800K	0	no

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	DSW	8388608

location

name	number	inverted
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8388608	yes
On	0	no

Coin Slot

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin Slot	DSW	16777216

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Shared	16777216	yes
Individual [Free Play]	0	no

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSW	234881024

location

name	number	inverted
SW1	2	no
SW1	3	no
SW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
3 Coins/1 Credit	167772160	no
2 Coins/1 Credit	201326592	no
1 Coin/1 Credit	234881024	yes
1 Coin/2 Credits	134217728	no
1 Coin/3 Credits	100663296	no
1 Coin/4 Credits	67108864	no
1 Coin/5 Credits	33554432	no
1C 6C [Free Play]	0	no

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSW	1879048192

location

name	number	inverted
SW1	5	no
SW1	6	no
SW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
3 Coins/1 Credit	1342177280	no
2 Coins/1 Credit	1610612736	no
1 Coin/1 Credit	1879048192	yes
1 Coin/2 Credits	1073741824	no
1 Coin/3 Credits	805306368	no
1 Coin/4 Credits	536870912	no
1 Coin/5 Credits	268435456	no
1C 6C [Free Play]	0	no

2C Start, 1C Continue

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2C Start, 1C Continue	DSW	2147483648

location

name	number	inverted
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2147483648	yes
On [Free Play]	0	no
