Vortex (Set 1) - mame (0.245.25) machine

MAME: 0.245.25 - Released: 1601-01-01T00:00:00 - Lists: 2 - Software: 266 - rom: 266 - disk: 0

machine

• XML • JSON • AO

name	sourcefile	cloneof	romof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	sampleof
tvortex	tempest.cpp	tempest	tempest	no	no	no	yes	Vortex (Set 1)	1980	Atari

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	vector	270			60.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge
d1.bin	2048	3aff3417	3b7c31f01b7467757ec85e98a17038e5df5720bb	maincpu	9000	good	no
e1.bin	2048	11861be3	a35797c649e8286c844cee6dac86ac50f4fbd669	maincpu	9800	good	no
f1.bin	2048	1d251111	2912a21dc708231e28d6164e54e593a8300b9c4a	maincpu	a000	good	no
h1.bin	2048	937a9859	336b25291533d19294f1ced730bbf20971849adf	maincpu	a800	good	no
j1.bin	2048	79481246	c5362670fd29ef1432f8e626323da395d6e8a675	maincpu	b000	good	no
k1.bin	2048	390f872a	c5463ea2d2307e21c941b5b459e3652c12154609	maincpu	b800	good	no
lm1.bin	2048	515760dd	773f06c9a64e72f9d3d8a5c622bf3ec2b4ba678d	maincpu	c000	good	no
mn1.bin	2048	c6c41c68	9323c07fc80a947142dde008c53f5e8c0b0c572d	maincpu	c800	good	no
p1.bin	2048	3c2ff130	32ebabcb2cbd7aab5e29de2b873f02ed78776ae6	maincpu	d000	good	no
r1.bin	2048	67cafbb1	467515733d843398e6fe29661002536a1e6c8fc9	maincpu	d800	good	no
n3.bin	2048	29c6a1cb	290702a1c0942a68e288b37963e51eba02177a3f	vectorrom	0	good	no
r3.bin	2048	7fbe5e21	e5de6c3af82e64444b0ddcda559e9cb4fbf6c1da	vectorrom	800	good	no
136002-125.d7	256	5903af03	24bc0366f394ad0ec486919212e38be0f08d0239	avg:prom	0	good	no	136002-125.d7
136002-126.a1	32	8b04f921	317b3397482f13b2d1bc21f296d3b3f9a118787b	user2	0	good	no	136002-126.a1
136002-132.l1	256	2af82e87	3816835a9ccf99a76d246adf204989d9261bb065	user3	0	good	no	136002-132.l1
136002-131.k1	256	b31f6e24	ce5f8ca34d06a5cfa0076b47400e61e0130ffe74	user3	0	good	no	136002-131.k1
136002-130.j1	256	8119b847	c4fbaedd4ce1ad6a4128cbe902b297743edb606a	user3	1	good	no	136002-130.j1
136002-129.h1	256	09f5a4d5	d6f2ac07ca9ee385c08831098b0dcaf56808993b	user3	1	good	no	136002-129.h1
136002-128.f1	256	823b61ae	d99a839874b45f64e14dae92a036e47a53705d16	user3	2	good	no	136002-128.f1
136002-127.e1	256	276eadd5	55718cd8ec4bcf75076d5ef0ee1ed2551e19d9ba	user3	2	good	no	136002-127.e1

chip

type	tag	name	clock
cpu	maincpu	MOS Technology 6502	1512000
cpu	pokey1	Atari C012294 POKEY	1512000
cpu	pokey2	Atari C012294 POKEY	1512000
audio	mono	Speaker
audio	pokey1	Atari C012294 POKEY	1512000
audio	pokey2	Atari C012294 POKEY	1512000

device_ref

name
m6502
watchdog
er2055
vector_device
screen
avg_tempest
mathbox
speaker
pokey
pokey

sound

channels
1

input

players	coins	service	tilt
2	3	no	yes

control

type	player	ways	reverse	buttons	minimum	maximum	sensitivity	keydelta	ways2	reqbuttons
dial	1		no	2	0	240	100	20
dial	2		no	2	0	15	100	20

port, analog

port_tag	analog_masks
:BUTTONSP1
:BUTTONSP2
:DSW1
:DSW2
:IN0
:IN1_DSW0
:IN2
:KNOBP1	15
:KNOBP2	15

dipswitch

Coinage

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage	DSW1	3

location

name	number	inverted
N13	8	no
N13	7	no

value

name	value	default
2 Coins/1 Credit	1	no
1 Coin/1 Credit	0	yes
1 Coin/2 Credits	3	no
Free Play	2	no

Right Coin

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Right Coin	DSW1	12

location

name	number	inverted
N13	6	no
N13	5	no

value

name	value	default
*1	0	yes
*4	4	no
*5	8	no
*6	12	no

Left Coin

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Left Coin	DSW1	16

location

name	number	inverted
N13	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
*1	0	yes
*2	16	no

Bonus Coins

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bonus Coins	DSW1	224

location

name	number	inverted
N13	3	no
N13	2	no
N13	1	no

value

name	value	default
None	0	yes
1 each 5	128	no
1 each 4 (+Demo)	64	no
1 each 3	160	no
2 each 4 (+Demo)	96	no
1 each 2	32	no
Freeze Mode	192	no
Freeze Mode	224	no

Minimum

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Minimum	DSW2	1

location

name	number	inverted
L12	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1 Credit	0	yes
2 Credit	1	no

Language

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Language	DSW2	6

location

name	number	inverted
L12	7	no
L12	6	no

value

name	value	default
English	0	yes
French	2	no
German	4	no
Spanish	6	no

Bonus Life

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bonus Life	DSW2	56

location

name	number	inverted
L12	5	no
L12	4	no
L12	3	no

value

name	value	default
10000	8	no
20000	0	yes
30000	16	no
40000	24	no
50000	32	no
60000	40	no
70000	48	no
None	56	no

Lives

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Lives	DSW2	192

location

name	number	inverted
L12	2	no
L12	1	no

value

name	value	default
2	192	no
3	0	yes
4	64	no
5	128	no

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	IN0	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Cabinet

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cabinet	IN1_DSW0	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Upright	16	yes
Cocktail	0	no

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	IN2	3

location

name	number	inverted
DE2	4	no
DE2	3	no

value

name	value	default
Easy	2	no
Medium1	3	yes
Medium2	0	no
Hard	1	no

Rating

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Rating	IN2	4

location

name	number	inverted
DE2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1, 3, 5, 7, 9	4	yes
tied to high score	0	no
