name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
500gp	namco/namcos23.cpp		no	no	no	yes	500 GP (US, 5GP3 Ver. C)	1998	Namco

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	640	480	59.904060	25600000	814	0	640	525	0	480	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
5gp3verc.2	2097152	e2d43468	5e861dd223c7fa177febed9803ac353cba18e19d	user1	0	good	no
5gp3verc.1	2097152	f6efc94a	785eee2bec5080d4e8ef836f28d446328c942b0e	user1	1	good	no
5gp3verc.3	524288	b323abdf	8962e39b48a7074a2d492afb5db3f5f3e5ae2389	subcpu	0	good	no
fcaf10.bin	262144			iocpu2	0	nodump	no
fcap10.ic2	16400			iocpu3	0	nodump	no
5gp1mtah.2j	8388608	246e4b7a	75743294b8f48bffb84f062febfbc02230d49ce9	data	0	good	no
5gp1mtal.2h	8388608	1bb00c7b	922be45d57330c31853b2dc1642c589952b09188	data	1	good	no
5gp1mtbh.2m	8388608	352360e8	d621dfac3385059c52d215f6623901589a8658a3	data	1000000	good	no
5gp1mtbl.2f	8388608	66640606	c69a0219748241c49315d7464f8156f8068e9cf5	data	1000001	good	no
5gp1cgll.4m	8388608	0cc5bf35	b75510a94fa6b6d2ed43566e6e84c7ae62f68194	textile	0	good	no
5gp1cglm.4k	8388608	31557d48	b85c3db20b101ba6bdd77487af67c3324bea29d5	textile	800000	good	no
5gp1cgum.4j	8388608	0265b701	497a4c33311d3bb315100a78400cf2fa726f1483	textile	1000000	good	no
5gp1cguu.4f	8388608	c411163b	ae644d62357b8b806b160774043e41908fba5d05	textile	1800000	good	no
5gp1ccrl.7f	4194304	e7c77e1f	0231ddbe2afb880099dfe2657c41236c74c730bb	textilemapl	0	good	no
5gp1ccrh.7e	2097152	b2eba764	5e09d1171f0afdeb9ed7337df1dbc924f23d3a0b	textilemaph	0	good	no
5gp1pt0h.7a	4194304	5746a8cd	e70fc596ab9360f474f716c73d76cb9851370c76	pointrom	0	good	no
5gp1pt0l.7c	4194304	a0ece0a1	b7aab2d78e1525f865214c7de387ccd585de5d34	pointrom	2	good	no
5gp1pt1h.5a	4194304	b1feb5df	45db259215511ac3e472895956f70204d4575482	pointrom	800000	good	no
5gp1pt1l.5c	4194304	80b25ad2	e9a03fe5bb4ce925f7218ab426ed2a1ca1a26a62	pointrom	800002	good	no
5gp1pt2h.4a	4194304	9a693771	c988e04cd91c3b7e75b91376fd73be4a7da543e7	pointrom	1000000	good	no
5gp1pt2l.4c	4194304	9289dbeb	ec546ad3b1c90609591e599c760c70049ba3b581	pointrom	1000002	good	no
5gp1pt3h.3a	4194304	26eaa400	0157b76fffe81b40eb970e84c98398807ced92c4	pointrom	1800000	good	no
5gp1pt3l.3c	4194304	480b120d	6c703550faa412095d9633cf508050614e15fbae	pointrom	1800002	good	no
5gp1wavel.2c	8388608	aa634cc2	e96f5c682039bc6ef22bf90e98f4da78486bd2b1	c352	0	good	no
5gp1waveh.2a	8388608	1e3523e8	cb3d0d389fcbfb728fad29cfc36ef654d28d553a	c352	800000	good	no

chip

type	tag	name	clock
cpu	maincpu	MIPS IDT R4650 (big)	169344000
cpu	subcpu	Hitachi H8/3002	16934400
cpu	jvs:namco_fca10:iocpu	Hitachi H8/3334	14745600
cpu	jvs:namco_fca10:iocpu2	Fujitsu MB90F574	4915200
audio	lspeaker	Speaker
audio	rspeaker	Speaker
audio	c352	Namco C352	25401600

device_ref

name
r4650be
h83002
h8h_intc
h8_adc_3337
h8h_dma
h8h_dma_channel
h8h_dma_channel
h8_digital_port
h8_digital_port
h8_digital_port
h8_digital_port
h8_digital_port
h8_digital_port
h8_digital_port
h8_timer16
h8h_timer16_channel
h8h_timer16_channel
h8h_timer16_channel
h8h_timer16_channel
h8h_timer16_channel
h8_sci
h8_sci
h8_watchdog
namco_settings
rtc4543
nvram
screen
palette
gfxdecode
speaker
speaker
c352
jvs_port
namco_fca10
h83334
h8_intc
h8_adc_3337
h8_digital_port
h8_digital_port
h8_digital_port
h8_digital_port
h8_digital_port
h8_digital_port
h8_digital_port
h8_digital_port
h8_digital_port
h8_timer8_channel
h8_timer8_channel
h8_timer16
h8_timer16_channel
h8_sci
h8_sci
h8_watchdog
jvs_port
mb90f574
f2mc16_port
f2mc16_port
f2mc16_port
f2mc16_port
f2mc16_port
f2mc16_port
f2mc16_port
f2mc16_port
f2mc16_port
f2mc16_port
f2mc16_port
f2mc16_port
f2mc16_port
f2mc16_intc
f2mc16_clock_generator
f2mc16_adc
f2mc16_uart
f2mc16_uart
f2mc16_ppg

sound

channels
2

feature

type	status	overall
graphics	imperfect
lan	unemulated

input

players	coins	service	tilt
2	1	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta
joy	1	4	vertical2	no
stick	1			no	256	65535	100	2560
pedal	1			no	256	65535	100	2560
joy	2	9	vertical2	no

port, analog

port_tag	analog_masks
:DSW
:JVS_ANALOG_INPUT1	65535
:JVS_ANALOG_INPUT2	65535
:JVS_ANALOG_INPUT3	65535
:JVS_ANALOG_INPUT4
:JVS_ANALOG_INPUT5
:JVS_ANALOG_INPUT6
:JVS_ANALOG_INPUT7
:JVS_ANALOG_INPUT8
:JVS_COIN1
:JVS_PLAYER1
:JVS_ROTARY_INPUT1
:JVS_SCREEN_POSITION_INPUT_X1
:JVS_SCREEN_POSITION_INPUT_Y1
:JVS_SYSTEM
:P1
:P2
:jvs:namco_fca10:DSW

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
jvs	namco_xmiu1	namco_xmiu1	no
jvs	namco_tssio	namco_tssio	no
jvs	namco_amc	namco_amc	no
jvs	namco_asca1	namco_asca1	no
jvs	namco_csz1	namco_csz1	no
jvs	namco_asca3	namco_asca3	no
jvs	namco_cyberleada	namco_cyberleada	no
jvs	namco_emio102	namco_emio102	no
jvs	namco_asca5	namco_asca5	no
jvs	namco_empri101	namco_empri101	no
jvs	namco_asca3a	namco_asca3a	no
jvs	namco_fca10	namco_fca10	yes
jvs	namco_fca11	namco_fca11	no
jvs	namco_cyberlead	namco_cyberlead	no
jvs	namco_fcb	namco_fcb	no
jvs:namco_fca10:jvs	namco_xmiu1	namco_xmiu1	no
jvs:namco_fca10:jvs	namco_tssio	namco_tssio	no
jvs:namco_fca10:jvs	namco_amc	namco_amc	no
jvs:namco_fca10:jvs	namco_asca1	namco_asca1	no
jvs:namco_fca10:jvs	namco_csz1	namco_csz1	no
jvs:namco_fca10:jvs	namco_asca3	namco_asca3	no
jvs:namco_fca10:jvs	namco_cyberleada	namco_cyberleada	no
jvs:namco_fca10:jvs	namco_emio102	namco_emio102	no
jvs:namco_fca10:jvs	namco_asca5	namco_asca5	no
jvs:namco_fca10:jvs	namco_empri101	namco_empri101	no
jvs:namco_fca10:jvs	namco_asca3a	namco_asca3a	no
jvs:namco_fca10:jvs	namco_fca10	namco_fca10	no
jvs:namco_fca10:jvs	namco_fca11	namco_fca11	no
jvs:namco_fca10:jvs	namco_cyberlead	namco_cyberlead	no
jvs:namco_fca10:jvs	namco_fcb	namco_fcb	no

configuration

Cabinet

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cabinet	JVS_PLAYER1	256

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Standard	256	yes
Deluxe	0	no

dipswitch

Service Mode DIP

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode DIP	DSW	1

location

name	number	inverted
DIP	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Skip POST

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Skip POST	DSW	2

location

name	number	inverted
DIP	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Freeze?

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Freeze?	DSW	4

location

name	number	inverted
DIP	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	8

location

name	number	inverted
DIP	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	16

location

name	number	inverted
DIP	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	32

location

name	number	inverted
DIP	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	64

location

name	number	inverted
DIP	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	128

location

name	number	inverted
DIP	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	JVS_SYSTEM	128

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	128	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	jvs:namco_fca10:DSW	1

location

name	number	inverted
DIP SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	jvs:namco_fca10:DSW	2

location

name	number	inverted
DIP SW2	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	jvs:namco_fca10:DSW	4

location

name	number	inverted
DIP SW2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	jvs:namco_fca10:DSW	8

location

name	number	inverted
DIP SW2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no
