MC68705R3 Programmer - mame (0286) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
705r3prg	motorola/m68705prg.cpp		no	no	no	yes	MC68705R3 Programmer	1984	Motorola	705p5prg	705p5prg

snap

MC68705R3 Programmer png snap

MC68705R3 Programmer jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
705r3prg	11822	29/12/2025 11:31:14	475	500	96	96	0	Format24bppRgb	305:MAME 0.182 (Jan 25 2017)	c6dd2d54aab6541793fee5c789fb2ffe281b4b8b

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	yes	no

chip

type	tag	name	clock
cpu	mcu	Motorola MC68705R3	1000000

device_ref

tag	name
:eprom_image	generic_socket
:mcu_image	generic_socket
:mcu	m68705r3

sound

channels
0

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
romimage	eprom_image	eprom			romimage1	rom1
romimage	mcu_image	mcu			romimage2	rom2

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
romimage	eprom_image	eprom			bin, rom
romimage	mcu_image	mcu			bin, rom

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
only_buttons		2		no

port, analog

port_tag	analog_masks
:SW

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
eprom_image
mcu_image
