Amiga 1000 (PAL) - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
a1000	amiga/amiga.cpp		no	no	no	yes	Amiga 1000 (PAL)	1985	Commodore

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	724	567	50.000282	28375160	908	184	908	625	58	625	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
252179-01.u5n	32768	76bd46ec	2155b4887f064c5e01e0a2ebb4a0cc2a3e88d9e8	bootrom	0	good	no
252180-01.u5p	32768	dd516b6d	2c307d02f10ad332a479b50767fd0463efc2844b	bootrom	1	good	no
252128-01.u4t	260	28209ff2	20c03b6b8e7254231f4b3014dc2c4d9274d469d2	dpalen	0	good	no
252128-02.u6p	260	b928efd2	430794a544d9160e1b786e97e0dec5f25502a00a	dpalcas	0	good	no
252128-03.u4s	260	87747964	00d72ec707c582363525fde56176973c7327b1d7	daugen	0	good	no
252128-04.u6n	260	f903adb4	4c8fb696fd1aaf9bb8c9efddeac24bb36f119c5f	daugcas	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	7093790
cpu	cia_0	MOS 8520 CIA	709379
cpu	cia_1	MOS 8520 CIA	709379
cpu	kbd:a1000_us:mcu	MOS Technology 6500/1	3000000
audio	lspeaker	Speaker
audio	rspeaker	Speaker
audio	paula	MOS 8364 "Paula"	3546895
audio	fdc:0:35dd:flopsndout	Speaker
audio	fdc:0:35dd:floppysound	Floppy sound	44100

softwarelist

tag	name	status
wb_list	amiga_workbench	original
hardware_list	amiga_hardware	original
apps_list	amiga_apps	original
flop_list	amiga_flop	original
ocs_list	amigaocs_flop	original
demos_list	amiga_demos	original
amigacd_list	amiga_cd	original
photocd_list	photo_cd	compatible

device_ref

name
m68000
screen
palette
mos8520
mos8520
speaker
speaker
paula_8364
paula_fdc
floppy_connector
floppy_35_dd
speaker
flopsnd
floppy_connector
floppy_connector
floppy_connector
agnus_copper
rs232
centronics
centronics_printer
printer_image
input_buffer
output_latch
software_list
software_list
software_list
software_list
software_list
software_list
software_list
software_list
amiga_kbd
a1000kbd_us
m6500_1
a1000kbrst
address_map_bank
address_map_bank
address_map_bank

sound

channels
3

feature

type	status	overall
graphics	imperfect

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
floppydisk	fdc:0:35dd	floppy_3_5			floppydisk	flop
printout	centronics:printer:printer				printout	prin

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
floppydisk	fdc:0:35dd	floppy_3_5			mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, adf, ipf
printout	centronics:printer:printer				prn

input

players	coins	service	tilt
2		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta
joy	1	3	8	no
mouse	1			no	0	255	100	5
keyboard	1	89		no
joy	2	3	8	no
mouse	2			no	0	255	100	5

port, analog

port_tag	analog_masks
:cia_0_port_a
:input
:joy_0_dat
:joy_1_dat
:kbd:a1000_us:COLS
:kbd:a1000_us:META
:kbd:a1000_us:ROW0
:kbd:a1000_us:ROW1
:kbd:a1000_us:ROW10
:kbd:a1000_us:ROW11
:kbd:a1000_us:ROW12
:kbd:a1000_us:ROW13
:kbd:a1000_us:ROW14
:kbd:a1000_us:ROW2
:kbd:a1000_us:ROW3
:kbd:a1000_us:ROW4
:kbd:a1000_us:ROW5
:kbd:a1000_us:ROW6
:kbd:a1000_us:ROW7
:kbd:a1000_us:ROW8
:kbd:a1000_us:ROW9
:p1_joy
:p1_mouse_x	255
:p1_mouse_y	255
:p2_joy
:p2_mouse_x	255
:p2_mouse_y	255
:potgo

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
fdc:0	35dd	floppy_35_dd	yes
fdc:1	35dd	floppy_35_dd	no
fdc:2	35dd	floppy_35_dd	no
fdc:3	35dd	floppy_35_dd	no
rs232	terminal	serial_terminal	no
rs232	sunkbd	sunkbd_adaptor	no
rs232	dec_loopback	dec_rs232_loopback	no
rs232	ie15	ie15_terminal	no
rs232	null_modem	null_modem	no
rs232	keyboard	serial_keyboard	no
rs232	patch	rs232_patch_box	no
rs232	swtpc8212	swtpc8212_terminal	no
rs232	printer	serial_printer	no
rs232	scorpion	scorpion_ic	no
rs232	loopback	rs232_loopback	no
rs232	mockingboard	mockingboardd	no
rs232	msystems_mouse	rs232_mouse_hle_msystems	no
rs232	nss_tvi	nss_tvinterface	no
rs232	rs232_sync_io	rs232_sync_io	no
rs232	pty	pseudo_terminal	no
rs232	rs_printer	rs_serial_printer	no
centronics	nlq401	nlq401	no
centronics	smartboard	centronics_smartboard	no
centronics	chessmec	centronics_chessmec	no
centronics	samdac	centronics_samdac	no
centronics	covox_stereo	covox_stereo	no
centronics	adaptator	adaptator_multitap	no
centronics	digiblst	cpcdigiblst	no
centronics	lx800	lx800	no
centronics	jx80	epson_jx80	no
centronics	ap2000	ap2000	no
centronics	ex800	ex800	no
centronics	fx80	epson_fx80	no
centronics	rx80	epson_rx80	no
centronics	covox	covox	no
centronics	pl80	comx_pl80	no
centronics	lx810l	lx810l	no
centronics	p72	p72	no
centronics	printer	centronics_printer	yes
kbd	a2000_no	a2000kbd_no	no
kbd	a2000_se	a2000kbd_se	no
kbd	a2000_de	a2000kbd_de	no
kbd	a2000_us	a2000kbd_us	no
kbd	a1000_us	a1000kbd_us	yes
kbd	a2000_gb	a2000kbd_gb	no
kbd	a2000_g80_de	a2000kbd_g80_de	no
kbd	a1000_de	a1000kbd_de	no
kbd	a1000_dk	a1000kbd_dk	no
kbd	a1000_gb	a1000kbd_gb	no
kbd	a1000_fr	a1000kbd_fr	no
kbd	a2000_dk	a2000kbd_dk	no
kbd	a1000_it	a1000kbd_it	no
kbd	a2000_ch	a2000kbd_ch	no
kbd	a1000_se	a1000kbd_se	no
kbd	a2000_fr	a2000kbd_fr	no
kbd	a1200_us	a1200kbd_rb	no
kbd	a2000_g80_se	a2000kbd_g80_se	no
kbd	a2000_es	a2000kbd_es	no
kbd	a2000_g80_dk	a2000kbd_g80_dk	no
kbd	a2000_it	a2000kbd_it	no
kbd	a2000_g80_us	a2000kbd_g80_us	no
kbd	a2000_g80_gb	a2000kbd_g80_gb	no

configuration

Game Port 0 Device

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Game Port 0 Device	input	16

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Mouse	0	yes
Joystick	16	no

Game Port 1 Device

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Game Port 1 Device	input	32

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Mouse	0	no
Joystick	32	yes
