A.B. Cop (World) (FD1094 317-0169b) - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
abcop	sega/segaxbd.cpp		no	no	no	yes	A.B. Cop (World) (FD1094 317-0169b)	1990	Sega

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
mainpcb:screen	raster	0	320	224	59.637405	6250000	400	0	320	262	0	224	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
epr-13568b.ic58	131072	f88db35b	7d85c1194a2aa08427333d2ffc2a8d4f7e1beff0	mainpcb:maincpu	0	good	no
epr-13556b.ic63	131072	337bf32e	dafb9d9b3baf79ca76355278e8a14294f186790a	mainpcb:maincpu	1	good	no
epr-13559.ic57	131072	4588bf19	6a8b3d4450ac0bc41b46e6a4e1b44d82112fcd64	mainpcb:maincpu	40000	good	no
epr-13558.ic62	131072	11259ed4	e7de174a0bdb1d1111e5e419f1d501ab5be1d32d	mainpcb:maincpu	40001	good	no
317-0169b.key	8192	058da36e	ab3f68a90725063c68fc5d0f8dbece1f8940dc7d	mainpcb:maincpu:key	0	good	no
epr-13566.ic20	131072	22e52f32	c67a4ccb88becc58dddcbfea0a1ac2017f7b2929	mainpcb:subcpu	0	good	no
epr-13565.ic29	131072	a21784bd	b40ba0ef65bbfe514625253f6aeec14bf4bcf08c	mainpcb:subcpu	1	good	no
opr-13553.ic154	65536	8c418837	e325db39fae768865e20d2cd1ee2b91a9b0165f5	mainpcb:gfx1	0	good	no
opr-13554.ic153	65536	4e3df9f0	8b481c2cd25c58612ac8ac3ffb7eeae9ca247d2e	mainpcb:gfx1	10000	good	no
opr-13555.ic152	65536	6c4a1d42	6c37b045b21173f1e2f7bd19d01c00979b8107fb	mainpcb:gfx1	20000	good	no
opr-13552.ic90	131072	cc2cf706	ad39c22e652ebcd90ffb5e17ae35985645f93c71	mainpcb:sprites	0	good	no
opr-13551.ic94	131072	d6f276c1	9ec68157ea460e09ef4b69aa8ea17687dc47ea59	mainpcb:sprites	1	good	no
opr-13550.ic98	131072	f16518dd	a5f1785cd28f03069cb238ac92c6afb5a26cbd37	mainpcb:sprites	2	good	no
opr-13549.ic102	131072	cba407a7	e7684d3b40baa6d832b887fd85ad67fbad8aa7de	mainpcb:sprites	3	good	no
opr-13548.ic91	131072	080fd805	e729565815a3a37462cfee460b7392d2f08e96e5	mainpcb:sprites	80000	good	no
opr-13547.ic95	131072	42d4dd68	6ae1f3585ebb20fd2908456d6fa41a893261277e	mainpcb:sprites	80001	good	no
opr-13546.ic99	131072	ca6fbf3d	49c3516d87f1546fa7efe785fc5c064d90b1cb8e	mainpcb:sprites	80002	good	no
opr-13545.ic103	131072	c9e58dd2	ace2e1630d8df2454183ffdbe26d8cb6d199e940	mainpcb:sprites	80003	good	no
opr-13544.ic92	131072	9c1436d9	5156e1b5c7461f6dc0d449b86b6b72153b290a4c	mainpcb:sprites	100000	good	no
opr-13543.ic96	131072	2c1c8f0e	19c9fd4272a3db18381f435ed6cd01f994c655e7	mainpcb:sprites	100001	good	no
opr-13542.ic100	131072	01fd52b8	b4ab13c7b2b2ffcfdab37d8e4855d5ef8823f1cc	mainpcb:sprites	100002	good	no
opr-13541.ic104	131072	a45c547b	d93aaa850d14a7699a1b0411e823088a9bce7553	mainpcb:sprites	100003	good	no
opr-13540.ic93	131072	84b42ab0	d24ba7fe23463fc5813ef26e0395951559d6d162	mainpcb:sprites	180000	good	no
opr-13539.ic97	131072	cd6e524f	e6df2552a84b2da95301486379c78679b0297634	mainpcb:sprites	180001	good	no
opr-13538.ic101	131072	bf9a4586	6013dee83375d72d262c8c04c2e668afea2e216c	mainpcb:sprites	180002	good	no
opr-13537.ic105	131072	fa14ed3e	d684496ade2517696a56c1423dd4686d283c133f	mainpcb:sprites	180003	good	no
opr-13564.ic40	65536	e70ba138	85eb6618f408642227056d278f10dec8dcc5a80d	mainpcb:segaic16road	0	good	no
epr-13560.ic17	65536	83050925	118710e5789c7999bb7326df4d7bd207cbffdfd4	mainpcb:soundcpu	0	good	no
opr-13563.ic11	131072	4083e74f	e48c7ce0aa3406af0bbf79c169a8157693c97041	mainpcb:pcm	0	good	no
opr-13562.ic12	131072	3cc3968f	d25647f6a3fa939ba30e03e7334362ef0749b23a	mainpcb:pcm	20000	good	no
opr-13561.ic13	131072	80a7c02a	7e8c1b9ba270d8657dbe90ed8be2e4b6463e5928	mainpcb:pcm	40000	good	no

chip

type	tag	name	clock
cpu	mainpcb:maincpu	Hitachi FD1094 Encrypted CPU	12500000
cpu	mainpcb:subcpu	Motorola MC68000	12500000
cpu	mainpcb:soundcpu	Zilog Z80	4000000
audio	mainpcb:lspeaker	Speaker
audio	mainpcb:rspeaker	Speaker
audio	mainpcb:ymsnd	YM2151 OPM	4000000
audio	mainpcb:pcm	Sega PCM	4000000

device_ref

name
segaxbd_pcb_fd1094
fd1094
m68000
z80
nvram
nvram
mb3773
sega_315_5248
sega_315_5248
sega_315_5249
sega_315_5249
sega_315_5250
sega_315_5250
cxd1095
cxd1095
adc0804
gfxdecode
palette
screen
sega_xboard_sprite
segaic16_video
segaic16_road
speaker
speaker
ym2151
segapcm

sound

channels
2

input

players	coins	service	tilt
1	2	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
paddle		1		yes	32	224	100	4
pedal				no	0	255	100	20

port, analog

port_tag	analog_masks
:mainpcb:ADC0	255
:mainpcb:ADC1	255
:mainpcb:IO0PORTA
:mainpcb:IO0PORTB
:mainpcb:IO1PORTA
:mainpcb:IO1PORTB
:mainpcb:IO1PORTC
:mainpcb:IO1PORTD

dipswitch

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	mainpcb:IO1PORTC	15

location

name	number	inverted
SWA	1	no
SWA	2	no
SWA	3	no
SWA	4	no

value

name	value	default
4 Coins/1 Credit	7	no
3 Coins/1 Credit	8	no
2 Coins/1 Credit	9	no
2 Coins/1 Credit, 5/3, 6/4	5	no
2 Coins/1 Credit, 4/3	4	no
1 Coin/1 Credit	15	yes
1 Coin/1 Credit, 5/6	3	no
1 Coin/1 Credit, 4/5	2	no
1 Coin/1 Credit, 2/3	1	no
2 Coins/3 Credits	6	no
1 Coin/2 Credits	14	no
1 Coin/3 Credits	13	no
1 Coin/4 Credits	12	no
1 Coin/5 Credits	11	no
1 Coin/6 Credits	10	no
Free Play (if Coin B too) or 1/1	0	no

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	mainpcb:IO1PORTC	240

location

name	number	inverted
SWA	5	no
SWA	6	no
SWA	7	no
SWA	8	no

value

name	value	default
4 Coins/1 Credit	112	no
3 Coins/1 Credit	128	no
2 Coins/1 Credit	144	no
2 Coins/1 Credit, 5/3, 6/4	80	no
2 Coins/1 Credit, 4/3	64	no
1 Coin/1 Credit	240	yes
1 Coin/1 Credit, 5/6	48	no
1 Coin/1 Credit, 4/5	32	no
1 Coin/1 Credit, 2/3	16	no
2 Coins/3 Credits	96	no
1 Coin/2 Credits	224	no
1 Coin/3 Credits	208	no
1 Coin/4 Credits	192	no
1 Coin/5 Credits	176	no
1 Coin/6 Credits	160	no
Free Play (if Coin A too) or 1/1	0	no

Credits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Credits	mainpcb:IO1PORTD	1

location

name	number	inverted
SWB	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1 to Start, 1 to Continue	1	yes
2 to Start, 1 to Continue	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	mainpcb:IO1PORTD	2

location

name	number	inverted
SWB	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	no
On	0	yes

Allow Continue

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Allow Continue	mainpcb:IO1PORTD	4

location

name	number	inverted
SWB	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	4	no
Yes	0	yes

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	mainpcb:IO1PORTD	8

location

name	number	inverted
SWB	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Time

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Time	mainpcb:IO1PORTD	48

location

name	number	inverted
SWB	5	no
SWB	6	no

value

name	value	default
Easy	16	no
Normal	48	yes
Hard	32	no
Hardest	0	no

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	mainpcb:IO1PORTD	192

location

name	number	inverted
SWB	7	no
SWB	8	no

value

name	value	default
Easy	64	no
Normal	192	yes
Hard	128	no
Hardest	0	no
