Franklin ACE 500 - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
ace500	apple/apple2e.cpp		no	no	no	yes	Franklin ACE 500	1986	Franklin Computer	apple2c	apple2c

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	560	192	60.000000	14305200	910	0	560	262	0	192	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge
franklin_ace2000_videorom.bin	8192	545bdeea	26ebc4b0d3080311f550090bc1b29807cb22d083	gfx1	1000	good	no
franklin500-rom.bin	32768	376c9104	7f82706adc0bfb5f60c207c81271eb0ba8510a11	maincpu	4000	good	no
342-0132-c.e12	2048	e47045f4	12a2e718f5f4acd69b6c33a45a4a940b1440a481	keyboard	0	good	no	342-0132-c.e12

chip

type	tag	name	clock
cpu	maincpu	WDC W65C02	1021800
audio	mono	Speaker
audio	speaker	Filtered DAC
audio	sl6:0:525:flopsndout	Speaker
audio	sl6:0:525:floppysound	Floppy sound	44100
audio	sl6:1:525:flopsndout	Speaker
audio	sl6:1:525:floppysound	Floppy sound	44100

softwarelist

tag	name	status	filter
flop_a2_clean	apple2_flop_clcracked	original
flop_a2_orig	apple2_flop_orig	compatible	A2C
flop_a2_misc	apple2_flop_misc	compatible

device_ref

name
w65c02
timer
timer
a2video_comp
apple2com
screen
speaker
speaker_sound_device
ds1216e
ram
ay3600
timer
a2bus
a2eauxslot
a2gameio
software_list
software_list
software_list
centronics
centronics_printer
printer_image
output_latch
mos6551
clock
rs232
a2iwmint
iwm
floppy_connector
floppy_525_sd
speaker
flopsnd
floppy_connector
floppy_525_sd
speaker
flopsnd
a2ef384

sound

channels
3

ramoption

name	default
128K	yes

device, instance

type	tag	interface	name	briefname
printout	parallel:printer:printer		printout	prin
floppydisk	sl6:0:525	floppy_5_25	floppydisk1	flop1
floppydisk	sl6:1:525	floppy_5_25	floppydisk2	flop2

device, extension

type	tag	interface	extension_names
printout	parallel:printer:printer		prn
floppydisk	sl6:0:525	floppy_5_25	mfi, dfi, dsk, do, po, rti, edd, woz, nib
floppydisk	sl6:1:525	floppy_5_25	mfi, dfi, dsk, do, po, rti, edd, woz, nib

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
mouse		1		no	0	255	40
keyboard		75		no

port, analog

port_tag	analog_masks
:X0
:X1
:X2
:X3
:X4
:X5
:X6
:X7
:X8
:a2_config
:a2video:a2_video_config
:franklin_fkeys
:kbd_lang_select
:keyb_special
:mse_button
:mse_x	255
:mse_y	255

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
gameio	compeyes	a2ceyes	no
gameio	gizmo	a2gizmo	no
gameio	paddles	a2pdls	no
gameio	joy	a2joy	no
parallel	nlq401	nlq401	no
parallel	smartboard	centronics_smartboard	no
parallel	chessmec	centronics_chessmec	no
parallel	samdac	centronics_samdac	no
parallel	covox_stereo	covox_stereo	no
parallel	adaptator	adaptator_multitap	no
parallel	digiblst	cpcdigiblst	no
parallel	lx800	lx800	no
parallel	jx80	epson_jx80	no
parallel	ap2000	ap2000	no
parallel	ex800	ex800	no
parallel	fx80	epson_fx80	no
parallel	rx80	epson_rx80	no
parallel	covox	covox	no
parallel	pl80	comx_pl80	no
parallel	lx810l	lx810l	no
parallel	p72	p72	no
parallel	printer	centronics_printer	yes
modem	terminal	serial_terminal	no
modem	sunkbd	sunkbd_adaptor	no
modem	dec_loopback	dec_rs232_loopback	no
modem	ie15	ie15_terminal	no
modem	null_modem	null_modem	no
modem	keyboard	serial_keyboard	no
modem	patch	rs232_patch_box	no
modem	swtpc8212	swtpc8212_terminal	no
modem	printer	serial_printer	no
modem	scorpion	scorpion_ic	no
modem	loopback	rs232_loopback	no
modem	mockingboard	mockingboardd	no
modem	msystems_mouse	rs232_mouse_hle_msystems	no
modem	nss_tvi	nss_tvinterface	no
modem	rs232_sync_io	rs232_sync_io	no
modem	pty	pseudo_terminal	no
modem	rs_printer	rs_serial_printer	no
sl6:0	525	floppy_525_sd	yes
sl6:1	525	floppy_525_sd	yes

configuration

40/80 Columns

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
40/80 Columns	a2_config	64

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
80 columns	0	no
40 columns	64	yes

Auto Line Feed for printer

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Auto Line Feed for printer	a2_config	128

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	128	no
Off	0	yes

Monitor type

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Monitor type	a2video:a2_video_config	7

setting

name	value	default
Color	0	yes
B&W	4	no
Green	5	no
Amber	6	no
B&W for NTSC shader	7	no

Color algorithm

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Color algorithm	a2video:a2_video_config	112

setting

name	value	default
Pixel-run (B&W bias)	0	yes
Pixel-run (color bias)	16	no
Box filter	32	no

Lores artifacts

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Lores artifacts	a2video:a2_video_config	128

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	128	no

Text color

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Text color	a2video:a2_video_config	768

setting

name	value	default
Off	0	yes
40-column only	256	no
On	768	no

Character Set

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Character Set	kbd_lang_select	255

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Mouse	0	yes
Std	2	no
