name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
aceattac	sega/segas16b.cpp		no	no	no	yes	Ace Attacker (FD1094 317-0059)	1988	Sega

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	270	320	224	60.054389	6293700	400	0	320	262	0	224	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
epr-11491.a4	65536	f3c19c36	e45ca6d1d943d6cc140867055033884c738e2ac2	maincpu	0	good	no
epr-11489.a1	65536	bbe623c5	6d047699c7b6df7ebb7a3c9bee032e2536eed84c	maincpu	1	good	no
epr-11492.a5	65536	d8bd3139	54915d4e8a616e0e54135ca34daf4357b8bfa068	maincpu	20000	good	no
epr-11490.a2	65536	38cb3a41	1d74cc69907cdff2d85e965b80bf3f551465257e	maincpu	20001	good	no
317-0059.key	8192	4512e2fa	c703fb482f846fb1a3bdba738b125221dc52bf22	maincpu:key	0	baddump	no
epr-11493.b9	65536	654485d9	b431270564c4e33fd70c8c85af1fcbff8b59ba49	gfx1	0	good	no
epr-11494.b10	65536	b67971ab	95cb6927baf425bcc290832ea9741b19852c7a1b	gfx1	10000	good	no
epr-11495.b11	65536	b687ab61	b08130a9d777c918972895136b1bf520d7117114	gfx1	20000	good	no
epr-11501.b1	65536	09179ead	3e6bf04e1e9ea867d087a47ff04ad0a064a8e299	sprites	1	good	no
epr-11505.b5	65536	b67f1ecf	3a26cdf91e5a1a11c1a8857e713a9e00cc1bfce0	sprites	0	good	no
epr-11502.b2	65536	7464bae4	c6b6ca240cee72e7fbd17bad5ca2d5cfe8e835c6	sprites	20001	good	no
epr-11506.b6	65536	b0104def	c81a66ec3a600c1d4c5d058caef15936c59b2574	sprites	20000	good	no
epr-11503.b3	65536	344c0692	3125701f6bb91d8f64515e214b571e169c30a444	sprites	40001	good	no
epr-11507.b7	65536	a2af710a	1c8b75b72797146c2eb788511f8cb1b367fc3e0d	sprites	40000	good	no
epr-11504.b4	65536	42b4a5f8	efb7beee7b45023861711f56b7cc907400cb266e	sprites	60001	good	no
epr-11508.b8	65536	5cbb833c	dc7041b6a4fa75d050bfc2176d0f9e242b55a0b8	sprites	60000	good	no
epr-11496.a7	32768	82cb40a9	daf2233438331ba6e6ff8bda4015e92d23e616c5	soundcpu	0	good	no
epr-11497.a8	32768	b04f62cc	29b468e5a565dc14e00c371913663eca66ccb44d	soundcpu	10000	good	no
epr-11498.a9	32768	97baf52b	97800014250b0099c7e53d597b0ef02ae14e6dba	soundcpu	20000	good	no
epr-11499.a10	32768	ea332866	eba0b422b39f7f3f81af1059043a87d944c4aff7	soundcpu	30000	good	no
epr-11500.a11	32768	2ddf1c31	77b20edbbd801072b20d9dc5e8fa2f468e53d79e	soundcpu	40000	good	no

chip

type	tag	name	clock
cpu	maincpu	Hitachi FD1094 Encrypted CPU	10000000
cpu	soundcpu	Zilog Z80	5000000
audio	mono	Speaker
audio	ym2151	YM2151 OPM	4000000
audio	upd	NEC uPD7759	640000
audio	netlist	Netlist Sound Device

device_ref

name
fd1094
z80
nvram
sega_315_5195
gfxdecode
palette
screen
sega_sys16b_sprite
segaic16_video
speaker
ym2151
upd7759
netlist_sound
nl_stream_in
nl_stream_in
nl_stream_in
nl_stream_out
upd4701a
upd4701a
cxd1095

sound

channels
1

input

players	coins	service	tilt
4	2	yes	no

control

type	player	buttons	reverse	maximum	sensitivity	keydelta
positional	1	1	no	10	10	1
trackball	1		yes	4095	100	30
stick	2	1	no	255	100	30
positional	2		no	10	10	1
pedal	2		no	7	100	1
trackball	3		yes	4095	100	30
stick	4		no	255	100	30
pedal	4		no	7	100	1

port, analog

port_tag	analog_masks
:DIAL1	15
:DIAL2	15
:DSW1
:DSW2
:HANDX1	255
:HANDX2	255
:HANDY1	7
:HANDY2	7
:P1
:P2
:SERVICE
:TRACKX1	4095
:TRACKX2	4095
:TRACKY1	4095
:TRACKY2	4095
:UNUSED

dipswitch

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSW1	15

location

name	number	inverted
SW1	1	no
SW1	2	no
SW1	3	no
SW1	4	no

value

name	value	default
4 Coins/1 Credit	7	no
3 Coins/1 Credit	8	no
2 Coins/1 Credit	9	no
2 Coins/1 Credit, 5/3, 6/4	5	no
2 Coins/1 Credit, 4/3	4	no
1 Coin/1 Credit	15	yes
1 Coin/1 Credit, 5/6	3	no
1 Coin/1 Credit, 4/5	2	no
1 Coin/1 Credit, 2/3	1	no
2 Coins/3 Credits	6	no
1 Coin/2 Credits	14	no
1 Coin/3 Credits	13	no
1 Coin/4 Credits	12	no
1 Coin/5 Credits	11	no
1 Coin/6 Credits	10	no
Free Play (if Coin B too) or 1/1	0	no

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSW1	240

location

name	number	inverted
SW1	5	no
SW1	6	no
SW1	7	no
SW1	8	no

value

name	value	default
4 Coins/1 Credit	112	no
3 Coins/1 Credit	128	no
2 Coins/1 Credit	144	no
2 Coins/1 Credit, 5/3, 6/4	80	no
2 Coins/1 Credit, 4/3	64	no
1 Coin/1 Credit	240	yes
1 Coin/1 Credit, 5/6	48	no
1 Coin/1 Credit, 4/5	32	no
1 Coin/1 Credit, 2/3	16	no
2 Coins/3 Credits	96	no
1 Coin/2 Credits	224	no
1 Coin/3 Credits	208	no
1 Coin/4 Credits	192	no
1 Coin/5 Credits	176	no
1 Coin/6 Credits	160	no
Free Play (if Coin A too) or 1/1	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW2	1

location

name	number	inverted
SW2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	no
On	0	yes

Starting Points

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Starting Points	DSW2	14

location

name	number	inverted
SW2	2	no
SW2	3	no
SW2	4	no

value

name	value	default
2000	6	no
3000	10	no
4000	12	no
5000	14	yes
6000	8	no
7000	4	no
8000	2	no
9000	0	no

Point Table

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Point Table	DSW2	48

location

name	number	inverted
SW2	5	no
SW2	6	no

value

name	value	default
Easy	32	no
Normal	48	yes
Hard	16	no
Hardest	0	no

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW2	192

location

name	number	inverted
SW2	7	no
SW2	8	no

value

name	value	default
Easy	0	no
Normal	192	yes
Hard	0	no
Hardest	0	no
