ACT-5A - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
act5a	microterm/microterm_f8.cpp		no	no	no	yes	ACT-5A	1980	Micro-Term

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	720	288	59.974377	16572000	918	0	720	301	0	288	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
act5a_2708.u1	1024	ad3bfa5a	723c7bfefbf96177171b8e58a8e20ee69daa27f0	maincpu	0	good	no
act5a_2708.u12	1024	be4a148d	69bf838ed9fccdf7f225bc380bcce8e7e0bd88bc	maincpu	400	good	no
act5a_2708.u22	1024	f0ec3b9f	7785eba9993c23a767b84fff2c44d5cb6210ad80	maincpu	800	good	no
act5a_9316.u39	8192	6f9eac71	0488bdd19a6bff4e869a3480c7e9d8c5ca9938eb	kbdecode	0	good	no
act5a_9316.u55	8192	8f96b7c8	652d420ab5be9412cae322cd1799f8a9e3959c44	chargen	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Fairchild F8	2000000
audio	mono	Speaker
audio	bell	Beep	1760

device_ref

name
f8
f3853_smi
ay51013
rs232
ipt_merge_all_hi
screen
ripple_counter
speaker
beep

sound

channels
1

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keyboard		87		no

port, analog

port_tag	analog_masks
:DSW1
:DSW2
:DSW3
:JUMPERS
:KEY0
:KEY1
:KEY10
:KEY2
:KEY3
:KEY4
:KEY5
:KEY6
:KEY7
:KEY8
:KEY9
:MODIFIERS
:SPECIAL

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
io	terminal	serial_terminal	no
io	sunkbd	sunkbd_adaptor	no
io	dec_loopback	dec_rs232_loopback	no
io	ie15	ie15_terminal	no
io	null_modem	null_modem	no
io	keyboard	serial_keyboard	no
io	patch	rs232_patch_box	no
io	swtpc8212	swtpc8212_terminal	no
io	printer	serial_printer	no
io	scorpion	scorpion_ic	no
io	loopback	rs232_loopback	no
io	mockingboard	mockingboardd	no
io	msystems_mouse	rs232_mouse_hle_msystems	no
io	nss_tvi	nss_tvinterface	no
io	rs232_sync_io	rs232_sync_io	no
io	pty	pseudo_terminal	no
io	rs_printer	rs_serial_printer	no

dipswitch

Printer Data Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Printer Data Rate	DSW1	255

location

name	number	inverted
S1	8	no
S1	7	no
S1	6	no
S1	5	no
S1	4	no
S1	3	no
S1	2	no
S1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
110	127	no
300	191	no
600	223	no
1,200	239	no
2,400	247	no
4,800	251	no
9,600	253	yes
19,200	254	no

I/O Data Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
I/O Data Rate	DSW2	255

location

name	number	inverted
S2	1	no
S2	2	no
S2	3	no
S2	4	no
S2	5	no
S2	6	no
S2	7	no
S2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
110	127	no
300	191	no
600	223	no
1,200	239	no
2,400	247	no
4,800	251	no
9,600	253	yes
19,200	254	no

Conversation Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Conversation Mode	DSW3	1

location

name	number	inverted
S3	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Half Duplex	1	no
Full Duplex	0	yes

Protected Field Attribute

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Protected Field Attribute	DSW3	6

location

name	number	inverted
S3	2	no
S3	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Reduced Intensity	6	yes
Blinking	2	no
Reverse Video	4	no
Underline	0	no

Display Null Character

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Display Null Character	DSW3	8

location

name	number	inverted
S3	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	8	yes

8th Bit Transmit

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
8th Bit Transmit	DSW3	16

location

name	number	inverted
S3	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
0 (Space)	0	no
1 (Mark)	16	yes

Word Length

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Word Length	DSW3	96

location

name	number	inverted
S3	6	no
S3	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
5 Bits	0	no
6 Bits	64	no
7 Bits	32	no
8 Bits	96	yes

Number of Stop Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Number of Stop Bits	DSW3	256

location

name	number	inverted
S3	9	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1	0	no
2	256	yes

Parity

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Parity	DSW3	640

location

name	number	inverted
S3	8	no
S3	10	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
None	640	yes
Even	128	no
Odd	0	no

Underline

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Underline	JUMPERS	3

location

name	number	inverted
W1	1	no
W1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Single	2	yes
Double	1	no

Cursor Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cursor Rate	JUMPERS	60

location

name	number	inverted
W2	1	no
W2	2	no
W2	3	no
W2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
0 Hz	28	no
1 Hz	44	no
2 Hz	52	yes
4 Hz	56	no

Blinking Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Blinking Rate	JUMPERS	448

location

name	number	inverted
W3	1	no
W3	2	no
W3	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1 Hz	192	yes
2 Hz	320	no
4 Hz	384	no

Protected Video Attribute

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Protected Video Attribute	JUMPERS	7680

location

name	number	inverted
W4	4	no
W4	3	no
W4	2	no
W4	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Reduced Intensity	3584	yes
Blinking	5632	no
Reverse Video	6656	no
Underline	7168	no

Keyboard Auto Repeat Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Keyboard Auto Repeat Rate	JUMPERS	57344

location

name	number	inverted
W5	1	no
W5	2	no
W5	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
7.5 cps	24576	yes
15 cps	40960	no
30 cps	49152	no
