Af-Tor - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
aftor	pinball/wico.cpp	genpin	no	no	yes	yes	Af-Tor	1984	Wico

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
u25.bin	4096	d66e95ff	f7e8c51f1b37e7ef560406f1968c12a2043646c5	hcpu	0	good	no
u52.bin	8192	8035b446	3ec59015e259c315bf09f4e2046f9d98e2d7a732	ccpu	0	good	no
u48.bin	8192	b4406563	6d1a9086eb1f6f947eae3a92ccf7a9b7375d85d3	ccpu	2000	good	no

chip

type	tag	name	clock
cpu	ccpu	Motorola MC6809E	1250000
cpu	hcpu	Motorola MC6809E	1250000
audio	mechvol	Speaker
audio	samples	Samples
audio	mono	Speaker
audio	sn76494	SN76494	156250

device_ref

name
mc6809e
mc6809e
timer
timer
nvram
speaker
samples
speaker
sn76494

sample

name
bumper
chime1
chime2
chime3
chime4
hole
knocker
sling
coinin
outhole
kickback
drop_target_reset
coil_coinlockout_engage
coil_coinlockout_release
relay_engage
relay_release
solenoid_engage
solenoid_release

sound

channels
2

input

players	coins	service	tilt
1	2	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keypad		51		no

port, analog

port_tag	analog_masks
:X0
:X1
:X10
:X11
:X12
:X13
:X14
:X15
:X2
:X3
:X4
:X5
:X6
:X7
:X8
:X9

dipswitch

Chute 1

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Chute 1	X12	15

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1 Coin/1 Credit	0	yes
1 Coin/2 Credits	1	no
1 Coin/3 Credits	2	no
1 Coin/4 Credits	3	no
1 Coin/5 Credits	4	no
1 Coin/6 Credits	5	no
1 Coin/7 Credits	6	no
1 coin 10 credits	7	no
1 coin 14 credits	8	no
2 Coins/1 Credit	9	no
2 Coins/5 Credits	10	no
2 Coins/7 Credits	11	no
2 coins 1 credit then 2 coins for 2 more credits	12	no
1 coin 1 credit up to 3, then 4th coin gives 2 credits	13	no
1 coin 1 credit, next coin gives 2 credits	14	no
1st coin 1 credit, 2nd coin 2 more credits, 3rd coin 1 credit, 4th coin 3 more credits	15	no

Release Targets Spot Wico

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Release Targets Spot Wico	X12	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	0	yes
Off	16	no

Saving Top Lane Lights

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Saving Top Lane Lights	X12	32

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	0	yes
Off	32	no

Fast Ride Lights Extra Ball

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Fast Ride Lights Extra Ball	X12	64

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
2	0	yes
3	64	no

Free Play

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Free Play	X12	128

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	128	no

Chute 2

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Chute 2	X13	15

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1 Coin/1 Credit	0	yes
1 Coin/2 Credits	1	no
1 Coin/3 Credits	2	no
1 Coin/4 Credits	3	no
1 Coin/5 Credits	4	no
1 Coin/6 Credits	5	no
1 Coin/7 Credits	6	no
1 coin 10 credits	7	no
1 coin 14 credits	8	no
2 Coins/1 Credit	9	no
2 Coins/5 Credits	10	no
2 Coins/7 Credits	11	no
2 coins 1 credit then 2 coins for 2 more credits	12	no
1 coin 1 credit up to 3, then 4th coin gives 2 credits	13	no
1 coin 1 credit, next coin gives 2 credits	14	no
1st coin 1 credit, 2nd coin 2 more credits, 3rd coin 1 credit, 4th coin 3 more credits	15	no

Drain eject hole on outhole

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Drain eject hole on outhole	X13	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	0	yes

2x multi during multiball

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2x multi during multiball	X13	32

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	0	yes
Off	32	no

Credits for new High score

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Credits for new High score	X13	192

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
3	0	no
2	64	yes
1	128	no
0	192	no

Reset left outlane gate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Reset left outlane gate	X14	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	0	yes

Maximum credits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Maximum credits	X14	6

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
10	0	no
15	2	yes
25	4	no
40	6	no

Extra ball allowed

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Extra ball allowed	X14	8

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	0	yes
Off	8	no

Level pass payout

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Level pass payout	X14	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Free Game	0	yes
Extra Ball	16	no

Capture ball in multiball

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Capture ball in multiball	X14	32

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	32	yes

Saves multi-lights

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Saves multi-lights	X14	64

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	0	yes
Off	64	no

One extra ball per ball

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
One extra ball per ball	X14	128

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	128	yes

Special bonus

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Special bonus	X15	3

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Free Game	0	yes
Extra Ball	1	no
100k points	2	no
Nothing	3	no

Flip special lights

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flip special lights	X15	4

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Alternate	0	yes
Both on	4	no

Balls

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Balls	X15	24

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
2	0	no
3	8	yes
4	16	no
5	24	no

Disable Credits display

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Disable Credits display	X15	32

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	32	no

Disable Match display

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Disable Match display	X15	64

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	64	no
