AgVision - mame (0283) machine

MAME: 0283 - Released: 2025-11-27T19:22:18 - Machines: 49383 - rom: 366513 - disk: 1391

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
agvision	trs/agvision.cpp		no	no	no	yes	AgVision	1979	Elanco

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	372	243	59.922743	7159090	456	0	372	262	0	243	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	yes	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
8041716-1.1-agvision.u13	2048	5b11b13e	896e68f90ed57e0921887e717fc92eda067a210d	maincpu	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC6809E	894886

device_ref

name
mc6809e
pia6821
screen
mc6847
sam6883
rs232
null_modem
bitbanger
ram

sound

channels
0

ramoption

name	default
4K
16K	yes

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
bitbanger	rs232:null_modem:stream				bitbanger	bitb

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
bitbanger	rs232:null_modem:stream

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
keyboard		53		no

port, analog

port_tag	analog_masks
:hup
:row0
:row1
:row2
:row3
:row4
:row5
:row6
:rs232:null_modem:FLOW_CONTROL
:rs232:null_modem:RS232_DATABITS
:rs232:null_modem:RS232_PARITY
:rs232:null_modem:RS232_RXBAUD
:rs232:null_modem:RS232_STOPBITS
:rs232:null_modem:RS232_TXBAUD
:vdg:artifacting

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
rs232	terminal	serial_terminal	no
rs232	sunkbd	sunkbd_adaptor	no
rs232	votraxtnt	serial_votraxtnt	no
rs232	rs_printer	rs_serial_printer	no
rs232	dec_loopback	dec_rs232_loopback	no
rs232	h19	serial_heath_h19	no
rs232	ie15	ie15_terminal	no
rs232	null_modem	null_modem	yes
rs232	keyboard	serial_keyboard	no
rs232	patch	rs232_patch_box	no
rs232	swtpc8212	swtpc8212_terminal	no
rs232	printer	serial_printer	no
rs232	scorpion	scorpion_ic	no
rs232	loopback	rs232_loopback	no
rs232	mockingboard	mockingboardd	no
rs232	msystems_mouse	rs232_mouse_hle_msystems	no
rs232	nss_tvi	nss_tvinterface	no
rs232	rs232_sync_io	rs232_sync_io	no
rs232	pty	pseudo_terminal	no

configuration

Flow Control

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flow Control	rs232:null_modem:FLOW_CONTROL	7

setting

name	value	default
Off	0	yes
RTS	1	no
DTR	2	no
XON/XOFF	4	no

CR/LF Input Conversion

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
CR/LF Input Conversion	rs232:null_modem:FLOW_CONTROL	24

setting

name	value	default
Off	0	yes
LF to CR	8	no
CR/LF to CR	16	no
LF to CR/LF	24	no

Delay After CR

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Delay After CR	rs232:null_modem:FLOW_CONTROL	224

setting

name	value	default
None	0	yes
10 ms	32	no
20 ms	64	no
40 ms	96	no
80 ms	128	no
160 ms	160	no
320 ms	192	no
640 ms	224	no

Data Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Data Bits	rs232:null_modem:RS232_DATABITS	255

setting

name	value	default
5	0	no
6	1	no
7	2	no
8	3	yes

Parity

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Parity	rs232:null_modem:RS232_PARITY	255

setting

name	value	default
None	0	yes
Odd	1	no
Even	2	no
Mark	3	no
Space	4	no

RX Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
RX Baud	rs232:null_modem:RS232_RXBAUD	255

setting

name	value	default
50	14	no
75	15	no
110	0	no
134.5	16	no
150	1	no
200	17	no
300	2	yes
600	3	no
1200	4	no
1800	18	no
2000	19	no
2400	5	no
3600	20	no
4800	6	no
7200	21	no
9600	7	no
14400	8	no
19200	9	no
28800	10	no
38400	11	no
57600	12	no
76800	23	no
78125	24	no
111900	22	no
115200	13	no

Stop Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stop Bits	rs232:null_modem:RS232_STOPBITS	255

setting

name	value	default
0	0	no
1	1	yes
1.5	2	no
2	3	no

TX Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
TX Baud	rs232:null_modem:RS232_TXBAUD	255

setting

name	value	default
50	14	no
75	15	no
110	0	no
134.5	16	no
150	1	no
200	17	no
300	2	yes
600	3	no
1200	4	no
1800	18	no
2000	19	no
2400	5	no
3600	20	no
4800	6	no
7200	21	no
9600	7	no
14400	8	no
19200	9	no
28800	10	no
38400	11	no
57600	12	no
76800	23	no
78125	24	no
111900	22	no
115200	13	no

Artifacting

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Artifacting	vdg:artifacting	3

setting

name	value	default
Off	0	no
Standard	1	yes
Reverse	2	no
