Alex Kidd: The Lost Stars (set 2, unprotected) - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
alexkidd	sega/segas16a.cpp		no	no	no	yes	Alex Kidd: The Lost Stars (set 2, unprotected)	1986	Sega

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	320	224	60.000000	5376240	342	0	320	262	0	224	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
epr-10447.43	65536	29e87f71	af980e55c02b3de1121c144fee23af74d24042ac	maincpu	0	good	no
epr-10445.26	65536	25ce5b6f	dfec64df7e8d145d30740808bc94bdbbe667c4e8	maincpu	1	good	no
epr-10448.42	65536	05baedb5	fc15989bf3d850170e4e018d74f18553f0268576	maincpu	20000	good	no
epr-10446.25	65536	cd61d23c	c235c4fef28556e9f2d07e815ad213c308e85598	maincpu	20001	good	no
epr-10431.95	32768	a7962c39	c816fc5d9f21b2ba32b9841e64b634bce7ea78c8	gfx1	0	good	no
epr-10432.94	32768	db8cd24e	656d98844ad9ccaa68e3f501137dddd0a27d999d	gfx1	8000	good	no
epr-10433.93	32768	e163c8c2	ac54c5ecedca5b1a2c550de32687ca57c4d3a411	gfx1	10000	good	no
epr-10437.10	32768	522f7618	9a6bc857dfef1dd1b7bffa034523c1c4cd8b3f4c	sprites	1	good	no
epr-10441.11	32768	74e3a35c	26b980a0a3aee94ac38e0e0c7d305bb35a60d1c4	sprites	0	good	no
epr-10438.17	32768	738a6362	a3c5f10c263cb216d275875f6333484a1cca281b	sprites	10001	good	no
epr-10442.18	32768	86cb9c14	42bd0ed985de61ff183eed0192257966caa01594	sprites	10000	good	no
epr-10439.23	32768	b391aca7	ca9d80b67e5365f709f90a5342b5e3aa7c7126e1	sprites	20001	good	no
epr-10443.24	32768	95d32635	788af2af1ae783128bcdc8cd44d17cd2f1542231	sprites	20000	good	no
epr-10440.29	32768	23939508	68450a18fc7e35f5b0155632aa68cffd251be38c	sprites	30001	good	no
epr-10444.30	32768	82115823	e4103003cda949bebe57815115a5028f4fe8e7d7	sprites	30000	good	no
epr-10434.12	32768	77141cce	6c5e83527f7e11a5ff5cc4fa75d55618a55e1a58	soundcpu	0	good	no
7751.bin	1024	6a9534fc	67ad94674db5c2aab75785668f610f6f4eccd158	upd7751	0	good	no
epr-10435.1	32768	ad89f6e3	812a132142065b0fe13b5f0ac534b6d8830ba102	upd7751data	0	good	no
epr-10436.2	32768	96c76613	fe3e4e649fd2cb2453eec0c92015bd54b3b9a1b5	upd7751data	8000	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	10000000
cpu	soundcpu	Zilog Z80	4000000
cpu	upd7751	NEC uPD7751	6000000
audio	speaker	Speaker
audio	ymsnd	YM2151 OPM	4000000
audio	dac	8-Bit R-2R DAC

device_ref

name
m68000
z80
upd7751
i8243
nvram
watchdog
i8255
screen
sega_sys16a_sprite
segaic16_video
gfxdecode
palette
speaker
generic_latch_8
ym2151
dac_8bit_r2r

sound

channels
1

input

players	coins	service	tilt
2	2	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	3	8	no
joy	2	3	8	no

port, analog

port_tag	analog_masks
:DSW1
:DSW2
:P1
:P2
:SERVICE
:UNUSED

dipswitch

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSW1	15

location

name	number	inverted
SW1	1	no
SW1	2	no
SW1	3	no
SW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
4 Coins/1 Credit	7	no
3 Coins/1 Credit	8	no
2 Coins/1 Credit	9	no
2 Coins/1 Credit, 5/3, 6/4	5	no
2 Coins/1 Credit, 4/3	4	no
1 Coin/1 Credit	15	yes
1 Coin/1 Credit, 5/6	3	no
1 Coin/1 Credit, 4/5	2	no
1 Coin/1 Credit, 2/3	1	no
2 Coins/3 Credits	6	no
1 Coin/2 Credits	14	no
1 Coin/3 Credits	13	no
1 Coin/4 Credits	12	no
1 Coin/5 Credits	11	no
1 Coin/6 Credits	10	no
Free Play (if Coin B too) or 1/1	0	no

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSW1	240

location

name	number	inverted
SW1	5	no
SW1	6	no
SW1	7	no
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
4 Coins/1 Credit	112	no
3 Coins/1 Credit	128	no
2 Coins/1 Credit	144	no
2 Coins/1 Credit, 5/3, 6/4	80	no
2 Coins/1 Credit, 4/3	64	no
1 Coin/1 Credit	240	yes
1 Coin/1 Credit, 5/6	48	no
1 Coin/1 Credit, 4/5	32	no
1 Coin/1 Credit, 2/3	16	no
2 Coins/3 Credits	96	no
1 Coin/2 Credits	224	no
1 Coin/3 Credits	208	no
1 Coin/4 Credits	192	no
1 Coin/5 Credits	176	no
1 Coin/6 Credits	160	no
Free Play (if Coin A too) or 1/1	0	no

Continues

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Continues	DSW2	1

location

name	number	inverted
SW2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Only before level 5	1	no
Unlimited	0	yes

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW2	2

location

name	number	inverted
SW2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	no
On	0	yes

Lives

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Lives	DSW2	12

location

name	number	inverted
SW2	3	no
SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
3	12	yes
4	8	no
5	4	no
240 (Cheat)	0	no

Bonus Life

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bonus Life	DSW2	48

location

name	number	inverted
SW2	5	no
SW2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
10000	32	no
20000	48	yes
40000	16	no
None	0	no

Time Adjust

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Time Adjust	DSW2	192

location

name	number	inverted
SW2	7	no
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
70	128	no
60	192	yes
50	64	no
40	0	no
