Alien Syndrome (set 7, System 16B, MC-8123B 317-00xx) - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
aliensyn7	sega/segas16b.cpp		no	no	no	yes	Alien Syndrome (set 7, System 16B, MC-8123B 317-00xx)	1987	Sega	aliensyn	aliensyn

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	320	224	60.054389	6293700	400	0	320	262	0	224	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge
epr-11083.a4	32768	cb2ad9b3	66284b4e1071b3cb4b36960a2dba8949325f9e86	maincpu	0	good	no	epr-11083.a4
epr-11080.a1	32768	fe7378d9	acfee79e5fe9fdf95926562c02599e96e96f76b5	maincpu	1	good	no	epr-11080.a1
epr-11084.a5	32768	2e1ec7b1	666a9e402d7d02d74c0a2468853a3843b161c1a2	maincpu	10000	good	no	epr-11084.a5
epr-11081.a2	32768	1308ee63	36a4c8cf3a310398e264c57c7c6f53c05dbc0108	maincpu	10001	good	no	epr-11081.a2
epr-11085.a6	32768	cff78f39	78431ce6c03232150a8db15499da9371977b570b	maincpu	20000	good	no	epr-11085.a6
epr-11082.a3	32768	9cdc2a14	c06693f45675e31d591703c27bb3f6ec02fc1215	maincpu	20001	good	no	epr-11082.a3
epr-10702.b9	65536	393bc813	672782c8fb2a6e454b27e073acc26130cacf3e50	gfx1	0	good	no	epr-10702.b9
epr-10703.b10	65536	6b6dd9f5	964409c6630caa13caf7d644d0c6fb071860b61b	gfx1	10000	good	no	epr-10703.b10
epr-10704.b11	65536	911e7ebc	f03d3d3a09d19f7b705f9cb29f73140a3073463f	gfx1	20000	good	no	epr-10704.b11
epr-10709.b1	65536	addf0a90	a92c9531f1817763773471ce63f566b9e88360a0	sprites	1	good	no	epr-10709.b1
epr-10713.b5	65536	ececde3a	9c12d4665179bf433c42f5ddc8a043ad592aa90e	sprites	0	good	no	epr-10713.b5
epr-10710.b2	65536	992369eb	c6796acf6807e9ba4c3d241903653f91adf4764e	sprites	20001	good	no	epr-10710.b2
epr-10714.b6	65536	91bf42fb	4b9d3e97768323dee01e92378adafecb26bcc094	sprites	20000	good	no	epr-10714.b6
epr-10711.b3	65536	29166ef6	99a7cfd7d811537c821412a320beadb5a9c09af3	sprites	40001	good	no	epr-10711.b3
epr-10715.b7	65536	a7c57384	46f8efa691d7bbb0a18119c0ff12cff7c0d129e1	sprites	40000	good	no	epr-10715.b7
epr-10712.b4	65536	876ad019	39973ddb5a5746e0e094c759447bff1130c72c84	sprites	60001	good	no	epr-10712.b4
epr-10716.b8	65536	40ba1d48	e2d4d2689bb9b9bdc85e7f72a6665e5fd4c583aa	sprites	60000	good	no	epr-10716.b8
epr-11086.a7	32768	c7fddc28	cf77748ba179829913923d2695101ac7c76c4667	soundcpu	0	good	no
epr-10724.a8	32768	f971a817	502c95638e4fd5f87e5fc837cb44b39a5d62f4e4	soundcpu	10000	good	no	epr-10724.a8
epr-10725.a9	32768	6a50e08f	d34b2ccadb8b07d5ad99cab5c5b5b79642c65574	soundcpu	20000	good	no	epr-10725.a9
epr-10726.a10	32768	d50b7736	b1f8e3b0cf2ffee5382098100cfabe21b383cd51	soundcpu	30000	good	no	epr-10726.a10
317-00xx.key	8192	76b370cd	996a4a24dec085caf93cbe614d3b0888379c91dd	soundcpu:key	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	10000000
cpu	soundcpu	MC-8123	5000000
audio	mono	Speaker
audio	ym2151	YM2151 OPM	4000000
audio	upd	NEC uPD7759	640000
audio	netlist	Netlist Sound Device

device_ref

name
m68000
mc8123
nvram
sega_315_5195
gfxdecode
palette
screen
sega_sys16b_sprite
segaic16_video
speaker
ym2151
upd7759
netlist_sound
nl_stream_in
nl_stream_in
nl_stream_in
nl_stream_out

sound

channels
1

input

players	coins	service	tilt
2	2	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	3	8	no
joy	2	3	8	no

port, analog

port_tag	analog_masks
:DSW1
:DSW2
:P1
:P2
:SERVICE
:UNUSED

dipswitch

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSW1	15

location

name	number	inverted
SW1	1	no
SW1	2	no
SW1	3	no
SW1	4	no

value

name	value	default
4 Coins/1 Credit	7	no
3 Coins/1 Credit	8	no
2 Coins/1 Credit	9	no
2 Coins/1 Credit, 5/3, 6/4	5	no
2 Coins/1 Credit, 4/3	4	no
1 Coin/1 Credit	15	yes
1 Coin/1 Credit, 5/6	3	no
1 Coin/1 Credit, 4/5	2	no
1 Coin/1 Credit, 2/3	1	no
2 Coins/3 Credits	6	no
1 Coin/2 Credits	14	no
1 Coin/3 Credits	13	no
1 Coin/4 Credits	12	no
1 Coin/5 Credits	11	no
1 Coin/6 Credits	10	no
Free Play (if Coin B too) or 1/1	0	no

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSW1	240

location

name	number	inverted
SW1	5	no
SW1	6	no
SW1	7	no
SW1	8	no

value

name	value	default
4 Coins/1 Credit	112	no
3 Coins/1 Credit	128	no
2 Coins/1 Credit	144	no
2 Coins/1 Credit, 5/3, 6/4	80	no
2 Coins/1 Credit, 4/3	64	no
1 Coin/1 Credit	240	yes
1 Coin/1 Credit, 5/6	48	no
1 Coin/1 Credit, 4/5	32	no
1 Coin/1 Credit, 2/3	16	no
2 Coins/3 Credits	96	no
1 Coin/2 Credits	224	no
1 Coin/3 Credits	208	no
1 Coin/4 Credits	192	no
1 Coin/5 Credits	176	no
1 Coin/6 Credits	160	no
Free Play (if Coin A too) or 1/1	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW2	1

location

name	number	inverted
SW2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW2	2

location

name	number	inverted
SW2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	no
On	0	yes

Lives

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Lives	DSW2	12

location

name	number	inverted
SW2	3	no
SW2	4	no

value

name	value	default
2	8	no
3	12	yes
4	4	no
Free Play	0	no

Timer

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Timer	DSW2	48

location

name	number	inverted
SW2	5	no
SW2	6	no

value

name	value	default
120	0	no
130	16	no
140	32	no
150	48	yes

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW2	192

location

name	number	inverted
SW2	7	no
SW2	8	no

value

name	value	default
Easy	128	no
Normal	192	yes
Hard	64	no
Hardest	0	no
