Altos 5-15 - mame (0281) machine

MAME: 0281 - Released: 2025-09-24T18:40:45 - Machines: 49006 - rom: 365545 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
altos5	altos/altos5.cpp		no	no	no	yes	Altos 5-15	1982	Altos

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
rs232:terminal:terminal_screen	raster	0	640	240	50.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
2732.bin	4096	15fdc7eb	e15bdf5d5414ad56f8c4bb84edc6f967a5f01ba9	maincpu	0	good	no
82s141.bin	512	35c8078c	dce24374bfcc5d23959e2c03485d82a119c0c3c9	proms	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Zilog Z80	4000000
audio	rs232:terminal:bell	Speaker
audio	rs232:terminal:beeper	Beep	2000
audio	fdc:0:525qd:flopsndout	Speaker
audio	fdc:0:525qd:floppysound	Floppy sound	44100
audio	fdc:1:525qd:flopsndout	Speaker
audio	fdc:1:525qd:floppysound	Floppy sound	44100

softwarelist

tag	name	status	filter
flop_list	altos5	original

device_ref

name
z80
z80dma
z80pio
z80pio
z80dart
z80dart_channel
z80dart_channel
z80sio
z80sio_channel
z80sio_channel
z80ctc
z80ctc_channel
z80ctc_channel
z80ctc_channel
z80ctc_channel
rs232
serial_terminal
screen
generic_keyboard
speaker
beep
fd1797
floppy_connector
floppy_525_qd
speaker
flopsnd
floppy_connector
floppy_525_qd
speaker
flopsnd
software_list
quickload

sound

channels
3

device, instance

type	tag	interface	name	briefname
floppydisk	fdc:0:525qd	floppy_5_25	floppydisk1	flop1
floppydisk	fdc:1:525qd	floppy_5_25	floppydisk2	flop2
quickload	quickload		quickload	quik

device, extension

type	tag	interface	extension_names
floppydisk	fdc:0:525qd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk
floppydisk	fdc:1:525qd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk
quickload	quickload		com, cpm

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keyboard		73		no

port, analog

port_tag	analog_masks
:rs232:terminal:RS232_DATABITS
:rs232:terminal:RS232_PARITY
:rs232:terminal:RS232_RXBAUD
:rs232:terminal:RS232_STOPBITS
:rs232:terminal:RS232_TXBAUD
:rs232:terminal:TERM_CONF
:rs232:terminal:keyboard:GENKBD_CFG
:rs232:terminal:keyboard:GENKBD_MOD
:rs232:terminal:keyboard:GENKBD_ROW0
:rs232:terminal:keyboard:GENKBD_ROW1
:rs232:terminal:keyboard:GENKBD_ROW2
:rs232:terminal:keyboard:GENKBD_ROW3

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
rs232	terminal	serial_terminal	yes
rs232	sunkbd	sunkbd_adaptor	no
rs232	dec_loopback	dec_rs232_loopback	no
rs232	ie15	ie15_terminal	no
rs232	null_modem	null_modem	no
rs232	keyboard	serial_keyboard	no
rs232	patch	rs232_patch_box	no
rs232	swtpc8212	swtpc8212_terminal	no
rs232	printer	serial_printer	no
rs232	scorpion	scorpion_ic	no
rs232	loopback	rs232_loopback	no
rs232	mockingboard	mockingboardd	no
rs232	msystems_mouse	rs232_mouse_hle_msystems	no
rs232	nss_tvi	nss_tvinterface	no
rs232	rs232_sync_io	rs232_sync_io	no
rs232	pty	pseudo_terminal	no
rs232	votraxtnt	serial_votraxtnt	no
rs232	rs_printer	rs_serial_printer	no
fdc:0	525qd	floppy_525_qd	yes
fdc:1	525qd	floppy_525_qd	yes

configuration

Data Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Data Bits	rs232:terminal:RS232_DATABITS	255

setting

name	value	default
5	0	no
6	1	no
7	2	no
8	3	yes

Parity

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Parity	rs232:terminal:RS232_PARITY	255

setting

name	value	default
None	0	yes
Odd	1	no
Even	2	no
Mark	3	no
Space	4	no

RX Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
RX Baud	rs232:terminal:RS232_RXBAUD	255

setting

name	value	default
50	14	no
75	15	no
110	0	no
134.5	16	no
150	1	no
200	17	no
300	2	no
600	3	no
1200	4	no
1800	18	no
2000	19	no
2400	5	no
3600	20	no
4800	6	no
7200	21	no
9600	7	yes
14400	8	no
19200	9	no
28800	10	no
38400	11	no
57600	12	no
76800	23	no
78125	24	no
111900	22	no
115200	13	no

Stop Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stop Bits	rs232:terminal:RS232_STOPBITS	255

setting

name	value	default
0	0	no
1	1	yes
1.5	2	no
2	3	no

TX Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
TX Baud	rs232:terminal:RS232_TXBAUD	255

setting

name	value	default
50	14	no
75	15	no
110	0	no
134.5	16	no
150	1	no
200	17	no
300	2	no
600	3	no
1200	4	no
1800	18	no
2000	19	no
2400	5	no
3600	20	no
4800	6	no
7200	21	no
9600	7	yes
14400	8	no
19200	9	no
28800	10	no
38400	11	no
57600	12	no
76800	23	no
78125	24	no
111900	22	no
115200	13	no

Cursor

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cursor	rs232:terminal:TERM_CONF	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	1	yes

Type

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Type	rs232:terminal:TERM_CONF	2

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Underline	0	no
Block	2	yes

Blinking

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Blinking	rs232:terminal:TERM_CONF	4

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	4	yes

Invert

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Invert	rs232:terminal:TERM_CONF	8

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	8	yes

Color

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Color	rs232:terminal:TERM_CONF	48

setting

name	value	default
Green	0	yes
Amber	16	no
White	32	no

Auto CR on LF

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Auto CR on LF	rs232:terminal:TERM_CONF	64

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	64	yes

Auto LF on CR

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Auto LF on CR	rs232:terminal:TERM_CONF	128

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	128	no

Local echo

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Local echo	rs232:terminal:TERM_CONF	256

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	256	no

Layout

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Layout	rs232:terminal:keyboard:GENKBD_CFG	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
ANSI	0	yes
JIS	1	no

Typematic Delay

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Typematic Delay	rs232:terminal:keyboard:GENKBD_CFG	6

setting

name	value	default
0.25s	0	no
0.5s	2	no
0.75s	4	yes
1.0s	6	no

Typematic Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Typematic Rate	rs232:terminal:keyboard:GENKBD_CFG	248

setting

name	value	default
2.0cps	0	no
2.1cps	8	no
2.5cps	16	no
2.7cps	24	no
2.0cps	32	no
2.1cps	40	no
2.5cps	48	no
2.7cps	56	no
3.3cps	64	no
3.8cps	72	no
4.0cps	80	no
4.3cps	88	no
4.6cps	96	no
5.0cps	104	no
5.5cps	112	no
6.0cps	120	no
8.0cps	128	no
8.6cps	136	no
9.2cps	144	no
10.0cps	152	yes
10.9cps	160	no
12.0cps	168	no
13.3cps	176	no
15.0cps	184	no
16.0cps	192	no
17.1cps	200	no
18.5cps	208	no
20.0cps	216	no
21.8cps	224	no
24.0cps	232	no
26.7cps	240	no
30.0cps	248	no
