Amust Executive 816 - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
amust	ausnz/amust.cpp		no	no	no	yes	Amust Executive 816	1983	Amust

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	640	480	50.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	supported	no	no	no	no

rom

name	size	crc	sha1	region	status	optional
mon_h.ic25	4096	10dceac6	1ef80039063f7a6455563d59f1bcc23e09eca369	maincpu	good	no
cg4.ic74	2048	52e7b9d8	cc6d457634eb688ccef471f72bddf0424e64b045	chargen	good	no
kbd_3.rom	2048	d9441b35	ce250ab1e892a13fd75182703f259855388c6bf4	keyboard	good	no

chip

type	tag	name	clock
cpu	maincpu	Zilog Z80	4000000
audio	mono	Speaker
audio	beeper	Beep	800
audio	fdc:0:525qd:flopsndout	Speaker
audio	fdc:0:525qd:floppysound	Floppy sound	44100
audio	fdc:1:525qd:flopsndout	Speaker
audio	fdc:1:525qd:floppysound	Floppy sound	44100

device_ref

name
z80
screen
palette
gfxdecode
speaker
beep
timer
hd6845s
upd765a
floppy_connector
floppy_525_qd
speaker
flopsnd
floppy_connector
floppy_525_qd
speaker
flopsnd
clock
i8251
rs232
serial_keyboard
i8251
pit8253
pit_counter
pit_counter
pit_counter
i8255
i8255

sound

channels
3

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
floppydisk	fdc:0:525qd	floppy_5_25			floppydisk1	flop1
floppydisk	fdc:1:525qd	floppy_5_25			floppydisk2	flop2

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
floppydisk	fdc:0:525qd	floppy_5_25			mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk
floppydisk	fdc:1:525qd	floppy_5_25			mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keyboard		73		no

port, analog

port_tag	analog_masks
:P9
:rs232:keyboard:GENKBD_CFG
:rs232:keyboard:GENKBD_MOD
:rs232:keyboard:GENKBD_ROW0
:rs232:keyboard:GENKBD_ROW1
:rs232:keyboard:GENKBD_ROW2
:rs232:keyboard:GENKBD_ROW3
:rs232:keyboard:RS232_DATABITS
:rs232:keyboard:RS232_PARITY
:rs232:keyboard:RS232_STOPBITS
:rs232:keyboard:RS232_TXBAUD

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
fdc:0	525qd	floppy_525_qd	yes
fdc:1	525qd	floppy_525_qd	yes
rs232	terminal	serial_terminal	no
rs232	sunkbd	sunkbd_adaptor	no
rs232	dec_loopback	dec_rs232_loopback	no
rs232	ie15	ie15_terminal	no
rs232	null_modem	null_modem	no
rs232	keyboard	serial_keyboard	yes
rs232	patch	rs232_patch_box	no
rs232	swtpc8212	swtpc8212_terminal	no
rs232	printer	serial_printer	no
rs232	scorpion	scorpion_ic	no
rs232	loopback	rs232_loopback	no
rs232	mockingboard	mockingboardd	no
rs232	msystems_mouse	rs232_mouse_hle_msystems	no
rs232	nss_tvi	nss_tvinterface	no
rs232	rs232_sync_io	rs232_sync_io	no
rs232	pty	pseudo_terminal	no
rs232	rs_printer	rs_serial_printer	no

configuration

Layout

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Layout	rs232:keyboard:GENKBD_CFG	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
ANSI	0	yes
JIS	1	no

Typematic Delay

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Typematic Delay	rs232:keyboard:GENKBD_CFG	6

setting

name	value	default
0.25s	0	no
0.5s	2	no
0.75s	4	yes
1.0s	6	no

Typematic Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Typematic Rate	rs232:keyboard:GENKBD_CFG	248

setting

name	value	default
2.0cps	0	no
2.1cps	8	no
2.5cps	16	no
2.7cps	24	no
2.0cps	32	no
2.1cps	40	no
2.5cps	48	no
2.7cps	56	no
3.3cps	64	no
3.8cps	72	no
4.0cps	80	no
4.3cps	88	no
4.6cps	96	no
5.0cps	104	no
5.5cps	112	no
6.0cps	120	no
8.0cps	128	no
8.6cps	136	no
9.2cps	144	no
10.0cps	152	yes
10.9cps	160	no
12.0cps	168	no
13.3cps	176	no
15.0cps	184	no
16.0cps	192	no
17.1cps	200	no
18.5cps	208	no
20.0cps	216	no
21.8cps	224	no
24.0cps	232	no
26.7cps	240	no
30.0cps	248	no

Data Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Data Bits	rs232:keyboard:RS232_DATABITS	255

setting

name	value	default
5	0	no
6	1	no
7	2	no
8	3	yes

Parity

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Parity	rs232:keyboard:RS232_PARITY	255

setting

name	value	default
None	0	yes
Odd	1	no
Even	2	no
Mark	3	no
Space	4	no

Stop Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stop Bits	rs232:keyboard:RS232_STOPBITS	255

setting

name	value	default
0	0	no
1	1	yes
1.5	2	no
2	3	no

TX Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
TX Baud	rs232:keyboard:RS232_TXBAUD	255

setting

name	value	default
50	14	no
75	15	no
110	0	no
134.5	16	no
150	1	no
200	17	no
300	2	no
600	3	no
1200	4	no
1800	18	no
2000	19	no
2400	5	no
3600	20	no
4800	6	no
7200	21	no
9600	7	yes
14400	8	no
19200	9	no
28800	10	no
38400	11	no
57600	12	no
111900	22	no
115200	13	no

dipswitch

Bit0

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bit0	P9	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	1	yes
Off	0	no

Bit1

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bit1	P9	2

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	2	yes
Off	0	no

Bit2

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bit2	P9	4

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	4	yes
Off	0	no

Bit3

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bit3	P9	8

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	8	yes
Off	0	no

Boot to Monitor

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Boot to Monitor	P9	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	16	yes
