AN1x Control Synthesizer - mame (0286) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
an1x	yamaha/yman1x.cpp		no	no	no	yes	AN1x Control Synthesizer	1997	Yamaha

snap

AN1x Control Synthesizer png snap

AN1x Control Synthesizer jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
an1x	2451	29/12/2025 11:31:15	1280	386	96	96	0	Format24bppRgb	305:MAME 0.233 (Jul 1 2021)	6e0f6c2621dfdd4b3d369f93776ba37a935f32b0

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
lcd:screen	svg	0	1280	386	60.000000	29644800	1280	0	1280	386	0	386	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
yamaha an1x 1.04.ic2	1048576	f03b8c30	778b669a450660f2b15cc385f156dc6676c437f1	program	0	good	no
xn668a00.bin	4096			pks	0	nodump	no
xt113b00.ic9	131072			vop3	0	nodump	no
xt113b00.ic1	131072			vop3s	0	nodump	no

chip

type	tag	name	clock
cpu	maincpu	Hitachi H8/3002	16000000
cpu	pks	Hitachi HD6305V0	8000000
audio	speaker	Speaker

device_ref

tag	name
:maincpu	h83002
:maincpu:intc	h8h_intc
:maincpu:adc	h8_adc_3337
:maincpu:dma	h8h_dma
:maincpu:dma:0	h8h_dma_channel
:maincpu:dma:1	h8h_dma_channel
:maincpu:port4	h8_digital_port
:maincpu:port6	h8_digital_port
:maincpu:port7	h8_digital_port
:maincpu:port8	h8_digital_port
:maincpu:port9	h8_digital_port
:maincpu:porta	h8_digital_port
:maincpu:portb	h8_digital_port
:maincpu:timer16	h8_timer16
:maincpu:timer16:0	h8h_timer16_channel
:maincpu:timer16:1	h8h_timer16_channel
:maincpu:timer16:2	h8h_timer16_channel
:maincpu:timer16:3	h8h_timer16_channel
:maincpu:timer16:4	h8h_timer16_channel
:maincpu:sci0	h8_sci
:maincpu:sci1	h8_sci
:maincpu:watchdog	h8_watchdog
:nvram	nvram
:pks	hd6305v0
:lcd	mulcd
:lcd:screen	screen
:speaker	speaker
:meg	meg

sound

channels
1

input

players	coins	service	tilt
0		no	no
