Arcadia (NMK) - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
arcadian	nmk/nmk16.cpp		no	no	no	yes	Arcadia (NMK)	1994	NMK

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	270	384	224	56.205036	8000000	512	28	412	278	16	240	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
arcadia.3	524288	8b46d609	793870d74c9d7d04c53d898610c682b2dc90d0af	maincpu	0	good	no
rhp94099.2	131072	fe01ece1	c469fb79f2774089848c814f92ddd3c9e384050f	audiocpu	0	good	no
arcadia.1	131072	1c2c4008	583d74a0a44519a7050b1d8490011ff60222f466	fgtile	0	good	no
rhp94099.4	2097152	076eee7b	7c315fe33d0fcd92e0ce2f274996c8059228b005	bgtile	0	good	no
rhp94099.8	2097152	49892f07	2f5d20cd193cffcba9041aa11d6665adebeffffa	sprites	0	good	no
rhp94099.9	2097152	ea2e47f0	97dfa8f95f27b36deb5ce1c80e3d727bad24e52b	sprites	200000	good	no
rhp94099.10	2097152	512cb839	4a2c5ac88e4bf8a6f07c703277c4d33e649fd192	sprites	400000	good	no
rhp94099.6	2097152	f1a80e5a	218bd7b0c3d8b283bf96b95bf888228810699370	oki1	40000	good	no
rhp94099.7	2097152	0d99547e	2d9630bd55d27010f9d1d2dbdbd07ac265e8ebe6	oki1	240000	good	no
rhp94099.5	2097152	515eba93	c35cb5f31f4bc7327be5777624af168f9fb364a5	oki2	40000	good	no
rhp94099.6	2097152	f1a80e5a	218bd7b0c3d8b283bf96b95bf888228810699370	oki2	240000	good	no
prom1.u19	256	4299776e	683d14d2ace14965f0fcfe0f0540c1b77d2cece5	proms	0	good	no
prom2.u53	256	e6ead349	6d81b1c0233580aa48f9718bade42d640e5ef3dd	proms	100	good	no
prom3.u60	256	304f98c6	8dfd9bf719087ec30c83efe95c4561666c7d1801	proms	200	good	no
prom1.u19	256	4299776e	683d14d2ace14965f0fcfe0f0540c1b77d2cece5	htiming	0	good	no
prom2.u53	256	e6ead349	6d81b1c0233580aa48f9718bade42d640e5ef3dd	vtiming	0	good	no
prom3.u60	256	304f98c6	8dfd9bf719087ec30c83efe95c4561666c7d1801	color	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	14000000
cpu	audiocpu	Toshiba TMP90841	8000000
audio	mono	Speaker
audio	ymsnd	YM2203 OPN	1500000
audio	oki1	OKI MSM6295 ADPCM	4000000
audio	oki2	OKI MSM6295 ADPCM	4000000

device_ref

name
m68000
timer
tmp90841
screen
nmk16spr
gfxdecode
palette
speaker
generic_latch_8
generic_latch_8
ym2203
okim6295
okim6295
nmk112

sound

channels
1

input

players	coins	service	tilt
2	2	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	3	8	no
joy	2	3	8	no

port, analog

port_tag	analog_masks
:DSW1
:DSW2
:IN0
:IN1

dipswitch

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	DSW1	1

location

name	number	inverted
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Language

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Language	DSW1	2

location

name	number	inverted
SW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Japanese	2	no
English	0	yes

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW1	4

location

name	number	inverted
SW1	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW1	8

location

name	number	inverted
SW1	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	8	no

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW1	48

location

name	number	inverted
SW1	4	no
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Easy	16	no
Normal	48	yes
Hard	32	no
Hardest	0	no

Lives

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Lives	DSW1	192

location

name	number	inverted
SW1	2	no
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1	0	no
2	64	no
3	192	yes
4	128	no

Flip Screen

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flip Screen	DSW2	1

location

name	number	inverted
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW2	2

location

name	number	inverted
SW2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	2	yes

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSW2	28

location

name	number	inverted
SW2	6	no
SW2	5	no
SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
4 Coins/1 Credit	16	no
3 Coins/1 Credit	8	no
2 Coins/1 Credit	24	no
1 Coin/1 Credit	28	yes
1 Coin/2 Credits	12	no
1 Coin/3 Credits	20	no
1 Coin/4 Credits	4	no
Free Play	0	no

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSW2	224

location

name	number	inverted
SW2	3	no
SW2	2	no
SW2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
4 Coins/1 Credit	128	no
3 Coins/1 Credit	64	no
2 Coins/1 Credit	192	no
1 Coin/1 Credit	224	yes
1 Coin/2 Credits	96	no
1 Coin/3 Credits	160	no
1 Coin/4 Credits	32	no
Free Play	0	no
