Area 88 (Japan) - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
area88	capcom/cps1.cpp		no	no	no	yes	Area 88 (Japan)	1989	Capcom	unsquad	unsquad

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	384	224	59.637405	8000000	512	64	448	262	16	240	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge
ar_36.12f	131072	65030392	d9dea5cfde28345716b0e519ee033c475be0454b	maincpu	0	good	no
ar_42.12h	131072	c48170de	e968522dbdd217dd8e4cd6aaeaef801c63488c1d	maincpu	1	good	no
ar_37.13f	131072	33e9694b	90db3052ac2ff859ede8473dd13e0f5be148590c	maincpu	40000	good	no	aru_31.12f
ar_43.13h	131072	7cc8fb9e	f70118d1a368fd4795d9953c55d283305d1f9630	maincpu	40001	good	no	aru_36.12h
ar_34.10f	131072	f6e80386	462c1e9981b733df03e4d084df2d1fc58cf2022c	maincpu	80000	good	no
ar_40.10h	131072	be36c145	9ada7ac7361ff8871e2ae61f75e4e5d98936cdc3	maincpu	80001	good	no
ar_35.11f	131072	86d98ff3	18137974fb7812b45f0d93e584ed14d0af2e6a3e	maincpu	c0000	good	no
ar_41.11h	131072	758893d3	1245bfd35b0f12bd701cd28c9ce2e85e166a4de2	maincpu	c0001	good	no
ar_09.4b	131072	db9376f8	501fc5543c66509f8fc1075c128fb01606ced2ad	gfx	0	good	no
ar_01.4a	131072	392151b4	ba3c69d852f750b43d8b4b2b58fcb7977cc0e5de	gfx	1	good	no
ar_13.9b	131072	81436481	85ceba63382959f7084bacb6aedcef80ddd8ad6b	gfx	2	good	no
ar_05.9a	131072	e246ed9f	aaaad5c81bf7c4ec4b2339fd8f0364096c86e903	gfx	3	good	no
ar_24.5e	131072	9cd6e2a3	186e756af496b0fb5b65cf7a106fe32c78d542c9	gfx	4	good	no
ar_17.5c	131072	0b8e0df4	ac8ab79e7237b72df9f42292a0c58aa56effe3a1	gfx	5	good	no
ar_38.8h	131072	8b9e75b9	eeeaa8f84167f7e8127b90318f052fe5e00c36ac	gfx	6	good	no
ar_32.8f	131072	db6acdcf	5842e29a0e29b4869b2c34a5f47f64c1a1f4609a	gfx	7	good	no
ar_10.5b	131072	4219b622	ecfc47687b466893b9c8587224830d600c754d17	gfx	100000	good	no
ar_02.5a	131072	bac5dec5	e69f5c4e5c07db46f088d3eabfd394e7d639fea0	gfx	100001	good	no
ar_14.10b	131072	e6bae179	31af958dedce5fcc1a7c159f96af4a3a1a4651fb	gfx	100002	good	no
ar_06.10a	131072	c8f04223	c96eba0ce53e8505668dc646344e5b2456d60546	gfx	100003	good	no
ar_25.7e	131072	15ccf981	2dd7a2d573089aa70b33586d6d9e6b8d816bd28e	gfx	100004	good	no
ar_18.7c	131072	9336db6a	1704d6f0de08ed283c26ee0bcbb82a838060fe70	gfx	100005	good	no
ar_39.9h	131072	9b8e1363	f830834305248446235cc6b17b17f7f0dd6baa03	gfx	100006	good	no
ar_33.9f	131072	3968f4b5	42722c61c4b514b15f1594fdad688375e2c51e71	gfx	100007	good	no
ar_23.13c	65536	f3dd1367	09eef72e862ac6b1a5cce5a45938b45bf4e456ad	audiocpu	0	good	no	ar_09.12b
ar_30.12e	131072	584b43a9	7820815c8c67d484baf2fdad7e55d8c14b98b860	oki	0	good	no	aru_18.11c
buf1	279	eb122de7	b26b5bfe258e3e184f069719f9fd008d6b8f6b9b	aboardplds	0	good	no	buf1
ioa1	279	59c7ee3b	fbb887c5b4f5cb8df77cec710eaac2985bc482a6	aboardplds	0	good	no	ioa1
prg1	279	f1129744	a5300f301c1a08a7da768f0773fa0fe3f683b237	aboardplds	0	good	no	prg1
rom1	279	41dc73b9	7d4c9f1693c821fbf84e32dd6ef62ddf14967845	aboardplds	0	good	no	rom1
sou1	279	84f4b2fe	dcc9e86cc36316fe42eace02d6df75d08bc8bb6d	aboardplds	0	good	no	sou1
ar22b.1a	279	f1db9030	85a6eefb93e7bf7c7d3980737365a425c5324c08	bboardplds	0	good	no
lwio.12c	279	ad52b90c	f0fd6aeea515ee449320fe15684e6b3ab7f97bf4	bboardplds	0	good	no	lwio.11e

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	10000000
cpu	audiocpu	Zilog Z80	3579545
audio	mono	Speaker
audio	2151	YM2151 OPM	3579545
audio	oki	OKI MSM6295 ADPCM	1000000

device_ref

name
m68000
z80
screen
gfxdecode
palette
speaker
generic_latch_8
generic_latch_8
ym2151
okim6295

sound

channels
1

input

players	coins	service	tilt
2	2	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	3	8	no
joy	2	3	8	no

port, analog

port_tag	analog_masks
:DSWA
:DSWB
:DSWC
:IN0
:IN1

dipswitch

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSWA	7

location

name	number	inverted
SW(A)	1	no
SW(A)	2	no
SW(A)	3	no

value

name	value	default
4 Coins/1 Credit	1	no
3 Coins/1 Credit	2	no
2 Coins/1 Credit	3	no
2 Coins/1 Credit (1 to continue)	0	no
1 Coin/1 Credit	7	yes
1 Coin/2 Credits	6	no
1 Coin/3 Credits	5	no
1 Coin/4 Credits	4	no

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSWA	56

location

name	number	inverted
SW(A)	4	no
SW(A)	5	no
SW(A)	6	no

value

name	value	default
4 Coins/1 Credit	8	no
3 Coins/1 Credit	16	no
2 Coins/1 Credit	24	no
2 Coins/1 Credit (1 to continue)	0	no
1 Coin/1 Credit	56	yes
1 Coin/2 Credits	48	no
1 Coin/3 Credits	40	no
1 Coin/4 Credits	32	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSWA	64

location

name	number	inverted
SW(A)	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSWA	128

location

name	number	inverted
SW(A)	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSWB	7

location

name	number	inverted
SW(B)	1	no
SW(B)	2	no
SW(B)	3	no

value

name	value	default
0 (Easiest)	7	no
1	6	no
2	5	no
3 (Normal)	4	yes
4	3	no
5	2	no
6	1	no
7 (Hardest)	0	no

Damage

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Damage	DSWB	24

location

name	number	inverted
SW(B)	4	no
SW(B)	5	no

value

name	value	default
Small	16	no
Normal	24	yes
Big	8	no
Biggest	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSWB	32

location

name	number	inverted
SW(B)	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSWB	64

location

name	number	inverted
SW(B)	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSWB	128

location

name	number	inverted
SW(B)	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSWC	1

location

name	number	inverted
SW(C)	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSWC	2

location

name	number	inverted
SW(C)	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Free Play

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Free Play	DSWC	4

location

name	number	inverted
SW(C)	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Freeze

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Freeze	DSWC	8

location

name	number	inverted
SW(C)	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Flip Screen

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flip Screen	DSWC	16

location

name	number	inverted
SW(C)	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSWC	32

location

name	number	inverted
SW(C)	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	no
On	0	yes

Allow Continue

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Allow Continue	DSWC	64

location

name	number	inverted
SW(C)	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	64	no
Yes	0	yes

Game Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Game Mode	DSWC	128

location

name	number	inverted
SW(C)	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Game	128	yes
Test	0	no
