Arm Wrestling - mame (0278) machine

MAME: 0278 - Released: 2025-06-29T00:16:39 - Machines: 48574 - rom: 362783 - disk: 1374

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
armwrest	nintendo/punchout.cpp		no	no	no	yes	Arm Wrestling	1985	Nintendo

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
top	raster	0	256	224	60.000000								no
bottom	raster	0	256	224	60.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
chv1-c.8l	8192	b09764c1	2f32acd689ef70ec81fe958c7a604855ae39cf5e	maincpu	0	good	no
chv1-c.8k	8192	0e147ff7	7ea8b7b5562d9432c6cace2ee13377f91543975d	maincpu	2000	good	no
chv1-c.8j	8192	e7365289	9d4ed5ce73b93c3917b1411ed902974e2a4f3d35	maincpu	4000	good	no
chv1-c.8h	8192	a2118eec	93e1b19819352f88888b3caf67ed27cd50f866a9	maincpu	6000	good	no
chpv-c.8f	16384	664a07c4	a8a049be5beeab3940079465fb0c80382f3860f0	maincpu	8000	good	no
chp1-c.4k	8192	cb6ef376	503dbcc1b18a497311bf129689d5650860bf96c7	audiocpu	e000	good	no
chpv-b.2e	16384	8b45f365	15fadccc9afe26672fbbb8eaeaa7d3ee70bcb056	gfx1	0	good	no
chpv-b.2d	16384	b1a2850c	e3aec428bb52443921fb7ceb5eb21b5f9ee9edcb	gfx1	4000	good	no
chpv-b.2m	16384	19245b37	711e263d487661afca09f731e9333a84eb8d1541	gfx2	0	good	no
chpv-b.2l	16384	46797941	e21fcec8e19702f9765205a4dc89105b4e98dcdd	gfx2	4000	good	no
chpv-b.2k	8192	de189b00	62b38d5f95bb4f0a0d04947c7c2031e07f95cbe4	gfx2	a000	good	no
chv1-v.2r	16384	d86056d9	decedf6b54e5990ff14d8049791b2d06c33ae71b	gfx3	0	good	no
chv1-v.2t	16384	5ad77059	05a1c7957982fa695bca62a05dc593c7913ccd7f	gfx3	4000	good	no
chv1-v.2v	16384	a0fd7338	afd8d78661c3b7149f4c491ba930a8ce66d29977	gfx3	c000	good	no
chv1-v.3r	16384	690e26fb	6c20daabf5db633482b288c8020130a80cc939fc	gfx3	10000	good	no
chv1-v.3t	16384	ea5d7759	4d72d7b602455349be4a9cbf34127952aa2a99ea	gfx3	14000	good	no
chv1-v.3v	16384	ceb37c05	9d0e3d52e018901c2f26a9de7aa9858b106487d3	gfx3	1c000	good	no
chv1-v.4r	16384	e291cba0	a03ff7eea3a7a841000b67a8baeca6e82e8496ef	gfx3	20000	good	no
chv1-v.4t	16384	e01f3b59	9f47507094e03735adaf033f3b99e17dd9dfd5d0	gfx3	24000	good	no
chv1-v.6p	8192	d834e142	e7d654145b695147b744af2284173f90749fbf0e	gfx4	0	good	no
chv1-v.8p	8192	a2f531db	c9be180fbc608135c892e8ee396b138f058edf24	gfx4	8000	good	no
chpv-b.7b	512	df6fdeb3	7766d420cb95377104e26d96afddc83b67553c2f	proms	0	good	no
chpv-b.7c	512	b1da5f42	55e744da70bbaa855cb1403eef028771a97578a1	proms	200	good	no
chpv-b.7d	512	4ede813e	6603465dae7d869c483d66768fab16f282caaa8b	proms	400	good	no
chpv-b.4b	512	9d51416e	ae933786c5fc19311144b2094305b4253dc8b75b	proms	600	good	no
chpv-b.4c	512	b8a25795	8e41baa796fd8f00739a95b2e07066d68193bd76	proms	800	good	no
chpv-b.4d	512	474fc3b1	9cda1d1626285310524d048b60b1cf89e197a26d	proms	a00	good	no
chv1-b.3c	256	c3f92ea2	1a82cca1b9a8d9bd4a1d121d8c131a7d0be554bc	proms	c00	good	no
chpv-v.2d	256	71dc0d48	dd6609f547d74887f520d7e71a1a00317ff181d0	proms	d00	good	no
chv1-c.6p	16384	31b52896	395f59ac38b46042f79e9224ac6bc7d3dc299906	vlm	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Zilog Z80	4000000
cpu	audiocpu	Ricoh RP2A03	1789772
audio	audiocpu	Ricoh RP2A03	1789772
audio	audiocpu:nesapu	RP2A03 APU	1789772
audio	speaker	Speaker
audio	vlm	Sanyo VLM5030	3579545

device_ref

name
z80
rp2a03
apu2a03
nvram
ls259
gfxdecode
palette
screen
screen
speaker
generic_latch_8
generic_latch_8
vlm5030

sound

channels
1

input

players	coins	service	tilt
1	2	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy		1	3 (half4)	no

port, analog

port_tag	analog_masks
:DSW1
:DSW2
:IN0
:IN1

dipswitch

Coinage 1

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage 1	DSW1	15

location

name	number	inverted
SW1	1	yes
SW1	2	yes
SW1	3	yes
SW1	4	yes

value

name	value	default
0000	0	yes
0001	1	no
0010	2	no
0011	3	no
0100	4	no
0101	5	no
0110	6	no
0111	7	no
1000	8	no
1001	9	no
1010	10	no
1011	11	no
1100	12	no
1101	13	no
1110	14	no
1111	15	no

Coin Slots

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin Slots	DSW1	64

location

name	number	inverted
R18	1	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1	64	no
2	0	yes

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW1	128

location

name	number	inverted
R19	1	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	128	no

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW2	3

location

name	number	inverted
SW2	1	yes
SW2	2	yes

value

name	value	default
Easy	0	yes
Medium	1	no
Hard	2	no
Hardest	3	no

Coinage 2

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage 2	DSW2	60

location

name	number	inverted
SW2	3	yes
SW2	4	yes
SW2	5	yes
SW2	6	yes

value

name	value	default
0000	0	yes
0001	4	no
0010	8	no
0011	12	no
0100	16	no
0101	20	no
0110	24	no
0111	28	no
1000	32	no
1001	36	no
1010	40	no
1011	44	no
1100	48	no
1101	52	no
1110	56	no
1111	60	no

Rematches

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Rematches	DSW2	64

location

name	number	inverted
SW2	7	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
3	64	no
7	0	yes

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	DSW2	128

location

name	number	inverted
SW2	8	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	128	no
