ASR-X - mame (0286) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
asrx	ensoniq/esqasr.cpp		no	no	no	yes	ASR-X	1997	Ensoniq

snap

ASR-X png snap

ASR-X jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
asrx	8931	26/02/2026 21:13:08	640	480	96	96	0	Format24bppRgb	305:MAME 0.286 (mame0286)	44309384e8bbc094190c775368f5e0460b95d22a

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
asr267lo.bin	524288	7408d441	0113f84b6d224bf1423ad62c173f32a0c95ca715	maincpu	1	good	no
asr267hi.bin	524288	7df14ea7	895b99013c0f924edb52612eb93c3e6babb9f053	maincpu	0	good	no

chip

type	tag	name	clock
cpu	maincpu	MC68340	16000000
cpu	esp	Ensoniq ES5510	10000000
audio	speaker	Speaker
audio	pump	Ensoniq 5505/5506 to 5510 interface	31250
audio	ensoniq	Ensoniq ES5506	16000000

device_ref

tag	name
:maincpu	mc68340
:maincpu:serial	mc68340sermod
:maincpu:serial:cha	duart_channel
:maincpu:serial:chb	duart_channel
:maincpu:timer1	mc68340timmod
:maincpu:timer2	mc68340timmod
:esp	es5510
:sq1vfd	esq2x40_sq1
:speaker	speaker
:pump	esq_5505_5510_pump
:ensoniq	es5506

sound

channels
1

input

players	coins	service	tilt
0		no	no
