Atlantis (rev. 3) - mame (0286) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
atlantip	pinball/by6803.cpp	genpin	no	no	yes	yes	Atlantis (rev. 3)	1989	Bally

snap

Atlantis (rev. 3) png snap

Atlantis (rev. 3) jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
atlantip	16968	19/03/2026 20:30:49	640	480	96	96	0	Format24bppRgb	305:MAME 0.286 (mame0286)	1d38b099680cea6f4df65a1f407c42aa70eb6289

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	supported	yes	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
u26_cpu.rom	16384	b98491e1	b867e2b24e93c4ee19169fe93c0ebfe0c1e2fc25	maincpu	8000	good	no
u27_cpu.rom	16384	8ea2b4db	df55a9fb70d1cabad51dc2b089af7904a823e1d8	maincpu	c000	good	no
u4_snd.rom	32768	6a48b588	c58dbfd920c279d7b9d2de8558d73c687b29ce9c	s11sound:audiocpu	0	good	no
u19_snd.rom	32768	1387467c	8b3dd6c2fc94cfebc1879795532c651cda202846	s11sound:audiocpu	10000	good	no
u20_snd.rom	32768	d5a6a773	30807e03655d2249c801007350bfb228a2e8a0a4	s11sound:audiocpu	20000	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC6803	3579545
audio	mechvol	Speaker
audio	samples	Samples
audio	mono	Speaker

device_ref

tag	name
:maincpu	m6803
:nvram	nvram
:mechvol	speaker
:samples	samples
:pia0	pia6821
:timer_z	timer
:pia1	pia6821
:mono	speaker

sample

name
bumper
chime1
chime2
chime3
chime4
hole
knocker
sling
coinin
outhole
kickback
drop_target_reset
coil_coinlockout_engage
coil_coinlockout_release
relay_engage
relay_release
solenoid_engage
solenoid_release

sound

channels
2

feature

type	status	overall
sound	unemulated

input

players	coins	service	tilt
1	3	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
keypad		46		no

port, analog

port_tag	analog_masks
:TEST
:X0
:X1
:X2
:X3
:X4
:X5
