name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
att4425	att/att4425.cpp		no	no	no	yes	AT&T Teletype 4425	1983	AT&T

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	720	351	50.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
455773-1.bin	8192	d216515b	6e098c35f8fe6be4f28a577a43145c92972041b1	maincpu	0	good	no
455774-1.bin	8192	636c069a	c00648eae44c574b983de6a0ba6cf74a7f07b098	maincpu	2000	good	no
456305-1.bin	8192	43cbf638	939569e65957370ab8e60d4f90179373b72b9573	maincpu	4000	good	no
456306-1.bin	8192	e4f2b0f1	c80c2b7219b313b4924834b0a9d1d42536d1ae63	maincpu	6000	good	no
char.bin	8192	cca962cc	201d97b954f782ceae8d17a08fb9a1c4d5ae7a58	chargen	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Zilog Z80	4000000

device_ref

name
z80
screen
gfxdecode
palette
z80ctc
z80ctc_channel
z80ctc_channel
z80ctc_channel
z80ctc_channel
z80sio
z80sio_channel
z80sio_channel
rs232
null_modem
bitbanger
rs232
serial_printer
printer_image
clock
i8251
rs232
serial_keyboard
clock
ram

sound

channels
0

feature

type	status	overall
sound	unemulated

ramoption

name	default
32K	yes
