AWS-200 - mame (0286) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
aws200	skeleton/aws.cpp		no	no	no	yes	AWS-200	1981	Convergent Technologies

snap

AWS-200 png snap

AWS-200 jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
aws200	940	22/01/2026 13:30:38	720	319	96	96	0	Format24bppRgb	305:MAME 0.284 (mame0284)	11d29dc2a3980288a23f12f37bb3a98d5de6ad76

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	720	320	60.000000	13824000	720	0	720	320	0	320	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
72-00077_l.bin	4096	87ca4912	c4f7ecda8d007bb212166cfa3cdf494da3966ca9	bios	0	good	no		boot60
a-27077_l.bin	4096	36e6d6d3	95e8026dca5f52eed6af956073c0e46703b42171	bios	0	good	no		dti12
a-16310_l.bin	4096	d96487c3	1fe1b8fd82ea97fc93763bd3688392c43284ae5f	bios	0	good	no		memext
a-17653_l.bin	4096	e104b328	c537ac50ff8bed4ae09b9b172dd624327faf2590	bios	0	good	no		a17653
72-00098_r.bin	4096	e74c12a7	0cde785aad1bdad5b44c41ba5b05bfb0eb0b1092	fontrom	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Intel 8086	8000000
cpu	dmac	Intel 8257 DMA Controller	3000000

device_ref

tag	name
:maincpu	i8086
:dmac	i8257
:pit	pit8253
:pit:counter0	pit_counter
:pit:counter1	pit_counter
:pit:counter2	pit_counter
:screen	screen
:crtc	i8275
:cpu_serial	upd7201
:cpu_serial:cha	i8274_channel
:cpu_serial:chb	i8274_channel
:keyboard	rs232
:keyboard:aws	aws_kb
:serial_clock	clock

biosset

name	description	default
boot60	CPU Bootstrap v6.0	no
dti12	DTI 1.2	no
memext	MemExt	no
a17653	A-17653	no

sound

channels
0

feature

type	status	overall
sound	unemulated

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
keyboard		97		no

port, analog

port_tag	analog_masks
:keyboard:aws:RS232_DATABITS
:keyboard:aws:RS232_PARITY
:keyboard:aws:RS232_STOPBITS
:keyboard:aws:RS232_TXBAUD
:keyboard:aws:kbd_row0
:keyboard:aws:kbd_row1
:keyboard:aws:kbd_row10
:keyboard:aws:kbd_row11
:keyboard:aws:kbd_row12
:keyboard:aws:kbd_row13
:keyboard:aws:kbd_row14
:keyboard:aws:kbd_row15
:keyboard:aws:kbd_row2
:keyboard:aws:kbd_row3
:keyboard:aws:kbd_row4
:keyboard:aws:kbd_row5
:keyboard:aws:kbd_row6
:keyboard:aws:kbd_row7
:keyboard:aws:kbd_row8
:keyboard:aws:kbd_row9

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
keyboard	aws	aws_kb	yes

configuration

Data Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Data Bits	keyboard:aws:RS232_DATABITS	255

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
8	3	yes

Parity

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Parity	keyboard:aws:RS232_PARITY	255

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
None	0	yes

Stop Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stop Bits	keyboard:aws:RS232_STOPBITS	255

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1	1	yes

TX Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
TX Baud	keyboard:aws:RS232_TXBAUD	255

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1200	4	yes

clones

name	description
aws220	AWS-220
