Battletoads - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
btoads	rare/btoads.cpp		no	no	no	yes	Battletoads	1994	Rare / Electronic Arts

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	512	224	60.797665	10000000	640	0	512	257	0	224	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
btc0-p0.u120	4194304	0dfd1e35	733a0a4235bebd598c600f187ed2628f28cf9bd0	maincpu	0	good	no
btc0-p1.u121	4194304	df7487e1	67151b900767bb2653b5261a98c81ff8827222c3	maincpu	2	good	no
bt.u102	32768	a90b911a	6ec25161e68df1c9870d48cc2b1f85cd1a49aba9	audiocpu	0	good	no
btc0-s.u109	2097152	d9612ddb	f186dfb013e81abf81ba8ac5dc7eb731c1ad82b6	bsmt	0	good	no
u10.bin	343	b1144178	15fb047adee4125e9fcf04171e0a502655e0a3d8	plds	0	good	no
u11.bin	343	7c6beb96	2f19d21889dd765b344ad7d257ea7c244baebec2	plds	0	good	no
u57.bin	343	be355a56	975238bb1ea8fef14458d6f264a82aa77ecf865d	plds	0	good	no
u58.bin	343	41ed339c	5853c805a902e6d12c979958d878d1cefd6908cc	plds	0	good	no
u90.bin	343	a0d0c3f1	47464c2ef9fadbba933df27767f377e0c29158aa	plds	0	good	no
u144.bin	343	8597017f	003d7b5de57e48f831ab211e2783fff338ce2f32	plds	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Texas Instruments TMS34020	32000000
cpu	audiocpu	Zilog Z80	6000000
cpu	bsmt:bsmt2000	Texas Instruments TMS32015	24000000
audio	speaker	Speaker
audio	bsmt	BSMT2000	24000000

device_ref

name
tms34020
z80
nvram
tlc34076
screen
speaker
bsmt2000
tms32015

sound

channels
1

input

players	coins	service	tilt
3	3	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	2	8	no
joy	2	2	8	no
joy	3	2	8	no

port, analog

port_tag	analog_masks
:P1
:P2
:P3
:SPECIAL
:SW1
:UNK

dipswitch

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	SW1	1

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	no
On	0	yes

Stereo

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stereo	SW1	2

location

name	number	inverted
SW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	no
On	0	yes

Common Coin Mech

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Common Coin Mech	SW1	4

location

name	number	inverted
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	no
On	0	yes

Three Players

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Three Players	SW1	8

location

name	number	inverted
SW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Free Play

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Free Play	SW1	16

location

name	number	inverted
SW1	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Blood Free Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Blood Free Mode	SW1	32

location

name	number	inverted
SW1	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Credit Retention

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Credit Retention	SW1	64

location

name	number	inverted
SW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	SW1	128

location

name	number	inverted
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no
