Cashcade (JPM) (SYSTEM5 VIDEO) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
cashcade	jpm/jpmsys5.cpp		no	no	no	yes	Cashcade (JPM) (SYSTEM5 VIDEO)	199?	JPM

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	508	254	57.784763	10000000	676	80	588	256	0	254	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
cashcade_2_1.bin	65536	7672953c	c1a2639ab6b830c971c2533d837404ae5f5aa535	maincpu	0	good	no
cashcade_2_2.bin	65536	8ce8cd66	4eb00af6a0260496950d04fdcc1d3d976868ce3e	maincpu	1	good	no
cashcade_2_3.bin	65536	a4caddd1	074e4aa870c3d28c2f120936ef6928c3b5e14301	maincpu	20000	good	no
cashcade_2_4.bin	65536	b0f595e8	5ca12839b87d092504d8b7cc579b8f1b2406cea1	maincpu	20001	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	8000000
audio	mono	Speaker
audio	upd7759	NEC uPD7759	640000
audio	ym2413	YM2413 OPLL	4000000

device_ref

name
m68000
ipt_merge_any_hi
bacta_datalogger
acia6850
acia6850
acia6850
clock
clock
nvram
s16lf01
pia6821
ptm6840
speaker
upd7759
ym2413
screen
tms34061
palette

sound

channels
1

feature

type	status	overall
sound	unemulated

input

players	coins	service	tilt
1	4	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
lightgun		1		no	0	255	45	15

port, analog

port_tag	analog_masks
:COINS
:DIRECT
:DSW
:TOUCH_PUSH
:TOUCH_X	255
:TOUCH_Y	255

dipswitch

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DIRECT	8

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DIRECT	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DIRECT	32

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Reset

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Reset	DIRECT	64

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DIRECT	128

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	no
On	0	yes

Change state to enter test

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Change state to enter test	DSW	1

location

name	number	inverted
SW2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	2

location

name	number	inverted
SW2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Alarm

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Alarm	DSW	4

location

name	number	inverted
SW2	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Discontinue alarm when jam is cleared	4	yes
Continue alarm until back door open	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	8

location

name	number	inverted
SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	16

location

name	number	inverted
SW2	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	32

location

name	number	inverted
SW2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Payout Percentage

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Payout Percentage	DSW	192

location

name	number	inverted
SW2	7	no
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
50%	0	yes
45%	128	no
40%	64	no
30%	192	no
