Catt (Japan) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
catt	misc/mcatadv.cpp		no	no	no	yes	Catt (Japan)	1993	Wintechno	mcatadv	mcatadv

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	320	224	60.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no	preliminary

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
catt-u30.bin	524288	8c921e1e	2fdaa9b743e1731f3cfe9d8334f1b759cf46855d	maincpu	0	good	no
catt-u29.bin	524288	e725af6d	78c08fa5744a6a953e13c0ff39736ccd4875fb72	maincpu	1	good	no
u9.bin	131072	fda05171	2c69292573ec35034572fa824c0cae2839d23919	soundcpu	0	good	no	u9.bin
mca-u82.bin	1048576	5f01d746	11b241456e15299912ee365eedb8f9d5e5ca875d	sprdata	0	good	no	mca-u82.bin
mca-u83.bin	1048576	4e1be5a6	cb19aad42dba54d6a4a33859f27254c2a3271e8c	sprdata	1	good	no	mca-u83.bin
u84.bin	1048576	843fd624	2e16d8a909fe9447da37a87428bff0734af59a00	sprdata	200000	good	no
u85.bin	1048576	5ee7b628	feedc212ed4893d784dc6b3361930b9199c6876d	sprdata	200001	good	no
mca-u86e	524288	017bf1da	f6446a7219275c0eff62129f59fdfa3a6a3e06c8	sprdata	400000	good	no	mca-u86e
mca-u87e	524288	bc9dc9b9	f525c9f994d5107752aa4d3a499ee376ec75f42b	sprdata	400001	good	no	mca-u87e
u58.bin	1048576	73c9343a	9efdddbad6244c1ed267bd954563ab43a1017c96	bg0	0	good	no
mca-u60.bin	1048576	c8942614	244fccb9abbb04e33839dd2cd0e2de430819a18c	bg1	0	good	no	mca-u60.bin
mca-u61.bin	1048576	51af66c9	1055cf78ea286f02003b0d1bf08c2d7829b36f90	bg1	100000	good	no	mca-u61.bin
mca-u100	524288	b273f1b0	39318fe2aaf2792b85426ec6791b3360ac964de3	bg1	200000	good	no	mca-u100
u53.bin	1048576	99f2a624	799e8e40e8bdcc8fa4cd763a366cc32473038a49	ymsnd:adpcma	0	good	no
peel18cv8.u1	341			plds	0	nodump	no
gal16v8a.u10	279			plds	200	nodump	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	16000000
cpu	soundcpu	Zilog Z80	4000000
audio	mono	Speaker
audio	ymsnd	YM2610 OPNB	8000000

device_ref

name
m68000
z80
screen
gfxdecode
palette
tmap038
tmap038
buffered_spriteram16
buffered_spriteram16
watchdog
speaker
generic_latch_8
generic_latch_8
ym2610

sound

channels
1

input

players	coins	service	tilt
2	2	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	3	8	no
joy	2	2	8	no

port, analog

port_tag	analog_masks
:DSW1
:DSW2
:P1
:P2

dipswitch

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW1	256

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	256	yes

Flip Screen

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flip Screen	DSW1	512

location

name	number	inverted
SW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	512	yes
On	0	no

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	DSW1	1024

location

name	number	inverted
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1024	yes
On	0	no

Coin Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin Mode	DSW1	2048

location

name	number	inverted
SW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Mode 1	2048	yes
Mode 2	0	no

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSW1	12288

location

name	number	inverted
SW1	5	no
SW1	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
4 Coins/1 Credit	0	no	DSW1	2048	eq	0
3 Coins/1 Credit	4096	no	DSW1	2048	eq	0
2 Coins/1 Credit	4096	no	DSW1	2048	eq	2048
1 Coin/1 Credit	12288	yes
2 Coins/3 Credits	0	no	DSW1	2048	eq	2048
1 Coin/2 Credits	8192	no	DSW1	2048	eq	2048
1 Coin/4 Credits	8192	no	DSW1	2048	eq	0

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSW1	49152

location

name	number	inverted
SW1	7	no
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
4 Coins/1 Credit	0	no	DSW1	2048	eq	0
3 Coins/1 Credit	16384	no	DSW1	2048	eq	0
2 Coins/1 Credit	16384	no	DSW1	2048	eq	2048
1 Coin/1 Credit	49152	yes
2 Coins/3 Credits	0	no	DSW1	2048	eq	2048
1 Coin/2 Credits	32768	no	DSW1	2048	eq	2048
1 Coin/4 Credits	32768	no	DSW1	2048	eq	0

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW2	768

location

name	number	inverted
SW2	1	no
SW2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Easy	512	no
Normal	768	yes
Hard	256	no
Hardest	0	no

Lives

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Lives	DSW2	3072

location

name	number	inverted
SW2	3	no
SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
2	1024	no
3	3072	yes
4	2048	no
5	0	no

Energy

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Energy	DSW2	12288

location

name	number	inverted
SW2	5	no
SW2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
3	12288	yes
4	8192	no
5	4096	no
8	0	no

Cabinet

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cabinet	DSW2	49152

location

name	number	inverted
SW2	7	no
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Upright 1 Player	16384	no
Upright 2 Players	49152	yes
Upright 2 Players	0	no
Cocktail	32768	no
