CC2-Schachzwerg (German) - mame (0286) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
cc2schach	elektor/avrmax.cpp		no	no	no	yes	CC2-Schachzwerg (German)	2009	Elektor	atm18mcc	atm18mcc

snap

CC2-Schachzwerg (German) png snap

CC2-Schachzwerg (German) jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
cc2schach	21499	29/12/2025 11:31:17	640	288	96	96	0	Format24bppRgb	305:MAME 0.247.0 (Aug 31 2022)	f7a5b529d36222dc68f270e7d9be20bba560bdb8

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	lcd	0	121	37	60.000000	268620	121	0	121	37	0	37	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	yes	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
avrmax_cc2_de-v1.0.bin	8192	64cfc646	4c371ea9f48c8745cf5f5bcf10973838e239e564	maincpu	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Atmel ATmega88	16000000

device_ref

tag	name
:maincpu	atmega88
:screen	screen
:lcd	hd44780u

sound

channels
0

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
keypad		11		no

port, analog

port_tag	analog_masks
:IN.0
:IN.1
:IN.2
:IN.3
