Caribbean Gold II (3XF5182H04, US) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
cgold2a	aristocrat/aristmk4.cpp	3bagfull	no	no	no	yes	Caribbean Gold II (3XF5182H04, US)	1995	Aristocrat	cgold2	cgold2

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	304	216	60.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge
2vas004.u59	8192	84226547	df9c2c01a7ac4d930c06a8c4863853ddb1a2adbe	maincpu	2000	good	no	2vas004.u59
3xf5182h04.u87	8192	070a02b2	872621275e51c5dca371861a9b9f3038f0dbc8aa	maincpu	6000	good	no
3xf5182.u86	32768	5ac1d424	42bb8b5eb163a04054621bbcba5cf8203a661baf	maincpu	8000	good	no
5vlsh076.u20	8192	6e81d96c	90877e2e7400e9820b0d3e99380f7452069bef07	tile_gfx	0	good	no	5vlsh076.u20
5vlsh076.u21	8192	8bf50f7c	17705de695d43fa4fa6f1e7afc5c19ecf6f75e35	tile_gfx	2000	good	no	5vlsh076.u21
5vlsh076.u22	8192	ec08e24b	9dce6952e92c8d10a1722ec0a394b93be6bc7cea	tile_gfx	4000	good	no	5vlsh076.u22
5vlsh076.u45	8192	442599ff	073c8354b0e0895092ce5c45c8cdd2d1b46e5fe3	tile_gfx	6000	good	no	5vlsh076.u45
5vlsh076.u46	8192	9580c2c2	8a010fb9e349c066e1af53ed9aa659dbf7dbf17e	tile_gfx	8000	good	no	5vlsh076.u46
5vlsh076.u47	8192	f3cb845a	288f7fe991bb60194a9ef9e8c9b2b18ebbd3b49c	tile_gfx	a000	good	no	5vlsh076.u47
1cm12.u71	512	918cb0ab	2ec37abae2ecae2f0f525daf6fafd03789fca20b	proms	0	baddump	no	1cm12.u71

chip

type	tag	name	clock
cpu	maincpu	Motorola MC6809E	1500000
audio	mono	Speaker
audio	ay1	AY-3-8910A PSG	1500000
audio	ay2	AY-3-8910A PSG	1500000
audio	samples	Samples
