CMI IIx - mame (0287) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
cmi2x	fairlight/cmi.cpp		no	no	no	yes	CMI IIx	1983	Fairlight

snap

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
cmi2x	553	29/12/2025 11:31:18	512	256	96	96	0	Format24bppRgb	305:MAME 0.177 (Aug 31 2016)	a1493b1d73ac5de3ddaef75b1e1973f209b357c9

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	512	256	50.810620	10380000	672	0	512	304	0	256	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
q9f0mrk1.bin	2048	16f195cc	fcc4be370ba60ae5a4145c36cdbdc97a7be91f8f	q133	0	good	no
f8lmrk5.bin	2048	cfc7967f	0695cc757cf6fab35414dc068dd2a3e50084685c	q133	800	good	no
mon1110e.bin	8192	476f7d5f	9af21e0072eaa58cae42947c20dca05d35dfadd0	smptemidi	0	good	no
mon1110o.bin	8192	150c8ebe	bbd371bebac29628f60537832d0587e83323ad01	smptemidi	1	good	no
dqfc911.bin	2048	5bc38db2	bd840e19e51a336e669c40b9e18cdaf6b3c62a8a	qfc9	0	good	no
brom.bin	256	3f730d15	095df6eee95b9ad6418b910fb5d2ae46913750f9	proms	0	good	no
srom.bin	256	a1b4b71b	6ea96480af2f1e43967f209218a74fc17972ce0e	proms	100	good	no
mrom.bin	256	dc26642c	49b207ff80d1b055c3b855dc954129846c49bfe3	proms	200	good	no
timrom.bin	256	a426e4a2	6b7ea128c730f5afd1042820ccd55bbda683afd8	proms	300	good	no
wrom.bin	32	68a9e17f	c3364a37a8d19a1882d7910add1c1df9b63ee32c	proms	400	good	no

chip

type	tag	name	clock
cpu	maincpu1	Motorola MC6809E	1005250
cpu	maincpu2	Motorola MC6809E	1005250
cpu	smptemidi	Motorola MC68000	10000000
cpu	cmi07cpu	Motorola MC6809E	1005250
cpu	mkbd:kbdcpu	Motorola MC6802	4000000
cpu	alphakeys:kbdcpu	Motorola MC6802	3840000
audio	wd1791:0:8dsdd:flopsndout	Speaker
audio	wd1791:0:8dsdd:floppysound	Floppy sound	44100
audio	wd1791:1:8dsdd:flopsndout	Speaker
audio	wd1791:1:8dsdd:floppysound	Floppy sound	44100
audio	mono	Speaker
audio	cmi01a_0	Fairlight CMI-01A Channel Card	2010500
audio	cmi01a_1	Fairlight CMI-01A Channel Card	2010500
audio	cmi01a_2	Fairlight CMI-01A Channel Card	2010500
audio	cmi01a_3	Fairlight CMI-01A Channel Card	2010500
audio	cmi01a_4	Fairlight CMI-01A Channel Card	2010500
audio	cmi01a_5	Fairlight CMI-01A Channel Card	2010500
audio	cmi01a_6	Fairlight CMI-01A Channel Card	2010500
audio	cmi01a_7	Fairlight CMI-01A Channel Card	2010500

device_ref

tag	name
:maincpu1	mc6809e
:maincpu2	mc6809e
:cpu1_periphs	address_map_bank
:cpu2_periphs	address_map_bank
:cpulatch	ls259
:smptemidi	m68000
:cmi07cpu	mc6809e
:screen	screen
:palette	palette
:msm5832	msm5832
:i8214_1	i8214
:i8214_2	i8214
:i8214_3	i8214
:maincpu1_irq_merger	ipt_merge_any_hi
:maincpu2_irq0_merger	ipt_merge_any_hi
:q133_pia_1	pia6821
:rtc_irq_merger	ipt_merge_any_hi
:q133_pia_2	pia6821
:q133_ptm	ptm6840
:q219_pia	pia6821
:q219_ptm	ptm6840
:cmi02_pia_1	pia6821
:cmi02_pia_2	pia6821
:cmi02_ptm	ptm6840
:q133_acia_clock	clock
:q133_acia_0	mos6551
:q133_acia_0:clock	clock
:q133_acia_1	mos6551
:q133_acia_1:clock	clock
:q133_acia_2	mos6551
:q133_acia_2:clock	clock
:q133_acia_3	mos6551
:q133_acia_3:clock	clock
:q133_acia_irq	ipt_merge_any_hi
:mkbd	cmi_mkbd
:mkbd:kbdcpu	m6802
:mkbd:cmi10_pia_u20	pia6821
:mkbd:cmi10_pia_u21	pia6821
:mkbd:acia_clock	clock
:mkbd:acia_cmi	acia6850
:mkbd:acia_kbd	acia6850
:mkbd:dp1	dl1416t
:mkbd:dp2	dl1416t
:mkbd:dp3	dl1416t
:alphakeys	cmi_ankbd
:alphakeys:kbdcpu	m6802
:alphakeys:irqs	ipt_merge_any_hi
:alphakeys:pia	pia6821
:alphakeys:pia_clock	clock
:cmi07_ptm	ptm6840
:midi_ptm_1	ptm6840
:midi_ptm_2	ptm6840
:midi_clock	clock
:midi_acia_1	acia6850
:midi_out_1	midi_port
:midi_out_1:midiout	midiout_port
:midi_out_1:midiout:midioutimg	midiout
:midi_acia_2	acia6850
:midi_out_2	midi_port
:midi_out_2:midiout	midiout_port
:midi_out_2:midiout:midioutimg	midiout
:midi_acia_3	acia6850
:midi_out_3	midi_port
:midi_out_3:midiout	midiout_port
:midi_out_3:midiout:midioutimg	midiout
:midi_acia_4	acia6850
:midi_out_4	midi_port
:midi_out_4:midiout	midiout_port
:midi_out_4:midiout:midioutimg	midiout
:midi_in_1	midi_port
:midi_in_1:midiin	midiin_port
:midi_in_1:midiin:midiinimg	midiin
:midi_in_2	midi_port
:midi_in_2:midiin	midiin_port
:midi_in_2:midiin:midiinimg	midiin
:midi_in_3	midi_port
:midi_in_3:midiin	midiin_port
:midi_in_3:midiin:midiinimg	midiin
:midi_ptm_irq	ipt_merge_any_hi
:midi_acia_irq	ipt_merge_any_hi
:wd1791	fd1791
:wd1791:0	floppy_connector
:wd1791:0:8dsdd	floppy_8_dsdd
:wd1791:0:8dsdd:flopsndout	speaker
:wd1791:0:8dsdd:floppysound	flopsnd
:wd1791:1	floppy_connector
:wd1791:1:8dsdd	floppy_8_dsdd
:wd1791:1:8dsdd:flopsndout	speaker
:wd1791:1:8dsdd:floppysound	flopsnd
:mono	speaker
:cmi01a_0	cmi_01a
:cmi01a_0:cmi01a_pia_0	pia6821
:cmi01a_0:cmi01a_pia_1	pia6821
:cmi01a_0:cmi01a_ptm	ptm6840
:cmi01a_0:cmi01a_irq	ipt_merge_any_hi
:cmi01a_1	cmi_01a
:cmi01a_1:cmi01a_pia_0	pia6821
:cmi01a_1:cmi01a_pia_1	pia6821
:cmi01a_1:cmi01a_ptm	ptm6840
:cmi01a_1:cmi01a_irq	ipt_merge_any_hi
:cmi01a_2	cmi_01a
:cmi01a_2:cmi01a_pia_0	pia6821
:cmi01a_2:cmi01a_pia_1	pia6821
:cmi01a_2:cmi01a_ptm	ptm6840
:cmi01a_2:cmi01a_irq	ipt_merge_any_hi
:cmi01a_3	cmi_01a
:cmi01a_3:cmi01a_pia_0	pia6821
:cmi01a_3:cmi01a_pia_1	pia6821
:cmi01a_3:cmi01a_ptm	ptm6840
:cmi01a_3:cmi01a_irq	ipt_merge_any_hi
:cmi01a_4	cmi_01a
:cmi01a_4:cmi01a_pia_0	pia6821
:cmi01a_4:cmi01a_pia_1	pia6821
:cmi01a_4:cmi01a_ptm	ptm6840
:cmi01a_4:cmi01a_irq	ipt_merge_any_hi
:cmi01a_5	cmi_01a
:cmi01a_5:cmi01a_pia_0	pia6821
:cmi01a_5:cmi01a_pia_1	pia6821
:cmi01a_5:cmi01a_ptm	ptm6840
:cmi01a_5:cmi01a_irq	ipt_merge_any_hi
:cmi01a_6	cmi_01a
:cmi01a_6:cmi01a_pia_0	pia6821
:cmi01a_6:cmi01a_pia_1	pia6821
:cmi01a_6:cmi01a_ptm	ptm6840
:cmi01a_6:cmi01a_irq	ipt_merge_any_hi
:cmi01a_7	cmi_01a
:cmi01a_7:cmi01a_pia_0	pia6821
:cmi01a_7:cmi01a_pia_1	pia6821
:cmi01a_7:cmi01a_ptm	ptm6840
:cmi01a_7:cmi01a_irq	ipt_merge_any_hi

sound

channels
3

feature

type	status	overall
sound	unemulated

device, instance

type	tag	interface	name	briefname
midiout	midi_out_1:midiout:midioutimg		midiout1	mout1
midiout	midi_out_2:midiout:midioutimg		midiout2	mout2
midiout	midi_out_3:midiout:midioutimg		midiout3	mout3
midiout	midi_out_4:midiout:midioutimg		midiout4	mout4
midiin	midi_in_1:midiin:midiinimg		midiin1	min1
midiin	midi_in_2:midiin:midiinimg		midiin2	min2
midiin	midi_in_3:midiin:midiinimg		midiin3	min3
floppydisk	wd1791:0:8dsdd	floppy_8	floppydisk1	flop1
floppydisk	wd1791:1:8dsdd	floppy_8	floppydisk2	flop2

device, extension

type	tag	interface	extension_names
midiout	midi_out_1:midiout:midioutimg		mid
midiout	midi_out_2:midiout:midioutimg		mid
midiout	midi_out_3:midiout:midioutimg		mid
midiout	midi_out_4:midiout:midioutimg		mid
midiin	midi_in_1:midiin:midiinimg		mid, syx
midiin	midi_in_2:midiin:midiinimg		mid, syx
midiin	midi_in_3:midiin:midiinimg		mid, syx
floppydisk	wd1791:0:8dsdd	floppy_8	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk
floppydisk	wd1791:1:8dsdd	floppy_8	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk

input

players	coins	service	tilt
2		no	no

control

type	player	buttons	reverse	minimum	maximum	sensitivity	keydelta
lightgun	1	1	no	0	255	50
keyboard	1	62	no
pedal	2		no	0	128	100	50
keypad	2	16	no

port, analog

port_tag	analog_masks
:LP_TOUCH
:LP_X	65535
:LP_Y	65535
:alphakeys:OPTIONS
:alphakeys:ROW0
:alphakeys:ROW1
:alphakeys:ROW2
:alphakeys:ROW3
:alphakeys:ROW4
:alphakeys:ROW5
:alphakeys:ROW6
:alphakeys:ROW7
:midi_in_1:midiin:midiinimg:CFG
:midi_in_2:midiin:midiinimg:CFG
:midi_in_3:midiin:midiinimg:CFG
:mkbd:ANALOG	255
:mkbd:KEYPAD_A
:mkbd:KEYPAD_B
:mkbd:KEY_0_0
:mkbd:KEY_0_1
:mkbd:KEY_0_2
:mkbd:KEY_0_3
:mkbd:KEY_1_0
:mkbd:KEY_1_1
:mkbd:KEY_1_2
:mkbd:KEY_1_3
:mkbd:KEY_2_0
:mkbd:KEY_2_1
:mkbd:KEY_2_2
:mkbd:KEY_2_3

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
midi_out_1	midiout	midiout_port	yes
midi_out_2	midiout	midiout_port	yes
midi_out_3	midiout	midiout_port	yes
midi_out_4	midiout	midiout_port	yes
midi_in_1	midiin	midiin_port	yes
midi_in_2	midiin	midiin_port	yes
midi_in_3	midiin	midiin_port	yes
wd1791:0	8dssd	floppy_8_dssd	no
wd1791:0	8dsdd	floppy_8_dsdd	yes
wd1791:1	8dssd	floppy_8_dssd	no
wd1791:1	8dsdd	floppy_8_dsdd	yes

configuration

MIDI file mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
MIDI file mode	midi_in_1:midiin:midiinimg:CFG	255

setting

name	value	default
Multi	255	yes
Poly: Channel 1	0	no
Poly: Channel 2	1	no
Poly: Channel 3	2	no
Poly: Channel 4	3	no
Poly: Channel 5	4	no
Poly: Channel 6	5	no
Poly: Channel 7	6	no
Poly: Channel 8	7	no
Poly: Channel 9	8	no
Poly: Channel 10	9	no
Poly: Channel 11	10	no
Poly: Channel 12	11	no
Poly: Channel 13	12	no
Poly: Channel 14	13	no
Poly: Channel 15	14	no
Poly: Channel 16	15	no

MIDI file mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
MIDI file mode	midi_in_2:midiin:midiinimg:CFG	255

setting

name	value	default
Multi	255	yes
Poly: Channel 1	0	no
Poly: Channel 2	1	no
Poly: Channel 3	2	no
Poly: Channel 4	3	no
Poly: Channel 5	4	no
Poly: Channel 6	5	no
Poly: Channel 7	6	no
Poly: Channel 8	7	no
Poly: Channel 9	8	no
Poly: Channel 10	9	no
Poly: Channel 11	10	no
Poly: Channel 12	11	no
Poly: Channel 13	12	no
Poly: Channel 14	13	no
Poly: Channel 15	14	no
Poly: Channel 16	15	no

MIDI file mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
MIDI file mode	midi_in_3:midiin:midiinimg:CFG	255

setting

name	value	default
Multi	255	yes
Poly: Channel 1	0	no
Poly: Channel 2	1	no
Poly: Channel 3	2	no
Poly: Channel 4	3	no
Poly: Channel 5	4	no
Poly: Channel 6	5	no
Poly: Channel 7	6	no
Poly: Channel 8	7	no
Poly: Channel 9	8	no
Poly: Channel 10	9	no
Poly: Channel 11	10	no
Poly: Channel 12	11	no
Poly: Channel 13	12	no
Poly: Channel 14	13	no
Poly: Channel 15	14	no
Poly: Channel 16	15	no

dipswitch

Speed (baud)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Speed (baud)	alphakeys:OPTIONS	7

value

name	value	default
9600	0	yes
4800	1	no
2400	2	no
1200	3	no
600	4	no
300	5	no
150	6	no
110	7	no

Parity

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Parity	alphakeys:OPTIONS	48

value

name	value	default
Even	0	no
None, bit 7 is 0	16	no
Odd	32	yes
None, bit 7 is 1	48	no
