Constellation - mame (0287) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
const	novag/const.cpp		no	no	no	yes	Constellation	1983	Novag Industries / Intelligent Heuristic Programming

snap

Constellation png snap

Constellation jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
const	58857	29/12/2025 11:31:18	710	500	96	96	0	Format24bppRgb	305:MAME 0.212 (Jul 31 2019)	41e72a1ed193039eca590a6e042d304079db6bc3

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
8315_white	8192	76e6c97b	55645e08f9f1258366c29a4ea2033bb86d860227	maincpu	a000	good	no
8314_orange	8192	89395a86	4807f196fec70abdaabff5bfc479a64d5cf2b0ad	maincpu	e000	good	no

chip

type	tag	name	clock
cpu	maincpu	MOS Technology 6502	2000000
audio	mono	Speaker
audio	beeper	Beep	976

device_ref

tag	name
:maincpu	m6502
:irq_clock	clock
:board	sensorboard
:display	pwm_display
:mono	speaker
:beeper	beep

sound

channels
1

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
keypad		14		no

port, analog

port_tag	analog_masks
:IN.0
:IN.1
:IN.2
:IN.3
:IN.4
:IN.5
:IN.6
:IN.7
:board:BS_CHECK
:board:CONF
:board:RANK.1
:board:RANK.10
:board:RANK.11
:board:RANK.12
:board:RANK.13
:board:RANK.2
:board:RANK.3
:board:RANK.4
:board:RANK.5
:board:RANK.6
:board:RANK.7
:board:RANK.8
:board:RANK.9
:board:SPAWN
:board:SS_CHECK
:board:UI
:board:UI_CHECK

configuration

Remember Position

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Remember Position	board:CONF	3	UI_CHECK	4	ne	0

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	1	no
Yes	2	no
Auto	0	yes

Show Pieces

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Show Pieces	board:CONF	4	UI_CHECK	4	ne	0

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	4	no
Yes	0	yes

clones

name	description
const36	Constellation 3.6MHz (set 1)
const36a	Constellation 3.6MHz (set 2)
constq	Constellation Quattro
