Crystal Gal 2 (Japan 860620) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
crystal2	nichibutsu/nbmj8688.cpp		no	no	no	yes	Crystal Gal 2 (Japan 860620)	1986	Nichibutsu

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	512	224	60.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
cgl2_01.bin	16384	67673350	c7b9e5f0a9e073793db74304272c94657328cd92	maincpu	0	good	no
cgl2_02.bin	16384	79c599d8	e70cbb2b2b7867be81bc133bb4dbc19753578b7e	maincpu	4000	good	no
cgl2_03.bin	16384	c11987ed	69a7c252b28843437a06812213ad1d6de683aac3	maincpu	8000	good	no
cgl2_04.bin	16384	ae0b7df8	9ca74fd087d299195b06aa8ea811393e3f87b76f	maincpu	c000	good	no
cgl2_01s.bin	32768	99b982ea	0c9f76dd30d722bd359b24320fabb62944f6e841	gfx1	0	good	no
cgl2_01m.bin	32768	7c7a0416	2dade3d7c2045ba84ea4bddd21264a2d1fd328f3	gfx1	8000	good	no
cgl2_02m.bin	32768	8511ddcd	001f9cea0320eedb42736ed29c746642eec2b460	gfx1	10000	good	no
cgl2_03m.bin	32768	f594e3bc	96bb0b5397934038a7a57fce77f5ee0ca09a8992	gfx1	18000	good	no
cgl2_04m.bin	32768	01a6bf99	610b61259037a19ab01617dcc14089e45d3b3ee0	gfx1	20000	good	no
cgl2_05m.bin	32768	ee941bf6	97dc870100e33f9cf3a803ebf957540de63963b1	gfx1	28000	good	no
cgl2_06m.bin	32768	93a8bf3b	29648e1349909cb5a3416e688864d51503823872	gfx1	30000	good	no
cgl2_07m.bin	32768	b9626199	44c52a1362b6c6609e7c3442d3c651cfec7795fc	gfx1	38000	good	no
cgl2_08m.bin	32768	8a4d02c9	69c047cf480eb9edeee6d8fefc82e0273de15495	gfx1	40000	good	no
cgl2_09m.bin	32768	e0d58e86	474b577f24f82036c16304994f9fbec8fb07aa04	gfx1	48000	good	no
cgl2_02s.bin	32768	7e0ca2a5	90ea16a4557b2f3c87492d63e4fc7ce6cac561ba	gfx1	50000	good	no
cgl2_03s.bin	32768	78fc9502	bb3bae6d4a57818f349c915b8bf15424b3bdd241	gfx1	58000	good	no
cgl2_04s.bin	32768	c2140826	f8d8692cd3968f586f1bd37a292747ef00a493e0	gfx1	60000	good	no
cgl2_05s.bin	32768	257df5f3	df0f5f9859a90f6fc8171bb2cdc1bee9cdbf2c27	gfx1	68000	good	no
cgl2_06s.bin	32768	27da3e4d	fe0446af7eada1d937496e488422b5988e43bc2a	gfx1	70000	good	no
cgl2_07s.bin	32768	bd202788	85c8b80b019476942696ce2295167c6cf8e3afc3	gfx1	78000	good	no

chip

type	tag	name	clock
cpu	maincpu	Zilog Z80	5000000
audio	speaker	Speaker
audio	psg	AY-3-8910A PSG	1250000
audio	dac	8-Bit R-2R DAC

device_ref

name
z80
nb1413m3
nvram
screen
palette
speaker
ay8910
dac_8bit_r2r

sound

channels
1

input

players	coins	service	tilt
2	1	no	no

control

type	player	buttons	reverse
mahjong	1	26	no
gambling	1	1	no
mahjong	2	26	no

port, analog

port_tag	analog_masks
:DSWA
:DSWB
:KEY0
:KEY1
:KEY2
:KEY3
:KEY4
:KEY5
:KEY6
:KEY7
:KEY8
:KEY9
:SYSTEM

dipswitch

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSWA	15

location

name	number	inverted
DSWA	1	no
DSWA	2	no
DSWA	3	no
DSWA	4	no

value

name	value	default
1 (Easy)	13	no
2	10	no
3	9	no
4	8	no
5	7	no
6	6	no
7	5	yes
8	4	no
9 (Hard)	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWA	16

location

name	number	inverted
DSWA	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWA	32

location

name	number	inverted
DSWA	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWA	64

location

name	number	inverted
DSWA	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWA	128

location

name	number	inverted
DSWA	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Last Chance Count

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Last Chance Count	DSWB	3

location

name	number	inverted
DSWB	1	no
DSWB	2	no

value

name	value	default
0	3	no
3	2	yes
5	1	no
10	0	no

Sangen Rush

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Sangen Rush	DSWB	12

location

name	number	inverted
DSWB	3	no
DSWB	4	no

value

name	value	default
1	12	no
3	8	no
5	4	no
Unlimited	0	yes

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWB	16

location

name	number	inverted
DSWB	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWB	32

location

name	number	inverted
DSWB	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWB	64

location

name	number	inverted
DSWB	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSWB	128

location

name	number	inverted
DSWB	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	no
On	0	yes

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	SYSTEM	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no
