Cue Brick (Japan) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
cuebrickj	konami/twin16.cpp		no	no	no	yes	Cue Brick (Japan)	1989	Konami	cuebrick	cuebrick

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	304	224	60.606061	6144000	384	8	312	264	16	240	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
903_e05.6n	65536	8b556220	dbe24133e74018c4fe9332519394cbb882c4ed5a	maincpu	0	good	no
903_e04.4n	65536	bf9c7927	3a594b8846f7e6074ca54f8cd5fe2ba3b64ba740	maincpu	1	good	no
903_e09.6r	65536	2a77554d	53eee99737333c8c4bbb9c757fd12488b6c4d3d8	maincpu	20000	good	no
903_e08.4r	65536	c0a430c1	bef737f12e9a79781a4cd795ffc108899757901d	maincpu	20001	good	no
903_d07.10n	65536	fc0edce7	57e969a42c48a9464ec370d4605eaecb690d58ab	sub	0	good	no
903_d06.8n	65536	b2cef6fe	27d1d15f3a408e6166745cb6a159704a8cbb4584	sub	1	good	no
903_e13.10s	65536	4fb5fb80	3a59dae3846341289c31aa106684ebc45488ca45	sub	20000	good	no
903_e12.8s	65536	883e3097	fe0fa1a2881a67223d741c400bb8c1a0c67946c1	sub	20001	good	no
903_d03.10a	32768	455e855a	cfdd54a5071862653ee94c0455301f4a7245fbd8	audiocpu	0	good	no
903_e14.d8	16384	ddbebbd5	df532f19a08cabb28d693e4cd445c47c9e35e5ff	fixed	0	good	no
903_e11.10r	65536	5c41faf8	f9eee6a7b92d3b3aa4320747da6390310522a2cf	data	0	good	no
903_e10.8r	65536	417576d4	e84762743e3a1117b6ef7ea0b304877e4a719f75	data	1	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	9216000
cpu	sub	Motorola MC68000	9216000
cpu	audiocpu	Zilog Z80	3579545
audio	speaker	Speaker
audio	ymsnd	YM2151 OPM	3579545
audio	k007232	Konami 007232 PCM Controller	3579545
audio	upd	NEC uPD7759	640000

device_ref

name
m68000
m68000
z80
watchdog
buffered_spriteram16
screen
gfxdecode
palette
speaker
generic_latch_8
ym2151
k007232
upd7759
nvram

sound

channels
1

input

players	coins	service	tilt
2	2	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	3	4	no
joy	2	3	4	no

port, analog

port_tag	analog_masks
:DSW1
:DSW2
:DSW3
:P1
:P2
:P3
:SYSTEM

dipswitch

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSW1	15

location

name	number	inverted
SW1	1	no
SW1	2	no
SW1	3	no
SW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
4 Coins/1 Credit	2	no
3 Coins/1 Credit	5	no
2 Coins/1 Credit	8	no
3 Coins/2 Credits	4	no
4 Coins/3 Credits	1	no
1 Coin/1 Credit	15	yes
3 Coins/4 Credits	3	no
2 Coins/3 Credits	7	no
1 Coin/2 Credits	14	no
2 Coins/5 Credits	6	no
1 Coin/3 Credits	13	no
1 Coin/4 Credits	12	no
1 Coin/5 Credits	11	no
1 Coin/6 Credits	10	no
1 Coin/7 Credits	9	no
Free Play	0	no

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSW1	240

location

name	number	inverted
SW1	5	no
SW1	6	no
SW1	7	no
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
4 Coins/1 Credit	32	no
3 Coins/1 Credit	80	no
2 Coins/1 Credit	128	no
3 Coins/2 Credits	64	no
4 Coins/3 Credits	16	no
1 Coin/1 Credit	240	yes
3 Coins/4 Credits	48	no
2 Coins/3 Credits	112	no
1 Coin/2 Credits	224	no
2 Coins/5 Credits	96	no
1 Coin/3 Credits	208	no
1 Coin/4 Credits	192	no
1 Coin/5 Credits	176	no
1 Coin/6 Credits	160	no
1 Coin/7 Credits	144	no
Invalid	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW2	1

location

name	number	inverted
SW2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW2	2

location

name	number	inverted
SW2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Cabinet

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cabinet	DSW2	4

location

name	number	inverted
SW2	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Upright	0	yes
Cocktail	4	no

Machine Name

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Machine Name	DSW2	24

location

name	number	inverted
SW2	4	no
SW2	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
None	24	no
Lewis	16	no
Johnson	8	yes
George	0	no

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW2	96

location

name	number	inverted
SW2	6	no
SW2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Easy	96	no
Normal	64	yes
Difficult	32	no
Very Difficult	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW2	128

location

name	number	inverted
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	no
On	0	yes

Flip Screen

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flip Screen	DSW3	1

location

name	number	inverted
SW3	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Upright Controls

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Upright Controls	DSW3	2

location

name	number	inverted
SW3	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Single	2	yes
Dual	0	no

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	DSW3	4

location

name	number	inverted
SW3	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Stop Time

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stop Time	DSW3	8

location

name	number	inverted
SW3	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
200	8	yes
150	0	no
