DoDonPachi III (World, 2002.05.15 Master Ver) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
ddp3	igs/pgm.cpp		no	no	no	yes	DoDonPachi III (World, 2002.05.15 Master Ver)	2002	Cave (AMI license)

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	270	448	224	59.185606	10000000	640	0	448	264	0	224	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
imperfect	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
ddp3_bios.u37	524288	b3cc5c8f	02d9511cf71e4a0d6ca8fd9a1ef2c79b0d001824	maincpu	0	good	no
ddp3_v101_16m.u36	2097152	fba2180e	59c1a76243e587c07215c8a76649401ef0bff7c7	maincpu	100000	good	no
ddp3_igs027a.bin	16384			prot	0	nodump	no
pgm_t01s.rom	2097152	1a7123a0	cc567f577bfbf45427b54d6695b11b74f2578af3	igs023	0	good	no
cave_t04401w064.u19	8388608	3a95f19c	fd3c47cf0b8b1e20c6bec4be68a089fc8bbf4dbe	igs023	180000	good	no
cave_a04401w064.u7	8388608	ed229794	1cf1863495a18c7c7d277a9be43ec116b00960b0	igs023:sprcol	0	good	no
cave_a04402w064.u8	8388608	752167b0	c33c3398dd8e479c9d5bd348924958a6aecbf0fc	igs023:sprcol	800000	good	no
cave_b04401w064.u1	8388608	17731c9d	0e0aa0ec01035323985ac8e08228a0fd6edf6689	igs023:sprmask	0	good	no
pgm_m01s.rom	2097152	45ae7159	d3ed3ff3464557fd0df6b069b2e431528b0ebfa8	ics	0	good	no
cave_m04401b032.u17	4194304	5a0dbd76	06ab202f6bd5ebfb35b9d8cc7a8fb83ec8840659	ics	400000	good	no
ddp3_defaults.nv	131072	571e96c0	348940c77ca348213331b85b9b1d3aabb96a528a	sram	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	20000000
cpu	soundcpu	Zilog Z80	8467200
cpu	prot	ARM7 (little)	20000000
audio	mono	Speaker
audio	ics	ICS2115 WaveFront Synthesizer	33868800

device_ref

name
m68000
timer
z80
nvram
v3021
screen
palette
speaker
generic_latch_8
generic_latch_8
generic_latch_8
igs023
ics2115
arm7_le

sound

channels
1

feature

type	status	overall
sound	imperfect

input

players	coins	service	tilt
2	2	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	3	8	no
joy	2	3	8	no

port, analog

port_tag	analog_masks
:DSW
:P1P2
:P3P4
:Region
:Service

dipswitch

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	DSW	1

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	2

location

name	number	inverted
SW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	4

location

name	number	inverted
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	8

location

name	number	inverted
SW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	16

location

name	number	inverted
SW1	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	32

location

name	number	inverted
SW1	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	64

location

name	number	inverted
SW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	128

location

name	number	inverted
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no
