Desert Breaker (World) (FD1094 317-0196) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
desertbr	sega/segas18.cpp		no	no	no	yes	Desert Breaker (World) (FD1094 317-0196)	1992	Sega

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	270	320	224	57.230000	5128036	342	0	320	262	0	224	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
epr-14802.a4	524288	9ab93cbc	a8d0013e17519c26c6ba7d28ec73e22ea5bde0e9	maincpu	0	good	no
epr-14902.a6	524288	6724e7b1	540c8bb7e848488dead81ca58f3bece45a87e611	maincpu	1	good	no
epr-14793.a5	524288	dc9d7af3	1fc1fedc1a4beed94cece268d0bb4bf62eeb407c	maincpu	100000	good	no
epr-14795.a7	524288	7e5bf7d9	32ac68ee423a34e0f1bedc8765e03f40e01c3af1	maincpu	100001	good	no
317-0196.key	8192	cb942262	7ad7cd3df887c6e6435d74784cb12ce016acd0da	maincpu:key	0	good	no
mpr-14781.c1	1048576	c4f7d7aa	3c69dd7a26efccd7111ef33dfa6e8b738095c0bf	tiles	0	good	no
mpr-14782.c2	1048576	ccc98d05	b89594bbfff45e3b4fe433aeeaf8b4073c2cabb5	tiles	100000	good	no
mpr-14783.c3	1048576	ef202bec	b557092f8a3e1c9889d34588344c6dd2c6f06731	tiles	200000	good	no
mpr-14788.c10	1048576	b5b05536	f8fde7ebca38c0a6f6a864c17771aa155e6fc30d	sprites	1	good	no
mpr-14796.a10	1048576	c033220a	279d3ef62b41d2c6a18ce1217a549402a874638b	sprites	0	good	no
mpr-14789.c11	1048576	0f9bcb97	c15ab3ece596c54e1c4d8e8a755473609334e8ba	sprites	200001	good	no
mpr-14797.a11	1048576	4c301cc9	8aea8af0b078b81d1054331b273568b1b903531b	sprites	200000	good	no
mpr-14790.c12	1048576	6a07ac27	0558b662c7965c5b74cbc552423194a8facbc092	sprites	400001	good	no
mpr-14798.a12	1048576	50634625	f4baaebdb1f850e92ca865e103fbca68cdb0de0f	sprites	400000	good	no
mpr-14791.c13	1048576	a4ae352b	dc814e1c2e167e191cd43fa554ff8ee974d47152	sprites	600001	good	no
mpr-14799.a13	1048576	aeb7b025	9ce2a9a46176a110c8d2e77deb3d8b9b69b902fa	sprites	600000	good	no
epr-14787.c7	262144	cc6feec7	31cc243178b98681a52500a485d74ed9e1274888	soundcpu	0	good	no
mpr-14786.c6	524288	cc8349f2	9f00d8ea372b70ba44a90dab497deadcc5be3dab	soundcpu	80000	good	no
mpr-14785.c5	524288	7babba13	190cd9ea0f73272e0df34bbdfd8e0035f9e9b0b0	soundcpu	100000	good	no
mpr-14784.c4	524288	073878e4	eff08080d06a16fccf4876e42b389fef599cceba	soundcpu	180000	good	no

chip

type	tag	name	clock
cpu	maincpu	Hitachi FD1094 Encrypted CPU	10000000
cpu	soundcpu	Zilog Z80	8000000
audio	gen_vdp	Sega 315-5313 Megadrive VDP	15000000
audio	gen_vdp:snsnd	Sega VDP PSG	1000000
audio	mono	Speaker
audio	ym1	YM3438 OPN2C	8000000
audio	ym2	YM3438 OPN2C	8000000
audio	rfsnd	Ricoh RF5C68	10000000

device_ref

name
fd1094
z80
nvram
sega_315_5195
315_5296
sega315_5313
palette
segapsg
palette
palette
palette
timer
screen
gfxdecode
palette
sega_sys16b_sprite
segaic16_video
speaker
ym3438
ym3438
rf5c68

sound

channels
1

input

players	coins	service	tilt
3	3	yes	no

control

type	player	buttons	ways	reverse
joy	1	3	8	no
joy	2	3	8	no
joy	3	3	8	no

port, analog

port_tag	analog_masks
:COINAGE
:DSW
:P1
:P2
:P3
:SERVICE

dipswitch

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	COINAGE	15

location

name	number	inverted
SW1	1	no
SW1	2	no
SW1	3	no
SW1	4	no

value

name	value	default
4 Coins/1 Credit	7	no
3 Coins/1 Credit	8	no
2 Coins/1 Credit	9	no
2 Coins/1 Credit, 5/3, 6/4	5	no
2 Coins/1 Credit, 4/3	4	no
1 Coin/1 Credit	15	yes
1 Coin/1 Credit, 5/6	3	no
1 Coin/1 Credit, 4/5	2	no
1 Coin/1 Credit, 2/3	1	no
2 Coins/3 Credits	6	no
1 Coin/2 Credits	14	no
1 Coin/3 Credits	13	no
1 Coin/4 Credits	12	no
1 Coin/5 Credits	11	no
1 Coin/6 Credits	10	no
Free Play (if Coin B too) or 1/1	0	no

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	COINAGE	240

location

name	number	inverted
SW1	5	no
SW1	6	no
SW1	7	no
SW1	8	no

value

name	value	default
4 Coins/1 Credit	112	no
3 Coins/1 Credit	128	no
2 Coins/1 Credit	144	no
2 Coins/1 Credit, 5/3, 6/4	80	no
2 Coins/1 Credit, 4/3	64	no
1 Coin/1 Credit	240	yes
1 Coin/1 Credit, 5/6	48	no
1 Coin/1 Credit, 4/5	32	no
1 Coin/1 Credit, 2/3	16	no
2 Coins/3 Credits	96	no
1 Coin/2 Credits	224	no
1 Coin/3 Credits	208	no
1 Coin/4 Credits	192	no
1 Coin/5 Credits	176	no
1 Coin/6 Credits	160	no
Free Play (if Coin A too) or 1/1	0	no

Credits to Start

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Credits to Start	DSW	1

location

name	number	inverted
SW2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1	1	yes
2	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW	2

location

name	number	inverted
SW2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	no
On	0	yes

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	4

location

name	number	inverted
SW2	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Play Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Play Mode	DSW	8

location

name	number	inverted
SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
2 players	0	no
3 players	8	yes

Coin Chute

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin Chute	DSW	16

location

name	number	inverted
SW2	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Common	16	yes
Individual	0	no

Start Button

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Start Button	DSW	32

location

name	number	inverted
SW2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Use	32	yes
Unused	0	no

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW	192

location

name	number	inverted
SW2	7	no
SW2	8	no

value

name	value	default
Hard	64	no
Easy	128	no
Normal	192	yes
Hardest	0	no
