Dimension 68000 - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
dim68k	microcraft/dim68k.cpp		no	no	no	yes	Dimension 68000	1984	Micro Craft

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	640	224	57.276390	14318181	896	0	640	279	0	224	no

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	supported	no	no	no	no

name	size	crc	sha1	region	offset	status	optional
mc103e.bin	4096	4730c902	5c4bb79ad22def721a22eb63dd05e0391c8082be	bootrom	1	good	no
mc104.bin	4096	14b04575	43e15d9ebe1c9c1bf1bcfc1be3899a49e6748200	bootrom	0	good	no
mc105e.bin	4096	7a09daa8	844bfa579293d7c3442fcbfa21bda75fff930394	chargen	0	good	no
mc106.bin	256	11530d8a	e3eae266535383bcaee2d84d7bed6052d40e4e4a	cop6512	0	good	no
mc107.bin	256	966db11b	3c3105ac842602d8e01b0f924152fd672a85f00c	cop6512	100	good	no
mc108.bin	1024	687f9b0a	ed9f1265b25f89f6d3cf8cd0a7b0fb73cb129f9f	cop6512	200	good	no
mc109.bin	512	4a857f98	9f2bbc2171fc49f65aa798c9cd7799a26afd2ddf	cop6512	600	good	no
mc110.bin	256	e207b457	a8987ba3d1bbdb3d8b3b11cec90c532ff09e762e	cop6512	800	good	no
mc111.bin	32	6a380057	6522a7b3e0af9db14a6ed04d4eec3ee6e44c2dab	copz80	0	good	no
mc112.bin	256	dfd4cdbb	a7831d415943fa86c417066807038bccbabb2573	cop8086	0	good	no
mc113.bin	239	594bdf05	36db911a27d930e023fa12683e86e9eecfffdba6	cop8086	100	good	no
mc102.bin	250	38e2abac	0d7e730b46fc162764c69c51dea3bbe8337b1a7d	mb	0	good	no
mc101.bin	250	caffb3a0	36f5140b306565794c4d856e0c20589b8f2a37f4	mb	100	good	no

type	tag	name	clock
cpu	maincpu	Motorola MC68000	7159090
cpu	keyboard:mcu	Intel 8048	4752000
audio	mono	Speaker
audio	speaker	Filtered DAC
audio	fdc:0:525qd:flopsndout	Speaker
audio	fdc:0:525qd:floppysound	Floppy sound	44100
audio	fdc:1:525qd:flopsndout	Speaker
audio	fdc:1:525qd:floppysound	Floppy sound	44100

tag	name	status	filter
flop_list	dim68k	original

channels
3

type	tag	interface	fixed_image	mandatory	name	briefname
floppydisk	fdc:0:525qd	floppy_5_25			floppydisk1	flop1
floppydisk	fdc:1:525qd	floppy_5_25			floppydisk2	flop2

type	tag	interface	fixed_image	mandatory	extension_names
floppydisk	fdc:0:525qd	floppy_5_25			mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk
floppydisk	fdc:1:525qd	floppy_5_25			mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk

players	coins	service	tilt
2		no	no

type	player	buttons	reverse	minimum	maximum	sensitivity	keydelta
stick	1	2	no	1	255	100	1
keyboard	1	84	no
stick	2	2	no	1	255	100	1

slot_name	slotoption_name	slotoption_devname	slotoption_default
fdc:0	525qd	floppy_525_qd	yes
fdc:1	525qd	floppy_525_qd	yes
gamectrl	mssw_pad	mssw_pad	no
gamectrl	magnum6_pad	magnum6_pad	no
gamectrl	basic_joy	pc_basic_joy	yes
rs232	terminal	serial_terminal	no
rs232	sunkbd	sunkbd_adaptor	no
rs232	dec_loopback	dec_rs232_loopback	no
rs232	ie15	ie15_terminal	no
rs232	null_modem	null_modem	no
rs232	keyboard	serial_keyboard	no
rs232	patch	rs232_patch_box	no
rs232	swtpc8212	swtpc8212_terminal	no
rs232	printer	serial_printer	no
rs232	scorpion	scorpion_ic	no
rs232	loopback	rs232_loopback	no
rs232	mockingboard	mockingboardd	no
rs232	msystems_mouse	rs232_mouse_hle_msystems	no
rs232	nss_tvi	nss_tvinterface	no
rs232	rs232_sync_io	rs232_sync_io	no
rs232	pty	pseudo_terminal	no
rs232	rs_printer	rs_serial_printer	no
