Diamond Heart Plus (v18.0) - mame (0287) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
dmndhrtp	skeleton/cle68k.cpp		no	no	no	yes	Diamond Heart Plus (v18.0)	2001	LSE

snap

Diamond Heart Plus (v18.0) png snap

Diamond Heart Plus (v18.0) jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
dmndhrtp	20954	30/01/2026 10:36:25	512	256	96	96	0	Format24bppRgb	305:MAME 0.285 (mame0285)	d7f3aed7b6bca37b455e038e6fb48705bb3cf256

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	512	256	60.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
8.u8	262144	6fe1a75a	373eab66823a5e06bc00fab0ba541a20c9db9505	maincpu	0	good	no
3.u3	262144	89440d16	f81c6188a073794f4dd214e45200d8c60569dc03	maincpu	1	good	no
diamond_heart_v20_u51.u51	4096			mcu	0	nodump	no
11_13ba.u10	524288	f664cf59	cd10fb43562dfec5481994fe612f1bbef1b168b8	tiles	0	good	no
11_52b.u11	524288	c0a28638	02b348ccf982f486716e394da7a0b7334c7028c2	tiles	1	good	no
m27c2001.u33	262144	63b0bc97	12adb70a8283c6fec10e2221f1216a7fbfc99355	oki	0	good	no
palce20v8h-15pc-4.pl4	343			plds	0	nodump	no
palce20v8h-15pc-4.pl5	343			plds	200	nodump	no
palce20v8h-15pc-4.pl6	343			plds	400	nodump	no
palce20v8h-25pc-4.pl7	343			plds	600	nodump	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	12000000
audio	mono	Speaker
audio	oki	OKI MSM6295 ADPCM	1000000

device_ref

tag	name
:maincpu	m68000
:screen	screen
:gfxdecode	gfxdecode
:palette	palette
:ramdac0	ramdac
:ramdac1	ramdac
:mono	speaker
:oki	okim6295

sound

channels
1

input

players	coins	service	tilt
1	1	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
gambling		3		no

port, analog

port_tag	analog_masks
:DSW1
:DSW2
:DSW3
:IN0
:IN1

dipswitch

Coinage

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage	DSW1	7

location

name	number	inverted
SW1	1	no
SW1	2	no
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1 Coin/1 Credit	7	yes
1 Coin/2 Credits	6	no
1 Coin/4 Credits	5	no
1 Coin/5 Credits	4	no
1 Coin/8 Credits	3	no
1 Coin/10 Credits	2	no
1 Coin/20 Credits	1	no
1 Coin/25 Credits	0	no

Key In Ratio

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Key In Ratio	DSW1	24

location

name	number	inverted
SW1	4	no
SW1	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Coin x5	24	yes
Coin x10	16	no
Coin x25	8	no
Coin x50	0	no

Coin In Limit

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin In Limit	DSW1	96

location

name	number	inverted
SW1	6	no
SW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1000	96	yes
5000	64	no
10000	32	no
20000	0	no

Key Out

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Key Out	DSW1	128

location

name	number	inverted
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Bet Max

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bet Max	DSW1	1792

location

name	number	inverted
SW2	1	no
SW2	2	no
SW2	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
10	1792	yes
16	1536	no
32	1280	no
40	1024	no
64	768	no
64 (duplicate)	512	no
64 (duplicate)	256	no
64 (duplicate)	0	no

Bet Min

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bet Min	DSW1	14336

location

name	number	inverted
SW2	4	no
SW2	5	no
SW2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1	14336	yes
8	12288	no
10	10240	no
16	8192	no
32	6144	no
40	4096	no
64	2048	no
64 (duplicate)	0	no

Card Kind

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Card Kind	DSW1	16384

location

name	number	inverted
SW2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Normal Card	16384	yes
Symbol Card	0	no

Card 7

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Card 7	DSW1	32768

location

name	number	inverted
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Lost	32768	yes
Even	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW2	1

location

name	number	inverted
SW3	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	no
On	0	yes

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW2	2

location

name	number	inverted
SW3	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW2	4

location

name	number	inverted
SW3	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Credit Limit

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Credit Limit	DSW2	56

location

name	number	inverted
SW3	4	no
SW3	5	no
SW3	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
5000	48	no
10000	40	no
20000	32	no
30000	24	no
40000	16	no
50000	8	no
100000	0	no
Unlimited	56	yes

Pool Min.

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Pool Min.	DSW2	64

location

name	number	inverted
SW3	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
5000	64	yes
10000	0	no

Pay Out Device Kind

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Pay Out Device Kind	DSW2	128

location

name	number	inverted
SW3	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Hopper	128	yes
Ticket	0	no

Payout Ratio

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Payout Ratio	DSW2	1792

location

name	number	inverted
SW4	1	no
SW4	2	no
SW4	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
82%	1792	yes
84%	1536	no
86%	1280	no
88%	1024	no
90%	768	no
92%	512	no
94%	256	no
96%	0	no

Double Probability

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Double Probability	DSW2	6144

location

name	number	inverted
SW4	4	no
SW4	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Easy	6144	yes
Medium	4096	no
Difficult	2048	no
Difficult (duplicate)	0	no

CB

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
CB	DSW2	8192

location

name	number	inverted
SW4	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8192	yes
On	0	no

CB Ratio

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
CB Ratio	DSW2	49152

location

name	number	inverted
SW4	7	no
SW4	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
50	49152	yes
100	32768	no
200	16384	no
500	0	no

Double Up Game

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Double Up Game	DSW3	1

location

name	number	inverted
SW5	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Hands Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Hands Mode	DSW3	2

location

name	number	inverted
SW5	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Auto Stop

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Auto Stop	DSW3	4

location

name	number	inverted
SW5	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Reel Speed

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Reel Speed	DSW3	8

location

name	number	inverted
SW5	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Slow	8	yes
High	0	no

Game Count

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Game Count	DSW3	16

location

name	number	inverted
SW5	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Score

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Score	DSW3	32

location

name	number	inverted
SW5	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Bonus Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bonus Mode	DSW3	64

location

name	number	inverted
SW5	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
6 3 1	64	yes
9 6 1	0	no

Amusement

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Amusement	DSW3	128

location

name	number	inverted
SW5	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW3	256

location

name	number	inverted
SW6	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	256	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW3	512

location

name	number	inverted
SW6	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	512	yes
On	0	no

Key Out Value

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Key Out Value	DSW3	7168

location

name	number	inverted
SW6	3	no
SW6	4	no
SW6	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Coin	7168	yes
1	6144	no
5	5120	no
20	4096	no
50	3072	no
100	2048	no
200	1024	no
500	0	no

Device Value

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Device Value	DSW3	57344

location

name	number	inverted
SW6	6	no
SW6	7	no
SW6	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Coin	57344	yes
1	49152	no
5	40960	no
20	32768	no
50	24576	no
100	16384	no
200	8192	no
500	0	no
