DPB-7000 - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
dpb7000	quantel/dpb7000.cpp		no	no	no	yes	DPB-7000	1981	Quantel

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
combined_screen	raster	0	710	575	50.000000	25000000	800	0	710	625	0	575	no
screen	raster	0	640	240	50.000000	9604800	696	56	696	276	36	276	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	yes	no

rom

name	size	crc	sha1	region	offset	status	optional	bios
01616a-nad-4af2.bin	32768	a42eace6	78c629a8afb48a95fc0a86ca762cc5b84bd9929b	monitor	1	good	no	v406
01616a-ncd-58de.bin	32768	f70fff2a	a6f85d086a0c53d156eeeb157184ebcad4adecb3	monitor	0	good	no	v406
01616a-mad-f512.bin	32768	4c3e39f6	443095c56481fbcadd4dcec1757d889c8f78805d	monitor	10001	good	no	v406
01616a-mcd-91f2.bin	32768	4b6b6eb3	1bef443d78197d33e44c708ead9604020881f67f	monitor	10000	good	no	v406
01616a-lad-0059.bin	32768	0daf670d	2342a43054ed141de298a1c1a6867949297bb52a	monitor	20001	good	no	v406
01616a-lcd-5639.bin	32768	c8977d3f	4ee9f3a883400b4771e6ae33c6e4edcd5c0b49e7	monitor	20000	good	no	v406
01616a-kad-1d9b.bin	32768	bda7e309	377edf2675a6736fe7ec775894858967b0e9247e	monitor	30001	good	no	v406
01616a-kcd-e51c.bin	32768	aa05a5cc	85dce335a72643f7640524b18cfe480a3c299f23	monitor	30000	good	no	v406
01616a-jad-47a8.bin	32768	60fff4c9	ba60281c0dd8627dffe07e7ea66f4eb688e74001	monitor	40001	good	no	v406
01616a-jcd-7825.bin	32768	bb258ede	ab8042391cd361bcd874b2f9d8fcaf20d4b2ebe7	monitor	40000	good	no	v406
01616a-iad-73a8.bin	32768	98709fd2	bd0f4689600e9fc49dbd8f2f326e18f8d602825e	monitor	50001	good	no	v406
01616a-icd-0562.bin	32768	bab5274e	3e51977da3dfe8fda089b9d2c3199acb4fed3212	monitor	50000	good	no	v406
01616a-had-d6fa.bin	32768	70d791c5	c281e4f27404e58ad5a80d6de1c5583cd9f3fe0e	monitor	60001	good	no	v406
01616a-hcd-9c0e.bin	32768	938cb614	ea7ea8a13e0ab1497691bab53090296ba51d271f	monitor	60000	good	no	v406
01616a-gad-397d.bin	32768	0b95f9ed	77126ee6c1f3dcdb8aa669ab74ff112e3f01918a	monitor	70001	good	no	v406
01616a-gcd-3ab8.bin	32768	e9c21438	1784ab2de1bb6023565b2e27872a0fcda25e1b1f	monitor	70000	good	no	v406
01993c-naa-0608.bin	65536	9e4cfd96	faae2ba849d30c894d9f929bae371ae76e05bdac	monitor	1	good	no	v411
01993c-nca-3964.bin	65536	04d75a15	79f706296ba0c399b4e2d3acf947cae7706f9d63	monitor	0	good	no	v411
01993c-maa-fa58.bin	65536	88dc8ee0	a2f6b80022ddb5adf687b678c621c8f5db1f3575	monitor	20001	good	no	v411
01993c-mca-b2b0.bin	65536	16bf9db4	a4696ee5a68b8a304c2433f16a6d57d7108f6406	monitor	20000	good	no	v411
01993c-laa-6be3.bin	65536	56e693cc	b4f3e0f8b635fe2b3fa975ed57f966e8ade7fbb1	monitor	40001	good	no	v411
01993c-lca-7c0d.bin	65536	9540fa68	79e46c4b6e86f6e53e3f5fea72e3be8c64de03af	monitor	40000	good	no	v411
01993c-kaa-3b12.bin	65536	41e2ec71	37112f878b3db24b198e878f5dba90fcbb4175d2	monitor	60001	good	no	v411
01993c-kca-f705.bin	65536	00bfbd62	17a5f2cbc91cabf1113c7d6e26124b67e5ece848	monitor	60000	good	no	v411
01993c-jaa-3cc9.bin	65536	9e477845	b89e5d2b69a6043452a56685a1227df86c83a328	monitor	80001	good	no	v411
01993c-jca-0b41.bin	65536	58e8f302	b37953046d81027b069b7a7a1834cd8c94fd9dca	monitor	80000	good	no	v411
cat7000_diagnostic_rom_merged.bin	131072	666767d6	1dad9747321302bca7e03728c63034070f9ebf13	monitor	0	good	no	diags
bw14char.ic1	4096	f9dd68b5	50132b759a6d84c22c387c39c0f57535cd380411	vduchar	0	baddump	no
17704a-hga-256.bin	256	ab59d8fd	6dcbbb48838a5e370e22a708cea44e3db80d6505	diskseq_ucode	0	good	no
17704a-hfa-256.bin	256	f2475396	b525ba58d37128cadf1e7285fb421c14e2495587	diskseq_ucode	100	good	no
17704a-hea-256.bin	256	0a19cc11	13b72368d7cb5b7f685adfa07f07029026426b80	diskseq_ucode	200	good	no
17704a-hda-256.bin	256	a431cdf6	027eea87ccafde727208277b40e3a3f88433343a	diskseq_ucode	300	good	no
17704a-hca-256.bin	256	610ef462	f495647cc8420b7470ad68bccc069370f8f2af93	diskseq_ucode	400	good	no
17704a-hba-256.bin	256	94c16baf	13baef1359bf92a8ebb9a0c39f4223e810c3cdc1	diskseq_ucode	500	good	no
17704a-haa-256.bin	256	0080f2a9	63c7b31e5f65cc6e2c5fc67883c84284652cb4a7	diskseq_ucode	600	good	no
17704a-dfa-32.bin	32	ce5b8b46	49a1e619f52101b6078e2f51d82ce5947fe2c011	diskseq_prom	0	good	no
17446a-gd-m2716.bin	2048	a0be00ca	48c4f8c07b9f6bc9b68698e1e326782e0b01e1b0	fddprom	0	good	no
pb-037-17418-cda.bin	1024	a31f3793	4e74e528088c155e2c2592fa937e4cabfe6324c8	output_timing_cursor	0	good	no
pb-037-17418-bga.bin	1024	3b2c3635	2038d616dd7f65ba55497bd037b0ad69aaa801ed	output_timing_hlines	0	good	no
pb-037-17418-bea.bin	1024	644e82a3	d7634e03809abe2db924571c05821c1b2aca051b	output_timing_hflags	0	good	no
pb-037-17418-dfa.bin	1024	ca2ec308	4232f44ea5bd3fa240eaf7c14e4b925140f90a1e	output_timing_vlines	0	good	no
pb-037-17418-bfa.bin	256	a4486aac	3834d550da3f1865b921807300a94612149f69d4	output_timing_vflags	0	good	no
etc2716 63b2.bin	2048	04614a50	e547458f2c9cf29cf52f02b8824b32e5e91807fd	keyboard	0	good	no
hn482764g.bin	8192	3626059c	1a4f5c8b337f31c7b2b93096b59234ffbc2f1f00	tds	0	good	no
nmc27c64q.bin	8192	a453928f	f4a25298fb446f0046c6f9f3ce70e7169dcebd01	tablet	0	good	no
pb-029-17419a-bea.bin	2048	d30015c3	fb5856df3ace452dfb1c1882b2adb6562e3a6800	brushaddr_pal	0	good	no
pb-02c-17593-baa.bin	512	6e31339f	72a92d97412be19c884c3b854f7d9831435391a5	brushproc_prom	0	good	no
pb-02c-17593-hba.bin	2048	76018e4f	73d995e2e78410676061d45857756d5305a9984a	brushproc_pal	0	good	no
pb-02a-17421-ada.bin	256	84bf7029	9d58322994f6f7e99a9c6478577559c8171670ed	brushstore_pal	0	good	no
pb-02f-01748a-aba.bin	1024	24b31494	f9185a00e5470ec95d234a76c15acbf33cfb285d	framestore_back_pal	0	good	no
pb-02f-01748a-bba.bin	1024	8f06b632	233b841c3957a6df229f3a693f9288cb8feec58c	framestore_front_pal	0	good	no
pb-027-17427a-dab.bin	256	6deac5cc	184c34267e1b390bad0ca4a94befceece979e677	filter_signalprom	0	good	no
pb-027-17427a-afa-bfa.bin	512	58164a20	c32997350bae22be075a8eee7fe4d1bdd8a34fd2	filter_multprom	0	good	no
pb-012-17428a-aca.bin	256	0003b9ec	8484e4c3b57069c5166201a7cb43d028c87e06cc	size_pal	0	good	no
pb-012-17428a-fda.bin	512	159418f4	4e4c9be6d2e3ccdfdf8edfcb5cad106887e03fd2	size_prom_yh	0	good	no
pb-012-17428a-gda.bin	512	1207291a	ea44cf510169fdba2cfb0570a508fb3b0c93b06e	size_prom_yl	0	good	no
pb-012-17428a-ecb.bin	512	1e324bf1	efd88294dcb9fba58b2bb2b8d4715ba2c16f511d	size_prom_xh	0	good	no
pb-012-17428a-gca.bin	512	ec7d26f3	8bdbec33218f903294c135554d61271fa18d1a8d	size_prom_xl	0	good	no
pb-032-17425b-igb.bin	65536	cdd80590	fecb64695b61e8ec740af1480240088d5447688d	storeaddr_pal_blank	0	good	no
pb-032-17425b-bbb.bin	1024	2051a6e4	3bd8a9015e77b034a94fe072a9753649b76f9f69	storeaddr_prom_xlnib	0	good	no
pb-032-17425b-bcb.bin	1024	01aaa6f7	e31bff0c68f74996368443bfb58a3524a838f270	storeaddr_prom_xmnib	0	good	no
pb-032-17425b-bdb.bin	1024	20e2fb9e	c4c77ec02ab6d3a1a28edf5543e57235a64a9d8d	storeaddr_prom_xhnib	0	good	no
pb-032-17425b-deb.bin	1024	faeb44dd	3eaf981245824332d216e97095bdc02ff04e4800	storeaddr_prom_protx	0	good	no
pb-032-17425b-edb.bin	1024	83585876	7c244adcd365f7b2ec347255100fa3597857905c	storeaddr_prom_proty	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	8000000
cpu	fddcpu	Motorola MC6803	4915200
cpu	keybcpu	Intel 8039	4608000
cpu	tds	Motorola MC6803	4915200
cpu	tablet	Zilog Z8681	7372800
audio	0:8:flopsndout	Speaker
audio	0:8:floppysound	Floppy sound	44100

device_ref

name
m68000
ipt_merge_any_hi
acia6850
acia6850
acia6850
rs232
rs232
com8116
screen
screen
palette
sy6545_1
m6803
floppy_connector
floppy_8_dsdd
speaker
flopsnd
rs232
harddisk_image
i8039
m6803
scn2681
duart_channel
duart_channel
z8681

biosset

name	description	default
v406	V4.06A	no
v411	V4.11A	no
diags	Diagnostics	no

sound

channels
1

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
floppydisk	0:8	floppy_8			floppydisk	flop
harddisk	hdd				harddisk	hard

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
floppydisk	0:8	floppy_8			mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk
harddisk	hdd				chd, hd, hdv, 2mg, hdi

input

players	coins	service	tilt
1		no	no

control

type	buttons	reverse	minimum	maximum	sensitivity	keydelta
lightgun	5	no	1000	4399	50
pedal		no	2	175	100	10
keyboard	55	no

port, analog

port_tag	analog_masks
:AUTOSTART
:BAUD
:CONFIGSW12
:CONFIGSW34
:KEYB_COL0
:KEYB_COL1
:KEYB_COL2
:KEYB_COL3
:KEYB_COL4
:KEYB_COL5
:KEYB_COL6
:KEYB_COL7
:PENPRESS	255
:PENPROX
:PENSW
:PENX	65535
:PENY	65535
:TDSDIPS

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
rs2320	terminal	serial_terminal	no
rs2320	sunkbd	sunkbd_adaptor	no
rs2320	dec_loopback	dec_rs232_loopback	no
rs2320	ie15	ie15_terminal	no
rs2320	null_modem	null_modem	no
rs2320	keyboard	serial_keyboard	no
rs2320	patch	rs232_patch_box	no
rs2320	swtpc8212	swtpc8212_terminal	no
rs2320	printer	serial_printer	no
rs2320	scorpion	scorpion_ic	no
rs2320	loopback	rs232_loopback	no
rs2320	mockingboard	mockingboardd	no
rs2320	msystems_mouse	rs232_mouse_hle_msystems	no
rs2320	nss_tvi	nss_tvinterface	no
rs2320	rs232_sync_io	rs232_sync_io	no
rs2320	pty	pseudo_terminal	no
rs2320	votraxtnt	serial_votraxtnt	no
rs2320	rs_printer	rs_serial_printer	no
rs2321	terminal	serial_terminal	no
rs2321	sunkbd	sunkbd_adaptor	no
rs2321	dec_loopback	dec_rs232_loopback	no
rs2321	ie15	ie15_terminal	no
rs2321	null_modem	null_modem	no
rs2321	keyboard	serial_keyboard	no
rs2321	patch	rs232_patch_box	no
rs2321	swtpc8212	swtpc8212_terminal	no
rs2321	printer	serial_printer	no
rs2321	scorpion	scorpion_ic	no
rs2321	loopback	rs232_loopback	no
rs2321	mockingboard	mockingboardd	no
rs2321	msystems_mouse	rs232_mouse_hle_msystems	no
rs2321	nss_tvi	nss_tvinterface	no
rs2321	rs232_sync_io	rs232_sync_io	no
rs2321	pty	pseudo_terminal	no
rs2321	votraxtnt	serial_votraxtnt	no
rs2321	rs_printer	rs_serial_printer	no
0	8	floppy_8_dsdd	yes
fddserial	terminal	serial_terminal	no
fddserial	sunkbd	sunkbd_adaptor	no
fddserial	dec_loopback	dec_rs232_loopback	no
fddserial	ie15	ie15_terminal	no
fddserial	null_modem	null_modem	no
fddserial	keyboard	serial_keyboard	no
fddserial	patch	rs232_patch_box	no
fddserial	swtpc8212	swtpc8212_terminal	no
fddserial	printer	serial_printer	no
fddserial	scorpion	scorpion_ic	no
fddserial	loopback	rs232_loopback	no
fddserial	mockingboard	mockingboardd	no
fddserial	msystems_mouse	rs232_mouse_hle_msystems	no
fddserial	nss_tvi	nss_tvinterface	no
fddserial	rs232_sync_io	rs232_sync_io	no
fddserial	pty	pseudo_terminal	no
fddserial	votraxtnt	serial_votraxtnt	no
fddserial	rs_printer	rs_serial_printer	no

dipswitch

Auto-Start

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Auto-Start	AUTOSTART	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	1	yes

Baud Rate for Terminal

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Baud Rate for Terminal	BAUD	15

value

name	value	default
50	0	no
75	1	no
110	2	no
134.5	3	no
150	4	no
300	5	no
600	6	no
1200	7	no
1800	8	no
2000	9	no
2400	10	no
3600	11	no
4800	12	no
9600	14	yes
19200	15	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	CONFIGSW12	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

NTSC/PAL

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
NTSC/PAL	CONFIGSW12	2

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
NTSC	2	no
PAL	0	yes

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	CONFIGSW12	4

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	CONFIGSW12	8

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	CONFIGSW12	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Diagnostic Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Diagnostic Mode	CONFIGSW12	32

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	CONFIGSW12	64

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	CONFIGSW12	128

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	CONFIGSW12	256

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	256	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	CONFIGSW12	512

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	512	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	CONFIGSW12	1024

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1024	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	CONFIGSW12	2048

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2048	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	CONFIGSW12	4096

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4096	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	CONFIGSW12	8192

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8192	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	CONFIGSW12	16384

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16384	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	CONFIGSW12	32768

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32768	yes
On	0	no

Disc Group 0 Count

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Disc Group 0 Count	CONFIGSW34	3

value

name	value	default
One	3	yes
Two	2	no
Three	1	no
Four	0	no

Disc Group 0 Type

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Disc Group 0 Type	CONFIGSW34	28

value

name	value	default
None	28	no
160Mb Fujitsu	24	no
330Mb Fujitsu	20	no
Floppy Disc	12	yes
NTSC/Floppy/PAL/Conv	8	no
80Mb CDC Removable	4	no
160Mb CDC Fixed	0	no

Disc Group 1 Count

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Disc Group 1 Count	CONFIGSW34	96

value

name	value	default
One	96	yes
Two	64	no
Three	32	no
Four	0	no

Disc Group 1 Type

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Disc Group 1 Type	CONFIGSW34	896

value

name	value	default
None	896	yes
160Mb Fujitsu	768	no
330Mb Fujitsu	640	no
Floppy Disc	384	no
NTSC/Floppy/PAL/Conv	256	no
80Mb CDC Removable	128	no
160Mb CDC Fixed	0	no

Disc Group 2 Count

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Disc Group 2 Count	CONFIGSW34	3072

value

name	value	default
One	3072	yes
Two	2048	no
Three	1024	no
Four	0	no

Disc Group 2 Type

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Disc Group 2 Type	CONFIGSW34	28672

value

name	value	default
None	28672	yes
160Mb Fujitsu	24576	no
330Mb Fujitsu	20480	no
Floppy Disc	12288	no
NTSC/Floppy/PAL/Conv	8192	no
80Mb CDC Removable	4096	no
160Mb CDC Fixed	0	no

Start Up In Dialogue

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Start Up In Dialogue	CONFIGSW34	32768

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32768	yes
On	0	no

TDS Box Encoding

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
TDS Box Encoding	TDSDIPS	8

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Binary	8	yes
ASCII	0	no

TDS Box Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
TDS Box Mode	TDSDIPS	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Normal	16	yes
Monitor	0	no

TDS Box Standard

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
TDS Box Standard	TDSDIPS	64

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
NTSC	64	no
PAL	0	yes
