Dragon Unit / Castle of Dragon - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
drgnunit	seta/seta.cpp		no	no	no	yes	Dragon Unit / Castle of Dragon	1989	Athena / Seta

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	384	240	60.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
prg-e.bin	131072	728447df	8bdc52a4cc5f36794a47f963545bdaa26c9acd6b	maincpu	0	good	no
prg-o.bin	131072	b2f58ecf	5198e75b22bab630b458797988f2e443c601351f	maincpu	1	good	no
obj-2.bin	131072	d7f6ab5a	a32f1705e833c339bd0c426a395cc706da96dad7	gfx1	0	good	no
obj-1.bin	131072	53a95b13	b7c7994441aafcea49662dc0fbebd6db836723f5	gfx1	1	good	no
obj-6.bin	131072	80b801f7	5b5635903137e50bc982d05b73c2648bbf182e71	gfx1	40000	good	no
obj-5.bin	131072	6b87bc20	9a0e3e18339d6c12e63960fb940a56c16dcb87cf	gfx1	40001	good	no
obj-4.bin	131072	60d17771	0874c10a2527293715db95bd7c83886d94f810cf	gfx1	80000	good	no
obj-3.bin	131072	0bccd4d5	7139ef793efe7c6477f78b50207227b1be223755	gfx1	80001	good	no
obj-8.bin	131072	826c1543	f669f255b4596da5648592b5993b02671e404102	gfx1	c0000	good	no
obj-7.bin	131072	cbaa7f6a	060f0651b8ca07d239ef1b7c63943cdd433e1ae9	gfx1	c0001	good	no
scr-1o.bin	131072	671525db	e230e99754c9f40af7da2054bd5ea09823e0b1b7	gfx2	0	good	no
scr-2o.bin	131072	2a3f2ed8	9d188100437a10eb3d3097f28e28e3cb2dc1b21d	gfx2	40000	good	no
scr-3o.bin	131072	4d33a92d	8b09768abb460446405224565eb6652d2dc1c571	gfx2	80000	good	no
scr-4o.bin	131072	79a0aa61	9905d90afb759b1d983856d7bef17c139d4f0e4f	gfx2	c0000	good	no
scr-1e.bin	131072	dc9cd8c9	04450a5cfde5d6b69fdd745cd930309863e1aadd	gfx2	1	good	no
scr-2e.bin	131072	b6126b41	13275f05868d93af95ebb162d229b69ddd660438	gfx2	40001	good	no
scr-3e.bin	131072	1592b8c2	d337de280c5ea3704dec9baa04c45e1c837924a9	gfx2	80001	good	no
scr-4e.bin	131072	8201681c	7784a68828d728107b0228bb3568129c543cbf40	gfx2	c0001	good	no
snd-1.bin	131072	8f47bd0d	c55e22ac4294931cfb72ac88a2128891d9f8ee93	x1snd	0	good	no
snd-2.bin	131072	65c40ef5	726b46144e2216d17b0828abad2f5e7c2305c174	x1snd	20000	good	no
snd-3.bin	131072	71fbd54e	bdaf7ecf1c79c6c8fc82d959186ca2f3304729c8	x1snd	40000	good	no
snd-4.bin	131072	ac50133f	d56a9569bd72c7bc13d09dcea9789cdc7252ffb4	x1snd	60000	good	no
snd-5.bin	131072	70652f2c	04ff016a087a230efe4644eb76f68886aae26978	x1snd	80000	good	no
snd-6.bin	131072	10a1039d	a1160fe600d39ae6fdbf247f634c2e094b3a675f	x1snd	a0000	good	no
snd-7.bin	131072	decbc8b0	9d315d1119fbc2bf889efdb174ebc5e26ecad859	x1snd	c0000	good	no
snd-8.bin	131072	3ac51bee	cb2ee501895b848d434991152dea293685f8ed22	x1snd	e0000	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	8000000
audio	mono	Speaker
audio	x1snd	Seta X1-010	16000000

device_ref

name
m68000
timer
x1_001
screen
x1_012
palette
speaker
x1_010

sound

channels
1

input

players	coins	service	tilt
2	2	no	yes

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	3	8	no
joy	2	3	8	no

port, analog

port_tag	analog_masks
:COINS
:DSW
:P1
:P2

dipswitch

Coinage Type

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage Type	COINS	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Coin Mode 1	16	yes
Coin Mode 2	0	no

Title

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Title	COINS	32

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Dragon Unit	32	yes
Castle of Dragon	0	no

(C) / License

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
(C) / License	COINS	192

value

name	value	default
Athena (Japan)	192	yes
Athena / Taito (Japan)	128	no
Seta USA / Taito America	64	no
Seta USA / Romstar	0	no

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW	3

location

name	number	inverted
SW1	1	no
SW1	2	no

value

name	value	default
Easy	3	no
Normal	2	yes
Hard	1	no
Hardest	0	no

Bonus Life

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bonus Life	DSW	12

location

name	number	inverted
SW1	3	no
SW1	4	no

value

name	value	default
150K, Every 300K	8	no
200K, Every 400K	12	yes
300K, Every 500K	4	no
400K Only	0	no

Lives

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Lives	DSW	48

location

name	number	inverted
SW1	5	no
SW1	6	no

value

name	value	default
1	0	no
2	16	no
3	48	yes
5	32	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	64

location

name	number	inverted
SW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Stage Time

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stage Time	DSW	128

location

name	number	inverted
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Normal	128	yes
Extra 20s	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	256

location

name	number	inverted
SW2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	256	yes
On	0	no

Flip Screen

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flip Screen	DSW	512

location

name	number	inverted
SW2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	512	yes
On	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW	1024

location

name	number	inverted
SW2	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1 of 4 Scenes	1024	yes
1 of 8 Scenes	0	no

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	DSW	2048

location

name	number	inverted
SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2048	yes
On	0	no

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSW	12288

location

name	number	inverted
SW2	5	no
SW2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
2 Coins/1 Credit	4096	no	COINS	16	eq	16
1 Coin/1 Credit	12288	yes	COINS	16	eq	16
2 Coins/3 Credits	0	no	COINS	16	eq	16
1 Coin/2 Credits	8192	no	COINS	16	eq	16
4 Coins/1 Credit	0	no	COINS	16	ne	16
3 Coins/1 Credit	4096	no	COINS	16	ne	16
2 Coins/1 Credit	8192	no	COINS	16	ne	16
1 Coin/1 Credit	12288	yes	COINS	16	ne	16

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSW	49152

location

name	number	inverted
SW2	7	no
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
2 Coins/1 Credit	16384	no	COINS	16	eq	16
1 Coin/1 Credit	49152	yes	COINS	16	eq	16
2 Coins/3 Credits	0	no	COINS	16	eq	16
1 Coin/2 Credits	32768	no	COINS	16	eq	16
1 Coin/2 Credits	49152	yes	COINS	16	ne	16
1 Coin/3 Credits	32768	no	COINS	16	ne	16
1 Coin/4 Credits	16384	no	COINS	16	ne	16
1 Coin/6 Credits	0	no	COINS	16	ne	16
