EP804 EPROM Programmer - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
ep804	skeleton/digel804.cpp		no	no	no	yes	EP804 EPROM Programmer	1982	Wavetek/Digelec, Inc	digel804	digel804

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	bios
804-2__rev_1.6__07f7.hn482764g-4.d41	8192	2d4c334c	1be70ed5f4f315a8d2e38a17327a049e00fa174e	maincpu	0	good	no	ep804_v1.6
804-3__rev_1.6__265c.hn482764g-4.d42	8192	9c14906b	41996039e604011c7c0f757397f82b6479ee3f62	maincpu	2000	good	no	ep804_v1.6
804-2_rev_1.4__7a7e.hn482764g-4.d41	8192	fdc0d2e3	da1bc1e8c4cb2a2d8cd2273f3e1a9f318ae8cb87	maincpu	0	good	no	ep804_v1.4
804-3_rev_1.4__f240.2732.d42	4096	29827e29	4c7fadf81bcf32349a564d946f5d215de50315c5	maincpu	2000	good	no	ep804_v1.4
804-3_rev_1.4__f240.2732.d42	4096	29827e29	4c7fadf81bcf32349a564d946f5d215de50315c5	maincpu	3000	good	no	ep804_v1.4
804-2_rev2.21__cs_ab50.hn482764g.d41	8192	ffbc95f6	b12aa97e23d546064f1d17aa9b90772017fec5ec	maincpu	0	good	no	ep804_v2.21
804-3_rev2.21__cs_6b98.hn482764g.d42	8192	a4acb9fe	bbc7e3e2e6b3b1abe747380909dcddc985ef8d0d	maincpu	2000	good	no	ep804_v2.21
2023__1-03__be7d.m5l2764k.d41	8192	8e5182f1	e8409b6ace80fdaad862e6c06975aeabcf728f97	maincpu	0	good	no	promicron2k_v2.3
2023__2-03__c73e.m5l2764k.d42	8192	ff7d959b	75718fc1d98969739911cc51b6d5fef74b530e36	maincpu	2000	good	no	promicron2k_v2.3
804.2-1.7_3bc0.2764.d41	8192	d39c2b51	6e00d9c8f5037936618fd17475b72261f3e54826	maincpu	0	good	no	ep804_v1.7
804-3-1.7_1c96.2764.d42	8192	994df376	93bbc48b72e2126a9f40312e66ca2a87c7f67bf6	maincpu	2000	good	no	ep804_v1.7
804-1-2.mmi_6330-in.d30	32	30dd4721	e4b2f5756118be4c8ab56c708dc4f42469c7e51b	proms	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Zilog Z80	1843200
audio	mono	Speaker
audio	speaker	Filtered DAC

device_ref

name
z80
roc10937
mm74c923
mos6551
clock
rs232
null_modem
bitbanger
ram
speaker
speaker_sound_device

biosset

name	description	default
ep804_v1.6	Wavetek/Digelec EP804 FWv1.6	yes
ep804_v1.4	Wavetek/Digelec EP804 FWv1.4	no
ep804_v2.21	Wavetek/Digelec EP804 FWv2.21	no
promicron2k_v2.3	Celectronic Berlin/Digelec promicron 2000 FWv2.3	no
ep804_v1.7	Wavetek/Digelec EP804 FWv1.7	no

sound

channels
1

ramoption

name	default
64K
32K	yes

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
bitbanger	rs232:null_modem:stream				bitbanger	bitb

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
bitbanger	rs232:null_modem:stream

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keyboard		24		no

port, analog

port_tag	analog_masks
:DEBUG
:LINE0
:LINE1
:LINE2
:LINE3
:MODE
:rs232:null_modem:FLOW_CONTROL
:rs232:null_modem:RS232_DATABITS
:rs232:null_modem:RS232_PARITY
:rs232:null_modem:RS232_RXBAUD
:rs232:null_modem:RS232_STOPBITS
:rs232:null_modem:RS232_TXBAUD

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
rs232	terminal	serial_terminal	no
rs232	sunkbd	sunkbd_adaptor	no
rs232	dec_loopback	dec_rs232_loopback	no
rs232	ie15	ie15_terminal	no
rs232	null_modem	null_modem	yes
rs232	keyboard	serial_keyboard	no
rs232	patch	rs232_patch_box	no
rs232	swtpc8212	swtpc8212_terminal	no
rs232	printer	serial_printer	no
rs232	scorpion	scorpion_ic	no
rs232	loopback	rs232_loopback	no
rs232	mockingboard	mockingboardd	no
rs232	msystems_mouse	rs232_mouse_hle_msystems	no
rs232	nss_tvi	nss_tvinterface	no
rs232	rs232_sync_io	rs232_sync_io	no
rs232	pty	pseudo_terminal	no
rs232	votraxtnt	serial_votraxtnt	no
rs232	rs_printer	rs_serial_printer	no

configuration

Flow Control

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flow Control	rs232:null_modem:FLOW_CONTROL	7

setting

name	value	default
Off	0	yes
RTS	1	no
DTR	2	no
XON/XOFF	4	no

Data Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Data Bits	rs232:null_modem:RS232_DATABITS	255

setting

name	value	default
5	0	no
6	1	no
7	2	yes
8	3	no

Parity

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Parity	rs232:null_modem:RS232_PARITY	255

setting

name	value	default
None	0	no
Odd	1	yes
Even	2	no
Mark	3	no
Space	4	no

RX Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
RX Baud	rs232:null_modem:RS232_RXBAUD	255

setting

name	value	default
50	14	no
75	15	no
110	0	no
134.5	16	no
150	1	no
200	17	no
300	2	no
600	3	no
1200	4	no
1800	18	no
2000	19	no
2400	5	no
3600	20	no
4800	6	no
7200	21	no
9600	7	yes
14400	8	no
19200	9	no
28800	10	no
38400	11	no
57600	12	no
111900	22	no
115200	13	no

Stop Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stop Bits	rs232:null_modem:RS232_STOPBITS	255

setting

name	value	default
0	0	no
1	1	yes
1.5	2	no
2	3	no

TX Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
TX Baud	rs232:null_modem:RS232_TXBAUD	255

setting

name	value	default
50	14	no
75	15	no
110	0	no
134.5	16	no
150	1	no
200	17	no
300	2	no
600	3	no
1200	4	no
1800	18	no
2000	19	no
2400	5	no
3600	20	no
4800	6	no
7200	21	no
9600	7	yes
14400	8	no
19200	9	no
28800	10	no
38400	11	no
57600	12	no
111900	22	no
115200	13	no

dipswitch

Debug Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Debug Mode	DEBUG	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no
