Espgaluda (2003/10/15 Master Ver) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
espgal	igs/pgm.cpp		no	no	no	yes	Espgaluda (2003/10/15 Master Ver)	2003	Cave (AMI license)

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	270	448	224	59.185606	10000000	640	0	448	264	0	224	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
imperfect	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
espgaluda_v100.u38	2097152	08ecec34	bce2e7fb9105ed51603d09cbd3a9eeb5b8f47ee2	maincpu	0	good	no
espgal_igs027a.bin	16384			prot	0	nodump	no
t01s.u18	2097152	1a7123a0	cc567f577bfbf45427b54d6695b11b74f2578af3	igs023	0	good	no
cave_t04801w064.u19	8388608	6021c79e	fbc340dafb18aa3094de29b881318a5a9794e4bc	igs023	180000	good	no
cave_a04801w064.u7	8388608	26dd4932	9bbabb5a53cb5ba88397cc2c258980f3b70314ce	igs023:sprcol	0	good	no
cave_a04802w064.u8	8388608	0e6bf7a9	a7541e2b5a0df2bc62a5b347e54dbc2ed1922db2	igs023:sprcol	800000	good	no
cave_b04801w064.u1	8388608	98dce13a	61d48b7117459f7babc022b68231f6928177a71d	igs023:sprmask	0	good	no
cave_w04801b032.u17	4194304	60298536	6b7333f16cce778c5725dbdf75a5446f0906397a	ics	400000	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	20000000
cpu	soundcpu	Zilog Z80	8467200
cpu	prot	ARM7 (little)	20000000
audio	mono	Speaker
audio	ics	ICS2115 WaveFront Synthesizer	33868800

device_ref

name
m68000
timer
z80
nvram
v3021
screen
palette
speaker
generic_latch_8
generic_latch_8
generic_latch_8
igs023
ics2115
arm7_le

sound

channels
1

feature

type	status	overall
sound	imperfect

input

players	coins	service	tilt
2	2	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	4	8	no
joy	2	4	8	no

port, analog

port_tag	analog_masks
:DSW
:P1P2
:P3P4
:Region
:Service

dipswitch

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	DSW	1

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	2

location

name	number	inverted
SW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	4

location

name	number	inverted
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	8

location

name	number	inverted
SW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	16

location

name	number	inverted
SW1	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	32

location

name	number	inverted
SW1	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	64

location

name	number	inverted
SW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	128

location

name	number	inverted
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no
