Earth Wind Fire - mame (0287) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
ewf	pinball/zac_1.cpp	genpin	no	no	yes	yes	Earth Wind Fire	1981	Zaccaria

snap

Earth Wind Fire png snap

Earth Wind Fire jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
ewf	14068	20/03/2026 12:09:53	640	480	96	96	0	Format24bppRgb	305:MAME 0.286 (mame0286)	968160f92af1d6ec2cd16808c85089078fdd10dc

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	supported	yes	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
zac_boot.u1	2048	62a3da59	db571139aff61757f6c0fda6fa0d1fea8257cb15	maincpu	0	good	no
ewf_2.u2	1024	aa67e0b4	4491eff7081fd5e397974fac1156992ce2012d0b	maincpu	1c00	good	no
ewf_3.u3	1024	b21bf015	ecddfe1d6797c39e094a7f86efabf0abea0fa4af	maincpu	800	good	no
ewf_4.u4	1024	d110da3f	88e27347d209fab5be924f95b0a001476ea92c1f	maincpu	c00	good	no
ewf_5.u5	1024	f695dab6	48ca60718cea40baa5052f690c8d69eb7ab32b0e	maincpu	1000	good	no
ewf.snd	2048	5079e493	51d366cdd09ad00b8b016b0ea1c85ac95ef94d71	audiocpu	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Signetics 2650	3000000
cpu	audiocpu	Intel 8035	6000000
audio	mechvol	Speaker
audio	samples	Samples
audio	mono	Speaker
audio	dac	MC1408 DAC

device_ref

tag	name
:maincpu	s2650
:ram	nvram
:zac_1_inttimer	timer
:zac_1_outtimer	timer
:mechvol	speaker
:samples	samples
:mono	speaker
:audiocpu	i8035
:dac	mc1408
:soundlatch	generic_latch_8

sample

name
bumper
chime1
chime2
chime3
chime4
hole
knocker
sling
coinin
outhole
kickback
drop_target_reset
coil_coinlockout_engage
coil_coinlockout_release
relay_engage
relay_release
solenoid_engage
solenoid_release

sound

channels
2

feature

type	status	overall
sound	unemulated

input

players	coins	service	tilt
1	3	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
keypad		40		no

port, analog

port_tag	analog_masks
:DSW2
:TEST
:X0
:X1
:X2
:X3
:X4
:X5

dipswitch

Sound Test

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Sound Test	DSW2	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW2	32

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no
