F-1 Grand Prix Part II - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
f1gp2	vsystem/f1gp.cpp		no	no	no	yes	F-1 Grand Prix Part II	1992	Video System Co.

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	90	320	224	60.000000	7864320	512	0	320	256	0	224	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no	preliminary

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
rom12.v1	131072	c5c5f199	56fcbf1d9b15a37204296c578e1585599f76a107	maincpu	0	good	no
rom14.v2	131072	dd5388e2	66e88f86edc2407e5794519f988203a52d65636d	maincpu	1	good	no
rom2	2097152	3b0cfa82	ea6803dd8d30aa9f3bd578e113fc26f20c640751	user1	100000	good	no
rom13.v3	131072	c37aa303	0fe09b398191888620fb676ed0f1593be575512d	sub	0	good	no
rom5.v4	131072	6a9398a1	e907fe5f9c135c5b10ec650ec0c6d08cb856230c	audiocpu	0	good	no
rom1	2097152	f2d55ad7	2f2d9dc4fab63b06ed7cba0ef1ced286dbfaa7b4	fgtiles	0	good	no
rom15	2097152	1ac03e2e	9073d0ae24364229a993046bd71e403988692993	sprites1	0	good	no
rom11	1048576	b22a2c1f	b5e67726be5a8561cd04c3c07895b8518b73b89c	roztiles	0	good	no
rom10	1048576	43fcbe23	54ab58d904890a0b907e674f855092e974c45edc	roztiles	100000	good	no
rom9	1048576	1bede8a1	325ecc3afb30d281c2c8a56719e83e4dc20545bb	roztiles	200000	good	no
rom8	1048576	98baf2a1	df7bd1a743ad0a6e067641e2b7a352c466875ef6	roztiles	300000	good	no
rom4	524288	c2d3d7ad	3178096741583cfef1ca8f53e6efa0a59e1d5cb6	ymsnd:adpcmb	0	good	no
rom3	1048576	7f8f066f	5e051d5feb327ac818e9c7f7ac721dada3a102b6	ymsnd:adpcma	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	10000000
cpu	sub	Motorola MC68000	10000000
cpu	audiocpu	Zilog Z80	5000000
audio	speaker	Speaker
audio	ymsnd	YM2610 OPNB	8000000

device_ref

name
m68000
m68000
z80
acia6850
clock
screen
gfxdecode
palette
k053936
speaker
generic_latch_8
ym2610
vsystem_spr

sound

channels
1

feature

type	status	overall
lan	unemulated

input

players	coins	service	tilt
1	2	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy		3	2	no
stick				no	0	255	10	5

port, analog

port_tag	analog_masks
:DSW1
:DSW2
:DSW3
:INPUTS
:JOY_TYPE
:WHEEL	255

configuration

Joystick Type

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Joystick Type	JOY_TYPE	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
2-Way	1	yes
4-Way	0	no

dipswitch

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW1	3

location

name	number	inverted
SW2	1	no
SW2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Easy	2	no
Normal	3	yes
Hard	1	no
Hardest	0	no

Game Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Game Mode	DSW1	4

location

name	number	inverted
SW2	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Single	4	yes
Multiple	0	no

Multi Player Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Multi Player Mode	DSW1	8

location

name	number	inverted
SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Single or Multi Player	8	yes	DSW1	4	eq	0
Multi Player Game Only	0	no	DSW1	4	eq	0
Multi Player Off	8	yes	DSW1	4	ne	0
Multi Player Off	0	no	DSW1	4	ne	0

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW1	16

location

name	number	inverted
SW2	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW1	32

location

name	number	inverted
SW2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW1	64

location

name	number	inverted
SW2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW1	128

location

name	number	inverted
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Free Play

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Free Play	DSW1	256

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	256	yes
Yes	0	no

Coinage

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage	DSW1	32256	DSW1	32768	ne	32768

location

name	number	inverted
SW1	2	no
SW1	3	no
SW1	4	no
SW1	5	no
SW1	6	no
SW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
2 to Start, 1 to Continue	32256	yes

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSW1	3584	DSW1	32768	eq	32768

location

name	number	inverted
SW1	2	no
SW1	3	no
SW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
3 Coins/1 Credit	2560	no
2 Coins/1 Credit	3072	no
1 Coin/1 Credit	3584	yes
1 Coin/2 Credits	2048	no
1 Coin/3 Credits	1536	no
1 Coin/4 Credits	1024	no
1 Coin/5 Credits	512	no
1 Coin/6 Credits	0	no

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSW1	28672	DSW1	32768	eq	32768

location

name	number	inverted
SW1	5	no
SW1	6	no
SW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
3 Coins/1 Credit	20480	no
2 Coins/1 Credit	24576	no
1 Coin/1 Credit	28672	yes
1 Coin/2 Credits	16384	no
1 Coin/3 Credits	12288	no
1 Coin/4 Credits	8192	no
1 Coin/5 Credits	4096	no
1 Coin/6 Credits	0	no

Continue Coin

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Continue Coin	DSW1	32768

location

name	number	inverted
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Normal Coinage	32768	yes
On	0	no

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	DSW2	256

location

name	number	inverted
SW3	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	256	yes
On	0	no

Flip Screen

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flip Screen	DSW2	512

location

name	number	inverted
SW3	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	512	yes
On	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW2	1024

location

name	number	inverted
SW3	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1024	no
On	0	yes

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW2	2048

location

name	number	inverted
SW3	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2048	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW2	4096

location

name	number	inverted
SW3	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4096	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW2	8192

location

name	number	inverted
SW3	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8192	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW2	16384

location

name	number	inverted
SW3	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16384	yes
On	0	no

Input Method

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Input Method	DSW2	32768

location

name	number	inverted
SW3	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Joystick	32768	yes
Steering Wheel	0	no

Region

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Region	DSW3	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
World	1	yes
Japan	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW3	30

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	30	yes
On	0	no
