F-1 Super Battle - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
f1superb	jaleco/ms32.cpp		no	no	no	yes	F-1 Super Battle	1994	Jaleco

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	320	224	59.410646	6000000	384	0	320	263	0	224	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
f1sb26.bin	524288	042fccd5	4a69de3aef51adad502d54987468170b9e7bb8ac	maincpu	3	good	no
f1sb27.bin	524288	5f96cf32	c9c64576a8bb81a8e8bbe30b054ed33afd760b93	maincpu	2	good	no
f1sb28.bin	524288	cfda8003	460146556f606bf213d7e2ab29d2eb8827131bd0	maincpu	1	good	no
f1sb29.bin	524288	f21f1481	97a97ff3b9a71b1a024d8f2cfe57a1d02cec5ea4	maincpu	0	good	no
f1sb1.bin	2097152	53a3a97b	c8cd501ae10d9eb48a02e4e59a1ce389a27afc44	sprite	2	good	no
f1sb13.bin	2097152	36565a99	db08ff3107dcc07ca31140715d7d4b7bd27fa4c5	sprite	0	good	no
f1sb2.bin	2097152	a452f50a	3782a37203b652ea5df5b04dc74a0fdace7b14cc	sprite	400002	good	no
f1sb14.bin	2097152	c0c20490	9e93beae38c5cfca9f381b4d134c1d95cfa2223a	sprite	400000	good	no
f1sb3.bin	2097152	265d068c	a2a7850fbc2a04e448f772544d2f6925f9aaf99c	sprite	800002	good	no
f1sb15.bin	2097152	575a146e	bf67a89ac3145d38564b9dbc3c650c9d5f2bcd92	sprite	800000	good	no
f1sb4.bin	2097152	0ccc66fd	07ffef821300386224a7743e8f83088e3437c6db	sprite	c00002	good	no
f1sb16.bin	2097152	a2d017a1	6c1dd67a1c9c18d69f7dbf7d4637671809be5c89	sprite	c00000	good	no
f1sb5.bin	2097152	bff4271b	dc5672f51348fe0a79352eeafaeeefd78428fe5a	sprite	1000002	good	no
f1sb17.bin	2097152	2b9739d5	db9e93fe79dfa041584730df9cc678caad073251	sprite	1000000	good	no
f1sb6.bin	2097152	6caf48ec	18ea445970285950c61c8eff74a3ab6387816990	sprite	1400002	good	no
f1sb18.bin	2097152	c49055ff	6038dc497583229060ad686090d6940c0a3d1558	sprite	1400000	good	no
f1sb7.bin	2097152	a5458947	7743d67a167f6eecfac6614d1336c6df425e5e95	sprite	1800002	good	no
f1sb19.bin	2097152	b7cacf0d	cea52b1062cf154ccba11640798902b0f9ddeb77	sprite	1800000	good	no
f1sb8.bin	2097152	ba3f1533	3ff1c4cca8358fc8daf0d2c381672569085ac9ae	sprite	1c00002	good	no
f1sb20.bin	2097152	fa349897	31e08aa2821e409057e3094333b9ecbe04a6a38a	sprite	1c00000	good	no
f1sb9.bin	2097152	66b12e1f	4dc3f162a5116403cc0c491af335208672c8e9af	roztiles	0	good	no
f1sb10.bin	2097152	893d7f4b	b2734f20f703a0dcf8b1fdaebf2b6198b2fb0f51	roztiles	200000	good	no
f1sb11.bin	2097152	0b848bb5	e4c0e434add151112352d6068e5de1a7098e6346	roztiles	400000	good	no
f1sb12.bin	2097152	edecd5f4	9b86802d08e5c8ec1a6dcea75dc8f050d3e96970	roztiles	600000	good	no
f1sb31.bin	2097152	1d0d2efd	e6446ef9c71be9316c286157f71e0043347c6a5c	bgtiles	0	good	no
f1sb32.bin	524288	1b31fcce	354cc6f43cd3bf3ba921ac8c5631ab993bedf563	txtiles	0	good	no
f1sb2b.bin	2097152	18d73b16	f06f4d31b15658cc1e1b559ae3b8a90b797546ca	gfx5	0	good	no
f1sb3b.bin	2097152	ce728fe0	e0fd7b8f4d3dc9e2b15ddf027c61e67e5c1f22b5	gfx5	200000	good	no
f1sb4b.bin	2097152	077180c5	ab16739da709ecdbbb1264beba349ef6ecf3f8b1	gfx5	400000	good	no
f1sb5b.bin	2097152	efabc47d	195afde8a1f45da4fc04c3080a3cf5fdfff7be5e	gfx5	600000	good	no
f1sb21.bin	262144	e131e1c7	33f95a074930c49548069518d8c6dcde7fa25627	audiocpu	0	good	no
mr92042-01.22	2097152	0fa26f65	e92b14862fbce33ea4ab4567ec48199bfcbbdd84	ymf	0	good	no
f1sb23.bin	2097152	bfefa3ab	7770cc9b091e258ede7f2780df61a592cc008dd7	ymf	200000	good	no
91022-01.ic83	1			motherbrd_pals	0	nodump	no

chip

type	tag	name	clock
cpu	maincpu	NEC V70	20000000
cpu	audiocpu	Zilog Z80	8000000
audio	speaker	Speaker
audio	ymf	Yamaha YMF271 OPX	16934400

device_ref

name
v70
z80
jaleco_ms32_sysctrl
screen
gfxdecode
palette
ms32spr
speaker
generic_latch_8
ymf271

sound

channels
1

feature

type	status	overall
graphics	imperfect
sound		imperfect
lan	unemulated

input

players	coins	service	tilt
2	2	yes	no

control

type	player	buttons	reverse	minimum	maximum	sensitivity	keydelta
stick	1	2	no	0	255	50	15
pedal	1		no	0	255	50	15
only_buttons	2	1	no

port, analog

port_tag	analog_masks
:AN0	255
:AN1	255
:AN2
:DSW
:DSW2
:INPUTS

dipswitch

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	AN2	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	AN2	2

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	AN2	4

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	AN2	8

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	AN2	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	AN2	32

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	AN2	64

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Shift Brake

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Shift Brake	AN2	128

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Credit Counter

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Credit Counter	DSW	1

location

name	number	inverted
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Eremite	0	no
Display	1	yes

Speed Meter Display

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Speed Meter Display	DSW	2

location

name	number	inverted
SW2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
mph	0	no
km/h	2	yes

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW	4

location

name	number	inverted
SW2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	4	yes

Time Up Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Time Up Mode	DSW	8

location

name	number	inverted
SW2	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	8	yes

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW	48

location

name	number	inverted
SW2	4	no
SW2	3	no

value

name	value	default
Easy	0	no
Normal	48	yes
Hard	16	no
Hardest	32	no

Region

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Region	DSW	192

location

name	number	inverted
SW2	2	no
SW2	1	no

value

name	value	default
USA	128	no
Europe	0	yes
Europe	64	no
Japan	192	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	256

location

name	number	inverted
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	256	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	512

location

name	number	inverted
SW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	512	yes
On	0	no

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSW	7168

location

name	number	inverted
SW1	6	no
SW1	5	no
SW1	4	no

value

name	value	default
5 Coins/1 Credit	0	no
4 Coins/1 Credit	4096	no
3 Coins/1 Credit	2048	no
2 Coins/1 Credit	6144	no
1 Coin/1 Credit	7168	yes
1 Coin/2 Credits	3072	no
1 Coin/3 Credits	5120	no
1 Coin/4 Credits	1024	no

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSW	57344

location

name	number	inverted
SW1	3	no
SW1	2	no
SW1	1	no

value

name	value	default
5 Coins/1 Credit	0	no
4 Coins/1 Credit	32768	no
3 Coins/1 Credit	16384	no
2 Coins/1 Credit	49152	no
1 Coin/1 Credit	57344	yes
1 Coin/2 Credits	24576	no
1 Coin/3 Credits	40960	no
1 Coin/4 Credits	8192	no

Communication Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Communication Mode	DSW2	1

location

name	number	inverted
SW3	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Master	0	yes
Slave	1	no

Car ID

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Car ID	DSW2	14

location

name	number	inverted
SW3	2	no
SW3	3	no
SW3	4	no

value

name	value	default
1	0	yes
2	2	no
3	4	no
4	6	no
5	8	no
6	10	no
7	12	no
8	14	no
